FUNCTIONAL DESCRIPTION

UM-6800A

July 2005

Revision Number: 1.3

Table of Contents

Need help?

Do you have a question about the Microlok II and is the answer not in the manual?

Questions and answers

Summary of Contents for Union Switch & Signal Microlok II

Page 1 UM-6800A FUNCTIONAL DESCRIPTION THIS DOCUMENT AND ITS CONTENTS ARE THE PROPERTY OF UNION SWITCH & SIGNAL INDIA. HEREINAFTER USSI) FURNISHED TO YOU ON THE FOLLOWING CONDITIONS: NO RIGHT OR LICENSE IN RESPECT TO THIS DOCUMENT OR ITS CONTENTS IS GIVEN OR WAIVED IN SUPPLYING THE DOCUMENT TO YOU. THIS DOCUMENT OR ITS CONTENTS ARE NOT TO BE USED OR TREATED IN ANY MANNER INCONSISTENT WITH THE RIGHTS OF USSI AND ARE NOT TO BE COPIED, REPRODUCED, DISCLOSED TO OTHERS OR DISPOSED OF EXCEPT WITH THE PRIOR WRITTEN CONSENT OF USSI.
Page 3 USSI Microlok II Functional description DOCUMENT APPROVAL RECORD A.Muruganantham This Issue Authored By: Date: 19 July 2004 Title of Author: Design Engineer This Issue Approved By: G.Perumalsamy Date: 19 July 2004 Title of Approver: Design Manager DOCUMENT CHANGE RECORD Issue No:...
Page 4: Table Of Contents
6.1. MICROLOK II SOFTWARE ____________________________________________________ 19 6.1.1. EXECUTIVE SOFTWARE ___________________________________________________ 19 6.1.2. APPLICATION SOFTWARE__________________________________________________ 20 7.1. MICROLOK II VITAL DIAGNOSTICS ____________________________________________ 20 8.1. SYSTEM OPERATING MODES ________________________________________________ 21 8.1.1. NORMAL MODE ___________________________________________________________ 21 8.1.2. SELECTIVE SHUTDOWN MODE _____________________________________________ 21 8.1.3.
Page 5 USSI Microlok II Functional description 10.1. SYSTEM LOGS ___________________________________________________________ 22 10.1.1. SYSTEM EVENT LOG ______________________________________________________ 23 10.1.2. SYSTEM ERROR LOG______________________________________________________ 23 10.1.3. SYSTEM USER DATA LOG __________________________________________________ 23 10.1.4. SYSTEM MERGED EVENT LOG______________________________________________ 23 11.1. SYSTEM SPECIFICATION __________________________________________________ 24 UM-6800A Rev1.3...
Page 6: Introduction
This manual provides the following information about the Microlok II system. • System level application and operational descriptions • System component specifications This manual is to be referred in conjunction with the Microlok II service manual SM6800A. 2.1. SYSTEM OVERVIEW The Microlok II system operation is controlled by proprietary executive software running on the system hardware.
Page 7: System Description
CAB/ Other Non-Vital application, Maintenance and Diagnostic function 4.1. MICROLOK II HARDWARE The Microlok II system consists of modular card file-mounted equipment and external peripheral devices that are used to interface the card file circuitry to the field gears and other associated control systems. The following sections provide an overview of the hardware.
Page 8: Environmental
19.6V DC to 32.4V DC 4.1.3. CARDFILE The Microlok II card file is a G64/96 bus based card file that holds the CPU, Power Supply & Variety of I/O boards. The card file will be a user configurable.
Page 9 The CPU board contains the central controlling logic and diagnostic monitoring for the Microlok II system, and provides five serial data ports. The CPU connector housing has an internal EEPROM that is used to store site-specific configuration data.
Page 10 USSI Microlok II Functional description Fig. 2 Ref Label Device Purpose 1, 2 (None) 4-character alpha- On-site configuration programming menus numeric displays and options. A, B, C, D, E Yellow LEDs Reserved for serial link status. 1, 2, 3, 4, 5, 6, 7, 8 Red LEDs User-defined in application software.
Page 11: Power Supply Board
• Supplies energy to the VCOR relay coil under the control of the CPU board The power supply board serves a vital role in the fail-safe design of the Microlok II system. The regulated +12V and +5V power is distributed to all system card file boards through the card file back plane bus.
Page 12: Physical I/O
USSI Microlok II Functional description 5V ON VCOR POWER SUPPLY Figure - 3 Fig. 2-2 Ref Label Device Purpose 5V ON LED (green) When lit, indicates 5V-operating power on to other Cardfile PCBs (If not lit refer to Figure-2.2.1). VCOR...
