Holding registers [DPU3 Series]
No. (address) Item
400001 (0000) Reference Value
400002 (0001) Start Limit Time
400003 (0002) Start Limit
400004 (0003) Soft Start Time
400005 (0004) Output High-Limit
400006 (0005) Output Low-Limit
400007 (0006) Remote SP1
400008 (0007) Remote SP2
400009 (0008) Remote SP3
400010 (0009) Remote SP4
400011 (000A) Remote SP5
400012 (000B) Remote SP6
400013 (000C) Slow Up Time
400014 (000D) Slow Down Time
400015 (000E) Current Limit
400016 (000F) Over current value
400017 (0010) Over current time
400018 (0011) Over voltage value
400019 (0012) Over voltage time
400020 (0013) Load detector alarm value
400021 (0014) Display selected contents
400022 (0015) Bar graph's content
400023 (0016) Control integer KP value
400024 (0017) Control integer KI value
400025 (0018) Control Method
400026 (0019) Digital input 1
400027 (001A) Digital input 2
400028 (001B) Digital input 3
400029 (001C) Auto ref input selector
400030 (001D) Load resistance display method
400031 (001E) Operation
400032 (001F) Output slope
400033 (0020) Base Up
400034 (0021) Input correction
400035 (0022) Input slope correction
400036 (0023) Overcurrent alarm output
400038 (0025) Overvoltage alarm output
400039 (0026) Fuse alarm
400041 (0028) Alarm heat sink temperature alarm
400042 (0029) SCR error alarm
400043 (002A) Heater break alarm
400044 (002B) Auto Gain
Digital Power Controllers
Factor
- *0.1 (0 to 1000)
0 to 100
S-LT
*0.1 (0 to 1100)
S-LM
0 to 100
ST-T
*0.1 (0 to 1100)
H-OL
*0.1 (0 to 1100)
L-OL
*0.1 (0 to 1000)
SP1
*0.1 (0 to 1000)
SP2
*0.1 (0 to 1000)
SP3
*0.1 (0 to 1000)
SP4
*0.1 (0 to 1000)
SP5
*0.1 (0 to 1000)
SP6
0 to 999
UP-T
0 to 999
DN-T
*0.1 (0 to 1100)
C-LM
*0.1 (0 to 1200)
OC-V
0 to 100
OC-T
*0.1 (0 to 1200)
OV-V
0 to 100
OV-T
*0.1 (100 to 5000)
HB-V
0 to 3
DISP
0: U-V, 1: V-W, 2: W-U, 3: LA-U, 4: LA-V, 5: LA-W, 6: KW, 7: REF
0 to 3
BAR
0: U-V, 1: V-W, 2: W-U, 3: LA-U, 4: LA-V, 5: LA-W, 6: KW, 7: REF
1 to 2000
P
*0.1 (1 to 9999)
I
1 to 6
C-MD
1: F-CY, 2: ONOF, 3: PA, 4: V-FB, 5: C-FB, 6: W-FB
DI-1
0 to 5
DI-2
0: SP M, 1: SP1, 2: SP2, 3: SP3, 4: RST, 5: HOLD
DI-3
0 to 6
IN-P
0: 4-20, 1: 0-20, 2: 1-5, 3: 0-5, 4: 0-10, 5: SSR, 6: COM
0 to 1
DRES
0: DOWN, 1: UP
Bit0... Fault
Bit1... I-OC
- Bit2... Over current
Bit3... Over volt
Bit4... Over temp
*0.001 (0 to 1000)
SLOP
*0.1 (0 to 1000)
B-UP
*0.1 (-999 to 999)
IN-B
*0.1 (-999 to 999)
SPAN
OC-A
OV-A
0 to 2
FUSE
0: NON, 1: AL1, 2: AL2
HEAT
SCR
HB-A
0 to 1
A-GA
0: OFF, 1: ON
Bit5... Fuse cut Bit10...
Bit6... Phase loss Bit11...
Bit7... Load open Bit12...
Bit8... SCR error
Bit9... Freq error
Run/Stop
Auto/Manual
EMS Power
L-49
