12

Parts list

12.1

Replacement diaphragms

Material
Standard
Silicone
Silicone Plus
EPDM
EPDM Plus
Viton A
Viton A
(steam grade)
Viton GF
PTFE
12.2

Actuator maintenance kits

MNXX/PNXX Series (Stainless steel actuators)
Part # Applicable To
MAK-100 0.5" - 3.0" manual actuators
MAK-400 4.0" manual actuator
PAK-050 0.5" pneumatic actuator
PAK-100 1.0" pneumatic actuator
PAK-200 1.5"/2.0" pneumatic actuator
PAK-300 3.0" pneumatic actuator
PAK-400 4.0" pneumatic actuator
m-radialdiaphragmvalve-en-02
0.5" 0.5"
Extended
SL05 SG05
PS05 PSG05
EP05 EG05
PE05 PEG05
VT05 VG05
VA05 N/A
N/A VGF05
N/A PFG05-1
1.0" 1.5"
SL10 SL17
PS10 PS17
EP10 EP17
PE10 PE17
VT10 N/A
VA10 N/A
N/A N/A
PF10-1 PF17-1
Description
Includes O-rings, guide bushing, and wiper
seal
Includes O-rings, guide bushing, and wiper
seal
Includes O-rings, guide bushing, and quad
ring
Includes O-rings, guide bushing, and quad
ring
Includes O-rings, guide bushing, and quad
ring
Includes O-rings, guide bushing, and quad
ring
Includes O-rings, guide bushing, and quad
ring
1.5/2.0" 3"
SL20 SL30
PS20 PS30
EP20 EP30
PE20 PE30
VT20 VT30
VA20 VA30
VF20 VF30
PF20-1 PF30-1
4"
SL40
N/A
EP40
N/A
N/A
N/A
N/A
N/A