Page 13 USSI Microlok II Functional description is assumed to be the maximum high voltage or minimum low voltage depending on which would cause the worse case for reliability and safety considerations. Response times for railway and transit application have historically been specified in the 100msec to 1second range.
Page 14 USSI Microlok II Functional description INPUTS OUTPUTS SWITCHED TO N12 NV.IN32 .OUT32 Figure – 4 Fig. 4 Ref Label Device Purpose Green LEDs Monitors states of non-vital inputs 1-32. When LED is lit, respective input is on. INPUTS 1-32 OUTPUTS (SWITCHED TO Yellow LEDs Monitors states of non-vital outputs 1-32.
Page 15 VCOR relay to drop, but will not cause any damage. A short to battery (+) will not cause any damage, but since this condition is equivalent to a false output, the Microlok II CPU will cause the VCOR relay to drop.
Page 16 PCB to a relay contact circuit contained in the same house of the Microlok II card file, the signal battery may be used as the energy source to activate the inputs. Terminals designated (-) may be connected to battery N24 and B24 switched over relay contacts.
Page 17 USSI Microlok II Functional description • Since the vital inputs are dealing with the detection of outdoor gears they normally configured with double cutting arrangement. IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 IN 7 IN 8...
Page 18: Vital Cut-Off Relay
This fail-safe function defaults the interlocking equipment associated with the Microlok II system to the most restrictive state. PN-150B vital biased relay is used for the VCOR. This relay consisting of low voltage silver-to-silver fronts and silver-to-silver backs contacts.
Page 19: Keying Plug
PCB is used for non-vital boards 4.1.9. KEYING PLUG Each of the Microlok II card file slots includes a 12-way female keying guide next to the 96-pin connector. The guide is used to ensure installation of the proper circuit board in each card file slot after the complete card file board configuration has been determined.
Page 20: Microlok Protocol
USSI Microlok II Functional description • The system will support the functions of both the master and slave of the Microlok Vital protocol. • The system will support the functions of both the master and slave of the Genisys Non-Vital protocol.
Page 21: Genisys Protocol
6.1. MICROLOK II SOFTWARE The primary Microlok II software components are the executive software, which is actually the Microlok II operating system software, as well as the application specific user-written software. Also included in the Microlok II software architecture is self-checking diagnostics designed to support fail- safe operational requirements.
Page 22: Application Software
Executive software that is continuously executed and controlled from the CPU board in order to detect and act upon various fault conditions. Microlok II uses diversity and self-checking concepts in which critical operations are performed in diverse ways using diverse software operations, and hardware is tested with self- checking operations.
Page 23: System Operating Modes
Critical Errors in the Microlok II system may be caused by persistent or transient faults. After a Critical Error has occurred, the Microlok II will be reset and will perform complete system diagnostics.
Page 24: Reset Menu Mode
Developer. 9.1. LOGIC PROCESSING The Boolean logic processing within Microlok II will also be of the same type of relay emulation as the Microlok and Genisys logic processors. In addition to the basic Boolean logic, the system will include table processing and block processing.
Page 25 USSI Microlok II Functional description 10.1.1. SYSTEM EVENT LOG • The system event log records up to 5000 of the most recent critical errors, warnings, and events. When the log has reached its maximum limit, the newest errors will overwrite the oldest errors.
Page 26 USSI Microlok II Functional description 11.1. SYSTEM SPECIFICATION ENVIRONMENTAL Operating Temperature Range System Cardfile Vibration Humidity Limit (All Units) 1.0grms, 0.2" displacement, -40° C to +70° C 95% non-condensing 5-1000 Hz SYSTEM CARDFILE HARDWARE CONFIGURATION Total Remote Upper PCB Cardfile...
Page 27 USSI Microlok II Functional description Power Characteristics Non-Vital I/O Printed Circuit Boards Input and Externally Externally US&S Current Rating On Output Voltage Available Available Part No. Outputs Range Inputs Outputs N17061501 6.0 to 30.0V DC Outputs 1-30: 0.25A (polyswitch- protected) Outputs 31, 32: 5.0A fuse*...
Page 28 USSI Microlok II Functional description NOTES Page 26 of 27 July 2005 UM-6800A Rev1.3...
Page 29 USSI Microlok II Functional description UM-6800A Rev1.3 July 2005 Page 27 of 27...
