PARTS REFERENCE - BRAKE GROUP

ITEM NO. QTY.
260 1
286 1
293 1
507 1
515 1
615 2
617 1
700 1
706 1
707 1
710 1
711 1
712 1
713 14
715 13
720 1
722 1
723 1
724 1
727 1
730 1
738 1
750 1
751 1
752 8
753 1
755 1
800 1
811 1
815 2
817 2
821 6
823 6
830 1
831 2
832 2
834 2
840 1
850 1
955 2
970 2
971 16
973 16
PAGE 28
PART NO.
21015 FREESPOOL COUPLING
20901 JOURNAL BEARING
25584 O-RING - 016 5/8 "ID 1/16" CS
25664 SPHERICAL ROLLER BEARING
25665 OIL SEAL 3.375 X 4.000 X .500
26229 THRUST WASHER TORRINGTON # FTRA 4060
25667 THRUST BEARING TORRINGTON # FNT 4060
20869 BRAKE HOUSING
21048 BRONZE WASHER
25061 O-RING - 163 6" ID 3/32" CS
20896 BACK-UP WASHER
25666 OIL SEAL**
20874 BRAKE SPACER
25624 DIVIDER PLATE
25623 FRICTION PLATE
20890 BRAKE HUB
20421 SPRAG CLUTCH ALIGNER
25303 SPRAG CLUTCH BORG WARNER # 140373 "B"
20421 SPRAG CLUTCH ALIGNER
25335 CIRCLIP ANDERTON # N1400 - 0196
20891 BRAKE SHAFT
21021 COUPLING FASTENER
21153 PISTON
25629 O-RING - 90 DURO - 253 5-3/8" ID 1/8" CS
20859 BRAKE SPRING
25630 O-RING - 90 DURO - 256 5-3/4" ID 1/8" CS
25370 PIPE PLUG 1/16NPT SOCKET HEAD
* MOTOR ADAPTOR
26624 O-RING 100 MM ID x 2 MM CS
25013 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.25 GR 5
25014 LOCKWASHER 1/2"
25013 CAPSCREW - HEX HEAD 1/2 - 13NC X 1.25 GR 5
25014 LOCKWASHER 1/2"
20902 CONNECTING TUBE
25018 O-RING - 010 1/4" ID 1/16" CS
21524 CHECK VALVE
25738 O-RING .306 ID X .034 C/S
20870 SAFETY VALVE
* MOTOR - 070 HIGH TORQUE LOW SPEED 12.9 CID
25687 PLASTIC CAPLUG SAE # 10 ORB
20892 TIE BAR
25265 CAPSCREW - HEX HEAD 7/16 - 14NC X 1.25 GR 5
25328 LOCKWASHER 7/16"
23124 WINCH SEAL KIT, CONSISTS OF ITEMS:
105, 123, 257, 265, 277, 293, 299, 515, 707,
710, 711, 751, 753, 811, 831 AND 834
23118 MOTOR SEAL KIT
* These part numbers and descriptions vary according to brake code.
Refer to APPENDIX B.
** Do not substitute.
Available from PULLMASTER or Authorized Dealer only.
Refer to PAGES 30 & 31 for ASSEMBLY DRAWINGS.
