Summary of Contents for Syris SY110SA
- Page 1 S Y R I S S Y 1 1 0 S A O p e r a t i n g M a n u a l V e r : 1 . 6 0 Apr.15.2006...
-
Page 2: Table Of Contents
SY110SA SINGLE DOOR CONTROLLER Table of content TABLE OF CONTENT..........................2 INTRODUCTION ..........................- 1 - Ⅰ. DO DEFAULT CONTRAST TABLE....................- 1 - Ⅱ. DI DEFAULT CONTRAST TABLE ....................- 1 - Ⅲ. OPERATION ............................- 1 - 0) LOGIN THE CONTROLLER......................- 1 - 1) ADD CARD (T ) ........ -
Page 3: Introduction
Introduction This document including the sequence of setup SY110SA functions. The input sequence is from left to right, please select the function and enter by the listed input order. Ⅰ. DO Default Contrast Table Notation Controller inner output point DO #1 Ⅱ. -
Page 4: Delete Card (This Function Requires To Login The Controller First)
SY110SA SINGLE DOOR CONTROLLER 2) DELETE CARD (This function requires to login the controller first) 2-1 Delete one card: please enter the new user ID (no need to present card) “DEL” + user ID + “EN” 2-2 Delete one card: enter the card serial number which wants to delete and no need to present card “DEL”... -
Page 5: Ⅳ. Simple Wiring Diagram
SY110SA SINGLE DOOR CONTROLLER Ⅳ. Simple Wiring Diagram Door Sensor Relay Force Alarm Beeper Violet DI2 Open Door Blue Orange SO Push Button Green SI Brown D1 White D0 Black GND Violet NO E.M. Blue COM Green NC Lock Normal Close ( NC ) -
Page 6: Ⅴ Advanced Function Setup Table
“FUN” + 40 + “ ” + N +“EN” N = 1~3, N = 1 means regular EM Card＊, when N = 2 means using SYRIS card, N = 3 means using Two Page Card. Card Data Bytes format “FUN” + 41 + “... -
Page 7: Ⅵ Do Complete Function Contrast Table
SY110SA SINGLE DOOR CONTROLLER Ⅵ DO Complete Function Contrast Table Notation DO #1 Controller inner contract DO# 2 External module DO contact Ⅶ DI Complete Function Contrast Table Notation DI #1 Controller inner contact DI #2 Controller inner contact DI #3 (Bell key) or (Call Key) -
Page 8: Ⅹ. Advanced Wiring Diagram
SY110SA SINGLE DOOR CONTROLLER Ⅹ. Advanced Wiring Diagram SY110 Wiring Diagram Relay Beeper Door Sensor Force Alarm Violet DI2 Open Door Blue Orange SO Push Button Green SI Brown D1 White D0 Black DO Orange Green +8 ~ 15V Red...
