1.1 Specifications
Model
P.T.O. Horsepower
Drive
Gearbox
Gearbox oil
Cutting Reels
Cutting width
Cutting depth (nominal)
Blades
Standard :
Optional :
Blade tip speed
Weight
Height
Overall Width
Length
Tyres
Tyre pressure
Rotor belts
Graden SW04 Swing-Wing Verticutter
20 - 35 h.p.
Belt drive via Tractor PTO
Comer T27A Increasing Gearbox
Gear Oil - SAE 80W90
1 Fixed (13 blades), 2 Floating (8 blades ea.)
1520mm (60 inches)
0 to 40mm (maximum with standard blades)
Tungsten carbide tipped spring steel
210mm x 2mm tip Part No. 0232
210mm x 3mm tip Part No. 0217
210mm x 1mm tip Part No. 1122
1250m/min (standard blades at normal PTO
speed of 540 rpm)
290 kg
1110 mm (machine on stands)
1980 mm
1330mm
4.10/3.50 - 4 Slick Pattern (6 per machine)
275 - 345 kPa (40 -50 psi)
A47 Dayco Super 2 Series (8 per machine)
