Ultra Violet Advanced Air Treatment System
EXTENDED SURFACE AREA
WITH CATALYTIC REACTIONS
FOR ADVANCED PLASMA
OXIDIZERS
• Helps Kill, Oxidize & Sterilize
• Dual UV Oxidizing lamp
• 9" & 16" Models
• Whole Home Purification
• Programmable LCD for Contact details
Power supply can cause electrical shock. Be
sure the UV power supply is disconnected
before installa�on begins.
Do not open the ballast unit as it is designated
to be installed as one piece. There are no
service components inside.
UV light may affect plas�cs in the hea�ng and
cooling system. Select a loca�on that reduces
lamp exposure to plas�c components that are
not UV resistant.
Do not touch glass without gloves. Keep lamp
surface clean.
Specifications
Dimensions:
Dimensions:
6 ½" x 6 ½" x 9" & 16"
6 ½" x 6 ½" x
24 to 120 VAC *
Electrical:
Electrical:
Weight:
Weight:
Less than 4 lbs.
Less than 4 lbs.
Humidity:
Humidity:
Water - resistant lamp
Water - resistant lamp
Lamp Life
Lamp Life
9000 hours
9000 hours
Power
Power
Requir d 24V A
Required 24V A :
e
*24Volt up to 18 watts
*120Volt for 36 watt models
1-866-876-8044 • 416-615-0214 • www.respicaire.com
OXY 4 Air Sterilizer
TM
40 VA Transformer
40
• UVC "Smart Light" monitor
• Multi Voltage - Auto Sensing Ballast
• High Temp "Attic" model - 220Fº (104Cº)
• Tandem Feature for Multiple Units
• Large Surface area for Active Oxidation
Lamps contain small amounts of mercury. If
lamp breakage occurs, clean area and dispose
with care.
To
minimize the risk of UV exposure to skin and
eyes, only power the lamp when the
installa�on is complete. Lamp illumina�on is
confirmed by the UV safety port window.
Disconnect power before all lamp change-outs
or
servicing.
recommend completely disconnec�ng all
power from electrical power supply.
Replacement Lamps
Model: 6RDP4X(L)O10W7L
Model: 6RDP4X(L)O18W9L
Model: 6RDP4X(L)O36W16L
Model: 6RDP4X(L)O10W7L
Model: 6RDP4X(L)O18W9L
Model: 6RDP4X(L)O36W16L
USB PROGRAMMING PORT
LED "SMART LIGHT" MONITOR
PROGRAMMABLE LCD OPTION
There are several disconnects. We
REPLACEMENT LAMP: 6RBUVO10W7L
REPLACEMENT LAMP: 6RBUVO18W9L
REPLACEMENT LAMP: 6RBUVO36W16L
REPLACEMENT PCO TRAY Oxy 4: 6RS4X9L
REPLACEMENT PCO TRAY Oxy 4: 6RS4X9L
REPLACEMENT PCO TRAY Oxy 4: 6RS4X16L
6RDOXY-inst1
Advertisement
Summary of Contents for RESPICARE OXY 4 6RDP4XLO10W7L
- Page 1 OXY 4 Air Sterilizer Ultra Violet Advanced Air Treatment System EXTENDED SURFACE AREA WITH CATALYTIC REACTIONS FOR ADVANCED PLASMA OXIDIZERS USB PROGRAMMING PORT LED “SMART LIGHT” MONITOR PROGRAMMABLE LCD OPTION • Helps Kill, Oxidize & Sterilize • UVC “Smart Light” monitor •...
- Page 2 Step 1 Step 2 Cut access hole in duct. (Figure 2) Use rubber template for installation location. Peel off backing and mount. (Figure 1) Figure 1 Figure 2 Step 3 Mount base plate to duct as shown - 4 screws. (Figure 3) Figure 3 Upper Locking Tab...
-
Page 3: Electrical Connection
ELECTRICAL CONNECTION LED UVC Light Monitor NOTE: CONSTANT POWER IS RECOMMENDED Step 5a) – For 120 Volt - Install power cord in unit & connect to 120 volt Power. Check that the blue UVC LED light monitor on the front of the unit is illuminated. This indicates that the internal UVC lamp is operating properly. - Page 4 Programming P3 - Character screen For LCD versions only The editing icon appears as a solid black box on the screen. (Figure P2) P1 - The LCD There are 3 rotating screens: 1. Respicaire logo 2. Number of days remaining before service 3.
-
Page 5: Warranty Information
P4 - Editing text P6 - Reset notification timer When you land on the character you need, depress the Depress the center button and left button together center button on the “joystick” once and it will load that for 5 seconds to reset the notification timer character into memory.
