Smart Thermostat Receiver
RCR114.1
A6V11562464_en--_a
2019-09-19
Smart Thermostat Receiver works with RDS110.R.
●
Mains-powered receiver AC 230 V
●
Configurable via DIP switch
●
Communicate with RDS110.R via Thread network
●
Online firmware upgrade via Thread network
Smart Infrastructure
Advertisement
Related Manuals for Siemens RCR114.1
Summary of Contents for Siemens RCR114.1
- Page 1 Smart Thermostat Receiver RCR114.1 Smart Thermostat Receiver works with RDS110.R. ● Mains-powered receiver AC 230 V ● Configurable via DIP switch ● Communicate with RDS110.R via Thread network ● Online firmware upgrade via Thread network A6V11562464_en--_a Smart Infrastructure 2019-09-19...
- Page 2 The RCR114.1 works as a router-eligible end device (REED) in the network created by RDS110.R. Functions RCR114.1 can be configured via the DIP switch on its backside to be a relay box or wireless repeater. Relay box RCR114.1 is installed within the network coverage of RDS110.R.
- Page 3 If RCR114.1 is installed too far away from RDS110.R, another RCR114.1 (works as a wireless repeater) should be added in between to extend the network coverage. See Mounting [➙ 4] for details. Note: 1. DIP switch 2 is reserved for internal use only.
- Page 4 CE declaration A6V11849464 Product environmental declaration A6V11806767 Related documents such as environmental declarations, CE declarations, etc., can be downloaded at: http://siemens.com/bt/download. Notes Security CAUTION National safety regulations Failure to comply with national safety regulations may result in personal injury and property damage.
- Page 5 Manual network reconnection 1. Check whether RDS110.R is powered on and in normal operation. 2. If the reconnection still fails, delete RCR114.1 in the device list of RDS110.R, then long press button on RCR114.1 for 8 seconds and re-add RCR114.1 to the device list.
-
Page 6: Operation
Comply with all local and currently applicable laws and regulations. Warranty Technical data on specific applications are valid only together with Siemens products listed under Equipment combinations. Siemens rejects any and all warranties in the event that third-party products are used. - Page 7 Technical data Power supply Operating voltage AC 230 V (+10/-15%) Frequency 48…63 Hz Power consumption 5 VA Radio parameters Frequency band 2.4…2.4835 GHz Maximum radio-frequency power 15 dBm Thread standard IEEE 802.15.4 Thread channel 11-26 Switching capacity of relays Voltage AC 24…230 V Current Q11- Q12 Max.
- Page 8 A6V11806767 contains data on environmentally compatible product design and assessments (RoHS compliance, materials composition, packaging, environmental benefit, disposal). *) The documents can be downloaded from http://siemens.com/bt/download. General Receiver with package, user document and accessory 262 g Receiver 174 g Housing: RAL9003...
- Page 9 Example 1: Loads = AC 230 V Example 2: Loads Y1, Y2 ≠ AC 230 V HVAC equipment DHW / Dehumidifier / Humidifier Relay Application examples Applications Gas boiler Electric boiler Floor heating with valve Radiator with pump Smart Infrastructure A6V11562464_en--_a 2019-09-19...
- Page 10 Applications Floor heating with pump Electric radiator Electric floor heating Fan with electric heating Domestic hot water boiler RDS110.R RCR114.1 F1, F2 Limit thermostats Heat generator (e.g. boiler) Magnetic valve Domestic hot water boiler Valve Circulating pump Smart Infrastructure A6V11562464_en--_a...
- Page 11 Dimensions Smart Infrastructure A6V11562464_en--_a 2019-09-19...
- Page 12 Issued by © Siemens Switzerland Ltd, 2019 Siemens Switzerland Ltd Technical specifications and availability subject to change without notice. Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug Tel. +41 58 724 2424 www.siemens.com/buildingtechnologies Smart Infrastructure A6V11562464_en--_a 2019-09-19 Document ID A6V11562464_en--_a...
