5

Setting - Lambda values - Broadband probe

Basic display
Residual oxygen content
Displays the current residual oxygen content.
Broadband probe type
(1 .. Bosch / 2 .. NTK)
(3 .. LSM11 input)
Setting the type of broadband probe used.
Lambda probe heating
▪ A 0: Automatic, Off; A 1: Automatic, On
▪ 1: Manual, On
▪ 0: Manual, Off
Broadband probe calibration (probe must be at 21% O2)
▪ YES: After activation of the lambda probe heating, the
broadband probe can be calibrated.
NOTICE! The broadband probe must be at 21% oxygen
(air)!
Broadband probe status
The following status displays are possible:
▪ Off
▪ Pre-Heating
▪ Normal operation
▪ Cooling
▪ Reheating
▪ Error
102
System Setting
Froling GesmbH | A-4710 Grieskirchen, Industriestraße 12 | www.froeling.com
Lambda values
Broadband probe
Broadband probe heating current
Display of the measured broadband probe heating current.
Broadband probe heating voltage
Display of the measured broadband probe heating voltage.
Broadband probe Nernst voltage
Display of the measured broadband probe Nernst voltage.
Broadband probe pump current
Display of the measured broadband probe pump current.
Broadband probe internal resistance
Display of the measured broadband probe internal
resistance.
Parameters overview
System
