Summary of Contents for GAOMON PD1161
- Page 2 D. When obvious abnormalities occur to the display. 13. While getting the components replaced, you are supposed to guarantee that the repairman is using the substitute components specified by the manufacturer. Unauthorized component replacement might cause fire, electric shocks or other dangers. www.gaomon.net...
-
Page 3: Table Of Contents
1.4 Driver Installation ......................6 1.5 Pen Nib Replacement ....................7 2. OSD Setting ..........................7 3. GAOMON Driver Setting ...................... 8 3.1 Device Connection Prompt ..................8 3.2 Working Area Setting ....................8 3.3 Press Keys Function Setting ..................10 3.4 Pen Button Setting ....................... -
Page 4: Product Overview
1.1 Product Introduction ® Thanks for choosing GAOMON PD1161 graphics display. This is a new generation of portable desktop-level professional drawing display, which can greatly improve your work efficiency of painting and creation, and full of fun. You can freely painting and writing, depicting different lines and colors, just as the pen writes on the paper, which brings you a real shock experience. - Page 5 1.2.2 Stylus Pen The stylus pen is a battery-free pen with 8192 levels pressure sensitivity and two customizable button. 1.2.3 3-in-2 Connection Cable ① ② ③ ④ ⑤ ①Video ②USB Type-C ③USB A ④HDMI ⑤Power www.gaomon.net...
- Page 6 1.2.4 Power Adapter Please choose the right plug according to your country or region, and assemble it to the power adapter.（It may not come with all the plugs） 1.2.6 Other Accessories www.gaomon.net...
-
Page 7: Display Connection
Windows 7 or later，macOS 10.12 or later 1.4.2 Install via Download Please download the driver from our website: www.gaomon.net/download After finishing installation, you can find the driver icon in the system tray area, which means the driver was installed successfully; When you connect the display to... -
Page 8: Pen Nib Replacement
: After entering menu, it’s function is to up/right/increase. MENU : Press to call up the menu, after entering menu, it’s function is confirm. POWER : Power on/off the display. Remark：Through the OSD menu, you can adjust the screen brightness, contrast, color and other parameters. www.gaomon.net... -
Page 9: Gaomon Driver Setting
2.Device connected: has been recognized by your computer successfully already. 3.2 Working Area Setting 3.2.1 Using Multiple Monitors When the GAOMON Display and other monitors are used in the same system, the movement of the screen cursor on the standard display depends on the system configuration. - Page 10 3. Customized Area: 1.> Enter coordinate values. Or 2.> Drag the corners of the foreground graphic to select the screen area. 3.2.3 Rotate Working Area By changing the direction of the display to adapt to the left and right hand operation. We provide four directions of choice. www.gaomon.net...
-
Page 11: Press Keys Function Setting
Default Setting: Place the cursor on the button or click the button icon to see the default values for the press keys Customized Express Keys: Select the function to be achieved on the pop-up dialog box, then click APPLY or OK to take effect. Enable/Disable Press Key: Check/Uncheck “Enable Press key” 10 / www.gaomon.net... -
Page 12: Pen Button Setting
Select the function to be achieved on the pop-up dialog box, then click APPLY or OK to take effect. 3.5 Pressure Sensitivity Setting The pressure sensitivity will be changed by dragging the slider up and down, the smaller the value, the more sensitive the pressure. 11 / www.gaomon.net... -
Page 13: Pen Pressure Testing
You can gradually apply pressure to the stylus on the screen to test the pressure level. 3.7 Enable the Windows Ink feature Microsoft Windows provides extensive support for pen input. Pen features are supported in such as Microsoft Office、Windows Journal、Adobe Photoshop CC、 SketchBook 6 and so on. 12 / www.gaomon.net... -
Page 14: Calibration
Screen Calibration: Click the red point of the cross center appearing on the screen to complete the calibration. Restore Factory Settings: Click "Restore Default" to restore to the factory settings. Cancel Calibration: Click"Cancel calibration” or press ESC on the keyboard to cancel the calibration. 13 / www.gaomon.net... -
Page 15: Data Export And Import
3.9 Data Export and Import The driver supports exporting and importing your customized configuration data of the product, which is convenient for you to use different software and avoid the trouble of repeated settings. 14 / www.gaomon.net... -
Page 16: Specifications
4. Specifications Model PD1161 Panel Size 11.6inch Resolution 1920 x 1080(16:9) LCD Type TFT LCD IPS Active Area 256.32 x 144.18mm Contrast Ratio 1000:1 Screen Brightness 220cd/m Response Time 25ms 89°/89°(H)/89°/89°(V) View Angle (Typ.)(CR＞10) Gamut 72%(NTSC) Touch Type Electromagnetic Resonance... -
Page 17: Trouble Shooting
Check "Mirror Displays" 3. If you decide to use in Extended mode. Make sure to choose pen display as Work Area in GAOMON Driver. It is usually ''Display 2''. Please set the display resolution with 1920 x 1080. - Page 18 10 mm There is a deviation between Try calibration the tip and the cursor GAOMON driver indicates ''device connected'', but the pen doesn ’ t respond in Mac OS 10.14 or above versions. Find answer here: https://www.gaomon.net/question/macos_mojave_catalina_solution.html...
