nordictrack.ca USER’S MANUAL Model No. NTL59621C.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to iconservice.ca. CUSTOMER CARE Call toll-free 1-888-936-4266 Mon.–Fri.
Note: The decals may not be shown at actual size. 305284 NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Wi-Fi is a registered trade- mark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi Alliance. The Bluetooth word mark and logos are ®...
To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4
19. Always stand on the foot rails when starting frame securely in the storage position. Do or stopping the walking belt. Always hold the not operate the treadmill while it is folded. handrails while using the treadmill. 26. Do not change the incline of the treadmill by 20.
BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK manual. To help us assist you, note the product model ® C 1000 treadmill. The C 1000 treadmill provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
ASSEMBLY • Assembly requires two persons. • Left parts are marked “L” or “Left” and right parts are marked “R” or “Right.” • Place all parts in a cleared area and remove the packing materials. Do not dispose of the packing •...
Page 9
2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (80) to the front of the Base (88). Next, identify the Right Upright (79). Have a second person hold the Right Upright near the Base (88).
Page 10
4. Set the Right Upright (79) on the Base (88) as shown. Do not pinch the Upright Wire (80). Slide the Right Upright so that the 3/8" x 2 3/8" Screw (2) in the Base is inserted into the slot (E) in the Right Upright;...
Page 11
6. Remove and save the four indicated 5/16" x 3/4" Screws (13). Identify the Left and Right Base Covers (93, 94). Slide the Left Base Cover onto the Left Upright (78), and slide the Right Base Cover onto the Right Upright (79). Do not press the Base Covers into place yet.
Page 12
9. Carefully slide the Upright Crossbar (77) between the Left and Right Uprights (78, 79). Attach the Upright Crossbar with the four 5/16" x 3/4" Screws (13) that you removed in step 6 7 13 and four 5/16" Star Washers (7); start all four Screws, and then tighten them.
Page 13
11. IMPORTANT: To avoid damaging the Crossbar (75), do not use power tools and do not overtighten the #10 x 3/4" Screws (9). Orient the Crossbar (75) as shown. Attach the Crossbar to the Handrails (72) with four #10 x 3/4"...
Page 14
13. Set the console assembly (K) on the Handrails (72). Do not pinch any wires. Insert the excess Upright Wire (80) into the con- sole assembly (K). Then, tighten the two ties (M) around the Upright Wire and cut off the ends of the ties.
Page 15
15. Slide the Right Handrail Cover (71) onto the right Handrail (72) and against the console assem- bly (K). Tighten a #8 x 3/4" Screw (11) into the bottom of the Right Handrail cover; do not over- tighten the Screw. Attach the Left Handrail Cover (70) to the left Handrail (72) in the same way.
Page 16
17. Raise the Frame (54) to the upright position. Have a second person hold the Frame until step 19 is completed. Remove the two 5/16" x 3/4" Screws (13) from the Latch Crossbar (51). Next, orient the Latch Crossbar (91) as shown. Make sure that the “This side toward belt”...
Page 17
19. Remove the 5/16" Nut (90) and the 5/16" x 2 1/4" Bolt (89) from the bracket on the Latch Crossbar (91). Align the upper end of the Storage Latch (52) with the bracket on the Latch Crossbar (91), and insert the 5/16"...
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD capable of carrying 15 or more amps. To avoid overloading the circuit, do not plug other electrical Use a Surge Suppressor devices, except for low-power devices such as cell phone chargers, into the surge suppressor or into Your treadmill, like other electronic equipment, can be an outlet on the same circuit.
Page 19
CONSOLE DIAGRAM FEATURES OF THE CONSOLE In addition, the console features a selection of work- outs. Each workout automatically controls the speed The advanced treadmill console offers a selection of and incline of the treadmill as it guides you through an features designed to make your workouts more effec- effective exercise session.
Page 20
HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the treadmill has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you become perature before you turn on the power.
Page 21
HOW TO SET UP THE CONSOLE 5. Check for firmware updates. Before using the treadmill for the first time, set up the First, touch your name or Hello on the screen, and then touch Settings. Next, select the maintenance console. section.
Page 22
HOW TO USE THE MANUAL MODE 4. Change the incline of the treadmill as desired. 1. Insert the key into the console. To change the incline of the treadmill, press the incline increase and decrease buttons or one of the See HOW TO TURN ON THE POWER on page numbered incline buttons.
Page 23
If you wish to save your icon on the screen. To draw your own map work- workout for future use, you can add it as a favorite out, see page 24.
Page 24
5. Monitor your progress with the display modes. 4. Save your workout. See step 5 on page 22. Touch Save New Workout on the screen. If desired, change the title of the workout or add a description, 6. When you are finished exercising, remove the and then press the >...
Page 25
Note: To use a distance or time workout, the console must be connected to a wireless network (see HOW Touch the calendar icon to download a distance or TO CONNECT TO A WIRELESS NETWORK on time workout from your schedule.
Page 26
HOW TO CHANGE CONSOLE SETTINGS 4. View machine information. IMPORTANT: Some of the settings and features Touch Equipment Info, and then touch Machine described may not be enabled. Occasionally, a Info to view information about your treadmill. firmware update may cause your console to function slightly differently.
Page 27
HOW TO CONNECT TO A WIRELESS NETWORK An information box will ask if you want to connect to the wireless network. Touch Connect to connect The console is Wi-Fi enabled, allowing you to set up a to the network or touch Cancel to return to the list wireless network connection.
Page 28
HOW TO USE THE SOUND SYSTEM THE OPTIONAL CHEST HEART RATE MONITOR To play music or audio books through the console Whether your sound system while you exercise, plug a 3.5 mm male goal is to to 3.5 mm male audio cable (not included) into the burn fat or to jack on the console and into a jack on your personal strengthen your...
IC INFORMATION This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at to zero before you fold the treadmill. Then, remove the left.
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE b. After the power cord has been plugged in, make sure that the key is inserted into the console. Regular maintenance is important for optimal per- formance and to reduce wear. Inspect and properly c. Check the power switch located on the treadmill tighten all parts each time the treadmill is used.
Page 32
SYMPTOM: The incline of the treadmill does not c. Your treadmill features a walking belt coated with change correctly high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking platform unless a. Calibrate the incline system (see step 6 on page 26). instructed to do so by an authorized service SYMPTOM: The treadmill will not connect to the representative.
Page 33
SYMPTOM: The walking belt slips when walked on SYMPTOM: The displays of the console do not function properly a. First, remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the console does not boot up properly, or screws clockwise, 1/4 of a turn.
EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian.
This warranty extends only to the original purchaser (customer) and is not transferrable. ICON’s obliga- tion under this warranty is limited to repairing or replacing, at ICON’s option, the product through one of its authorized service providers. All repairs for which warranty claims are made must be preauthorized by ICON.
