- Page 1 ROVER LiTHIUM 70AH POWER STATION OWNERS MANUAL Part No. 10000072...
-
Page 2: Safety Information
IMPORTANT: PLEASE READ, UNDERSTAND AND FOLLOW THIS INSTRUCTION MANUAL CAREFULLY BEFORE FIRST USE, AND STORE IT IN A SAFE PLACE FOR FUTURE REFERENCE. SAFETY INFORMATION • Follow the instructions within this manual carefully as to not cause harm to yourself or others •... -
Page 3: General Safety
70AH POWER STATION GENERAL SAFETY • Only use the device as intended • DO NOT insert foreign objects into the input/output ports • DO NOT attempt to open, repair or replace the internal battery or any parts • DO NOT pull on the cords to unplug input/output power from the device •... - Page 4 UNDERSTANDING YOUR APPLIANCE 1. ON/OFF POWER BUTTON 2. INDICATOR LIGHTS 3. 4X USB OUTPUT, 1X USB C OUTPUT 4. USB ON/OFF BUTTON 5. DC, AC OR SOLAR INPUT 6. 12V 2 PIN OUTPUT 7. 12V CIGARETTE OUTPUT 8. LED LIGHT 9.
-
Page 5: Understanding The Lcd Display
70AH POWER STATION USB Outputs LCD Screen UNDERSTANDING THE LCD DISPLAY USB Outputs LCD Screen Type C Output USB Power Button Power Button Type C Output USB Power Button Power Button 12V 2-Pin Output 12V Cigarette Output 12V 2-Pin Output 12V Cigarette Output AC, DC, or Solar Input LED Light... - Page 6 TO RECHARGE BATTERY The Rover Li 70 uses a Lithium Nickel Manganese Cobalt Oxide battery or NMC for short. There are three ways the battery can be charged - DC Cable, 240V AC Adaptor or Solar Panel. The power station can only be charged using one of the above options as all three use the same input.
- Page 7 70AH POWER STATION CHARGING BY DC CABLE (INCLUDED) Step 1. Turn on the power station by holding the power button for three seconds. Step 2. Insert the adaptor plug into the input socket on the side of the power station and the DC charger to your power source.
- Page 8 Charging by Solar Panel (not included) The power station has a built in MPPT controller so you do not need to use a solar controller. The solar panel MUST be connected directly to the power station with unregulated solar. Step 1 .
-
Page 9: Powering Appliances
70AH POWER STATION POWERING APPLIANCES The power station consists of multiple outputs that can be used at the same time. Step 1. Turn on the power station by holding the power button for three seconds. Step 2. Each power outlet have there own individual on/off buttons. Press the power button and it will allow power to that socket. - Page 10 Note: The power station has the following protective functions - over temperature protection, under temperature protection, overvoltage protection, undervoltage protection, overcurrent protection, short circuit protection and incorrect polarity protection. If these are activated the alarm LED will flash on the front of the power station. Remove all Inputs and Outputs and turn the power station off and back on.
-
Page 11: Cleaning Instructions
70AH POWER STATION CLEANING INSTRUCTIONS Step 1. Ensure the device is disconnected from the mains before performing any cleaning or device maintenance. Step 2. DO NOT use sharp or hard objects, or cleaning agents to clean as these may damage the product. Step 3. -
Page 12: Troubleshooting
TROUBLE SHOOTING Situation Probable Cause Solution Check power station is turned on Turn on the power outputs by Power outlets are not working and relevant outlet power is turned pressing theindividual power button after the power station is on. Check power station is turned on Turn power station on Fridge connected but Check power station has sufficient... -
Page 13: Specifications
70AH POWER STATION SPECIFICATIONS 10000072 Part no. LiNiMnCoO2 (NMC) Cell Chemistry Capacity 70Ah Wh (Watt hours) 850Wh Lifecycles 800 cycles (80% Capacity Afterwards) Shelf Life 1 year Management System MPPT Solar Input 13-30V 12A 14V 9A (Max 126W) DC Charger AC Charger 16.8V 5A (Max 84W) USB Output... - Page 14 NOTES...
-
Page 15: Warranty Policy
70AH POWER STATION WARRANTY POLICY 1. Products distributed by Adventure Operations Australia Pty Ltd and any of our subsidiaries come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. - Page 16 WARRANTY - For details see www.companionleisure.com.au/warrant Companion is a registered trademark of ® Primus Australia Pty Ltd Designed & Imported by : Adventure Trading Australia Pty Ltd 71 Charles Ulm Place, Eagle Farm, QLD 4009 AUSTRALIA Made in China...
