Installation instructions United States and Canada

• Attention! Electrical devices may only be mounted and connected by electrically skilled
persons.
• For safe installation, commissioning and operation, the instruction and legal manual with
the product must be read. Ensure always install the product according to the local
electrical code.
• Before any assembly or disassembly or replacement of the battery always switch off the
circuit breaker.
!
• Make always sure nobody can switch on the circuit breaker while working
• It's advised to check if there is no voltage, ground and shortcut on any parts
• Cover up live wires
• Test if the power is off before proceeding
Only proceed when above is checked.
Advice: Print the manual and strikethrough above points to ensure a safe working situation
After installation:
• Always make sure your room after installation has at least one light switch left that can
cut the power physically
NOTE: If the wiring in the wall box does not resemble any of these configurations, consult
an electrician.
1 1
2
3
4
Single Pole
1. Line (Hot)
2. Neutral
3. Ground
4. Load
1 1
2
3
4
5
3-Way
1. Line or Load
2. Neutral
3. Ground
4. First Traveler - note colour
5. Second Traveler - note colour
19
