FlameGard® 5 UV/IR
HART
HART Communication Manual
FlameGard 5 UV/IR HART
The information and technical data disclosed in
this document may be used and disseminated
only for the purposes and to the extent
specifically authorized in writing by MSA.
Instruction Manual
MSA reserves the right to change published
specifications and designs without prior notice.
Part No.
Revision
MAN5UVIRH
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlameGard 5 UV/IR and is the answer not in the manual?

Questions and answers

Related Manuals for MSA FlameGard 5 UV/IR

Summary of Contents for MSA FlameGard 5 UV/IR

  • Page 1 MSA. Instruction Manual MSA reserves the right to change published specifications and designs without prior notice. Part No. MAN5UVIRH Revision...

  • Page 2: Table Of Contents

    Local Interfaces, Jumpers, and Switches ..................4 5.0 DEVICE VARIABLES......................5 6.0 DYNAMIC VARIABLES ......................5 Primary Variable = FlameGard 5 UV/IR Operating Mode............5 Secondary, Tertiary, and Quaternary Variables: Not Applicable ..........5 7.0 STATUS INFORMATION ....................... 5 8.0 UNIVERSAL COMMANDS..................... 6 9.0 COMMON PRACTICE COMMANDS ..................
  • Page 3 Command #205: Get Flame Device Info..................21 11.0 TABLE ........................22 11.1 FlameGard 5 UV/IR-HART– Device Specific Commands Summary........22 11.2 FlameGard 5 UV/IR – Operating Mode Values ...............22 11.3 Fault Event Log – Cause Description ..................23 12.0 PERFORMANCE ...................... 23 12.1 Sampling Rates........................23...

  • Page 4: Table Of Tables

    Table 2: Analog Output Current Values........................4 Table 3: Error Status Information ........................... 5 Table 4: FlameGard 5 UV/IR – Common Practice Commands................6 Table 5: FlameGard 5 UV/IR – Device Specific Commands................22 Table 6: FlameGard 5 UV/IR Operating Mode Values ..................23 Table 7: Fault Event Log –...

  • Page 5: Introduction

    1.0 Introduction 1.1 Scope The FlameGard 5 UV/IR Flame Detector complies with HART Protocol Revision 6.0. This document specifies all of the device specific features and documents HART Protocol implementation details. The functionality of this Field Device is described sufficiently to allow its proper application in a process and its complete support in HART capable Host Applications.

  • Page 6: Device Identification

    Getting Started In order to enable HART communication with the FlameGard 5 UV/IR Flame Detector, users may employ several means including HART handheld communicators or PC-based systems. Using a PC- based software application and a HART interface modem, for example, allow operators to access information from the FlameGard 5 UV/IR Flame Detector.
  • Page 7 PC, host application, or handheld terminal, the master will commonly begin communication to the FlameGard 5 UV/IR Flame Detector by using the HART Command #0. The field device will then respond only if its tag matches. The data in the reply to Command #11 is identical to that of Command #0, so the master can then construct the Unique Identifier for use with further commands.

  • Page 8: Product Interfaces

    Table 2: Analog Output Current Values 4.2.1 Analog Output: FlameGard 5 UV/IR Flame Detector Mode The FlameGard 5 UV/IR Flame Detector Mode is output to the user as the primary variable of the HART protocol. Table 6 shows the interpretation of this variable.

  • Page 9: Device Variables

    The device mode is the variable, which corresponds to the Modbus register 0x00. 6.2 Secondary, Tertiary, and Quaternary Variables: Not Applicable There are none defined for the FlameGard 5 UV/IR Flame Detector. 7.0 Status Information The error status, which is returned via Common Practice Command #48, is shown in Table 3 and corresponds to Modbus register 0x02.

  • Page 10: Universal Commands

    Table 4: FlameGard 5 UV/IR Flame Detector – Common Practice Commands 9.2 Burst Mode The FlameGard 5 UV/IR Flame Detector does not support Burst Mode. 9.3 Catch Device Variable This FlameGard 5 UV/IR Flame Detector does not support Catch Device Variable.

  • Page 11: Device Specific Commands

    FlameGard 5 UV/IR HART 10.0 Device Specific Commands The Device Specific commands are used strictly for the unique features of the FlameGard 5 UV/IR Flame Detector and at the discretion of MSA. They are described here in Section 10.0 and are summarized in Table 5.

  • Page 12: Command #139: Reset Alarm

    FlameGard 5 UV/IR HART Code Class Description 17 - 127 Undefined 10.3 Command #139: Reset Alarm This command will reset the latching warn and alarm relay. Request Data Bytes Byte Format Description None Response Data Bytes Byte Format Description None...

  • Page 13: Command #142: Reset Event Happened Flag

    FlameGard 5 UV/IR HART Unsigned-8 Alarm Lo Relay En/dE: 0 – dE, 1 – En Unsigned-8 zero Unsigned-8 zero Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1 – 2 Undefined Error Passed Parameter too large Undefined Error...

  • Page 14: Command #144: Clear Event Logging Counters

    FlameGard 5 UV/IR HART 4 – 5 Unsigned-16 Fault Event Counter 6 – 7 Unsigned-16 Maintenance Event Counter 8 – 9 Unsigned-16 Calibrate Event Counter Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.7 Command #144: Clear Event Logging Counters This resets the 5 event logging counters to zero.

  • Page 15: Command #146: Read Alarm Event Log

    FlameGard 5 UV/IR HART 10-13 Unsigned-8 Reserved = 0 Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.9 Command #146: Read Alarm Event Log This reads the Alarm Event Log as specified by the event log number. Event 0 is the most recent event.

