Chapter

BREAKDOWN INFORMATION

8.1.

ALARM MESSAGES

In the event of a breakdown during operations the ma-
chine stops automatically and alarm messages appear
on the display.
The table lists the displayed messages, the type of
problem, the cause and possible solutions.
Alarm Problem
E11 Carriage descent safety alarm
E30 Main inverter alarm
E31 Carriage inverter alarm
E32 Film pre-stretch inverter alarm
E33 Film pull inverter alarm
E41 Serial communication alarm
Cycle parameter initialisation
E42
alarm
Machine configuration parame-
E43
ter initialisation alarm
E44 PLC RESET alarm
Serial communication alarm
E46
(pre-stretch card)
Serial communication alarm (I/
E47
O expansion card)
E60 Film end/broken alarm.
E61 Table blocked alarm
E70 Function disabled alarm
E90 Low voltage alarm
E91 High voltage alarm
English
8
Cause
An obstacle has been detected
along the path during the reel car-
riage descent.
Inverter overload
Inverter overload
Inverter overload
Inverter overload
Electronic anomaly
Electronic anomaly
Electronic anomaly
Electronic anomaly
Electronic anomaly
Electronic anomaly
The film is broken or the spool is
empty.
A breakdown or obstacle block ta-
ble rotation
A function was selected from the
control panel that is not enabled
for the type of reel carriage in-
stalled on the machine or the key-
board block is on
Voltage is lower than the allowed
minimum
Voltage is higher than the maxi-
mum allowed value
Information
For these operations a precise technical skill or
ability is required and must therefore be exclu-
sively performed by qualified personnel with cer-
tified experience acquired in the specific field.
- 37 -
Solution
Remove the obstacle and press
the "Reset" button
Remove the overload cause and
press the "Reset" button.
Remove the overload cause and
press the "Reset" button.
Remove the overload cause and
press the "Reset" button.
Remove the overload cause and
press the "Reset" button.
Contact the service centre
Contact the service centre
Contact the service centre
Contact the service centre
Contact the service centre
Contact the service centre
Insert the film or replace the reel
Fix the breakdown or remove the
obstacle and press the "Reset"
button
Select another function from the
control panel or release the key-
board.
Reset the voltage value
Reset the voltage value