  • Page 16: Command #148: Read Maintenance Event Log

    FlameGard 5 UV/IR HART Response Data Bytes Byte Format Description 0 – 3 Unsigned-32 Event Running Time (in Seconds) 4– 6 Date Event Date: Day, Month, Year – 1900 Unsigned-8 Event Hour Unsigned-8 Event Minute Unsigned-8 Event Second 10-11 Unsigned-16 Event Cause –...

  • Page 17: Command #149: Set Clock

    FlameGard 5 UV/IR HART 10.12 Command #149: Set Clock This sets the internal real-time clock. Request Data Bytes Byte Format Description 0 – 2 Date Date: Day, Month, Year-1900 Unsigned-8 Hours Unsigned-8 Minutes Unsigned-8 Seconds Response Data Bytes Byte Format Description 0 –...

  • Page 18: Command #151: Set Run Time Meter

    FlameGard 5 UV/IR HART Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.14 Command #151: Set Run Time Meter This sets the internal run time meter. Request Data Bytes Byte Format Description 0 – 3 Unsigned-32...

  • Page 19: Command #154: Set Event Index

    FlameGard 5 UV/IR HART 10.16 Command #154: Set Event Index This sets the index of logged event to read from 0 to the latest event. Request Data Bytes Byte Format Description Unsigned – 8 Sets index of logged event to read using commands 143 – 146.

  • Page 20: Command #163: Get Fast Changing Information

    FlameGard 5 UV/IR HART 10.18 Command #163: Get Fast Changing Information Request Data Bytes Byte Format Description None Response Data Bytes Byte Format Description 0 – 1 Unsigned-16 Mode – depends on instrument (see table 5) 2 – 3 Unsigned-16 Sub Mode –...

  • Page 21: Command #165: Get Set Up Information

    Format Description Unsigned-8 FlameGard 5 UV/IR Flame Detector TYPE: Standard 01, Long range 02, Hydrogen 03 Enumerated Measured Units - FlameGard 5 UV/IR Flame Detector Operating Mode 2- 5 Unsigned-32 Unsigned-8 Unsigned-8 Alarm Hi Relay La/nL: 0 – nL, 1 – LA Unsigned-8 Alarm Hi Relay En/dE: 0 –...

  • Page 22: Command #166: Get Device Constants

    FlameGard 5 UV/IR HART Current Range: 0= 3.5 – 20, 1=1.25 – 20 Unsigned-8 Command-Specific Response Codes Code Class Description Success No Command-Specific Errors 1-127 Undefined 10.21 Command #166: Get Device Constants Request Data Bytes Byte Format Description None Response Data Bytes...

  • Page 23: Command #200: Set Sensitivity

    FlameGard 5 UV/IR HART 10.23 Command #200: Set Sensitivity This sets the sensitivity parameter on flame detectors to increase the range of their view. Request Data Bytes Byte Format Description Unsigned 8 Sensitivity: 0- 100% hi, 1- 75% mid, 2 -50% low...

  • Page 24: Command #203: Set Dip Switch Override

    FlameGard 5 UV/IR HART Code Class Description Error Too Few Data Bytes Received 6 - 127 Undefined 10.25 Command #203: Set DIP Switch Override Request Data Bytes Byte Format Description Unsigned-8 0 – Setting from Switch, 1 – Override Switch...

  • Page 25: Command #205: Get Flame Device Info

    FlameGard 5 UV/IR HART 10.27 Command #205: Get Flame Device Info Request Data Bytes Byte Format Description None Response Data Bytes Byte Format Description 0 – 1 Unsigned-16 UV signal counts 2 – 3 Unsigned -16 UV COPM Fault count 4 –...

  • Page 26: Table

    FlameGard 5 UV/IR HART 11.0 Table 11.1 FlameGard 5 UV/IR-HART – Device Specific Commands Summary The following Table 5 is a summary of the FlameGard 5 UV/IR Device Specific Commands. Command Byte Number Meaning Number Abort Alarm Test Alarm Test...

  • Page 27: Fault Event Log - Cause Description

    0x0080 Flash Checksum Table 7: Fault Event Log – Cause Description 12.0 Performance 12.1 Sampling Rates The FlameGard 5 UV/IR Flame Detector responds to interrupts from the sensors. Other items are sampled at a 35 or multiple of 35 ms.

  • Page 28: Power-Up

    The FlameGard 5 UV/IR Flame Detector does not use delayed-response times. 12.7 Long Messages The largest data field used by FlameGard 5 UV/IR Flame Detector is in response to Command 20 & 22 (Read/Write Long Tag): 34 bytes including the two status bytes.

  • Page 29: Operating Modes

    FlameGard 5 UV/IR HART 12.9 Operating Modes The FlameGard 5 UV/IR Flame Detector reports No Fire in ready state. Various other modes are used to indicate wither UV and/or IR is detected. Other modes are used to show special states.

  • Page 30: Annex B. Default Configuration

    FlameGard 5 UV/IR HART 14.0 Annex B. Default Configuration Parameter Default value Lower Range Value Upper Range Value 65535 PV Units FlameGard 5 UV/IR Flame Detector Operating Mode Sensor type UV/IR Number of wires Damping time constant Fault-indication jumper Write-protect jumper...
  • Page 31 FlameGard 5 UV/IR HART...
  • Page 32 MINE SAFETY APPLIANCES COMPANY CRANBERRY TOWNSHIP, PENNSYLVANIA, USA 16066 1-800-MSA-INST www.msanet.com...
