LinTronic TT455-RT-238 Quick Manual

Hide thumbs Also See for TT455-RT-238:

Advertisement

Quick Links

Download this manual
Get started
LinTronic
TT455-RT-238
Quick guide
Updated 210414 (yymmdd)
https//lintronic.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TT455-RT-238 and is the answer not in the manual?

Questions and answers

Related Manuals for LinTronic TT455-RT-238

Summary of Contents for LinTronic TT455-RT-238

  • Page 1 Get started LinTronic TT455-RT-238 Quick guide Updated 210414 (yymmdd) https//lintronic.

  • Page 2: In This Guide

    In this guide: Step 1 - Getting started Step 2 - CommandList Step 3 - Memory Map Step 4 - MyScore Step 5 - MyFeedback Step 6 - Dealers projects Step 7 - RadioFrequency https//lintronic.

  • Page 3: Step 1 - Getting Started

    This is a Quick Guide to get you started. When you have studied this Quick Guide - we recommend you read it all - then use the Configurators HELP button to find the manual for the CommandList and Memory Map https//lintronic.
  • Page 4 Get started HELP / GET STARTED - QuickGudes NEWS / DOCUMENTATION - manuals, videos FIRMWARE UPDATES - checks for updates of your products BOOTLOADER - updates your product DATASAMPLER - Comport monitor/control NOTEPAD https//lintronic.
  • Page 5 FIRST 1. Read this entire document, so you understand the relation between “CommandList and Memory Map” as well as “Triggers and Actions” We offer separate PDF file for: http://lintronic.dk/TriggersAndActions.pdf 2. Download and install latest Configurator: http://lintronic.dk/download.aspx 3. You tube: https://www.youtube.com/channel/UCqJ3HTufgmRUfZ6kIcGpNgA...
  • Page 6 STEP 1 - COMMANDLIST / ACTIONS Before you start configuring your TT455-RT-238 to carry out what you want it to do, you need to get hold of the commands (Actions) to be carried out by the TT455-RT-238. These commands (Actions) are collected and tested in the CommandList, so you know that the products you carry on to the memory Map actually work.
  • Page 7 DOWNLOAD/INSTALL Download / install the Configurator Visit - http://lintronic.dk | Support | Download http://lintronic.dk/download.aspx https//lintronic.
  • Page 8 DOWNLOAD/INSTALL From your online Customer profile: Enter the license related Email and Password. Then generate your LicenseKey. Please note: If you later change your email address, then do not forget to edit it in the customer profile. https//lintronic.
  • Page 9 CONNECT Get started ComCab-003 Insert the ComCab-003 into the computer. Windows should automatically detect. ComCab-001 If your computer holds an RS232 comport, then you can connect the TT455-RT-238 to the Female Male computers comport using the ComCab-001. https//lintronic.
  • Page 10 CONNECT Get started OPEN THE COMPORT ASSIGNED TO YOUR (USB) CABLE Do not change default settings. = default Click USB button in order to find USB port https//lintronic.
  • Page 11 12 volt. The -238 is protected against wrong polarity. 2.1 mm Front LED should blink for 2 seconds and then turn on for ½ a second. Heart beat indicator blinks every second. This indicator is best viewed from the side. https//lintronic.
  • Page 12 - check power supply - Products blinks for 2 seconds when power is applied - If you use our USB-RS232 ComCab-002/003 cable, did you install the driver ? A driver update might be required. Still no luck ? Contact LinTronic for OnlineSupport. https//lintronic.

  • Page 13: Step 1 - Commandlist

    Mark a product as Favorite if you want to use it in a configuration project. NEVER UPLOAD COMMANDS UNLESS YOU HAVE TESTED THEM IN A MEMORY MAP PROJECT AND YOU KNOW THEY THEY WORK. OTHER USERS DEPEND ON YOUR UPLOADS. https//lintronic.
  • Page 14 Setting product to Favorite, will allow you to add it to your projects instructs your TT455-RT-238 to send the selected IR command when selected IR command is tested, this shows the command you can send from your homeautomation software...
  • Page 15 If you can use the commands from this product, but your product holds a different typenumber, then please copy the product into a new product and change the typenumber. See the complete CommandList manual for more details - and how to copy commands from your own remote control. https//lintronic.

  • Page 16: Step 3 - Memory Map

    SPECIFY MODE/TRIGGER - SELECT RELATED ACTION. THAT’S IT. START SIMPLE ! Start by controlling a CD player (play, stop, eject) or a TV (power on/off, channels, volume). When you know how this works - you can virtually do all. https//lintronic.
  • Page 17 TRIGGER: B&O Get started TT455-RT-238 If you want to use a B&O infrared remote control as trigger: You can insert the IR receiver and use the remote to set MODE and TRIGGER. See manual for the TT-IR-8087030 IR receiver: http://lintronic.dk/AppNote_TTIR8087030.pdf...
  • Page 18 Get started TT455-RT-238 If you want to use a B&O bluetooth remote control as trigger: You can connect the BT-RS232 with the TT455-RT-238 and use the remote to set MODE and TRIGGER. See manual for the BT-RS232 bluetooth receiver: http://lintronic.dk/AppNote_BeoRemoteOneBluetooth.pdf...
  • Page 19 LinTronic codes: For easy configuration, choose LinTronic (codeset 745) as trigger and operate the remote. Point the remote at the front of the TT455-RT-238 and operate the keys to set Mode and Trigger. LogiTech Smart can be recommended allowing control from your smartphone.
  • Page 20 If you want to use a NEC code based remote as trigger: For easy configuration, choose NEC (codeset 713/716) as trigger and operate the remote. Point the remote at the front of the TT455-RT-238 and operate the keys to set Mode and Trigger. https//lintronic.
  • Page 21 If you want to use a SAMSUNG code based remote as trigger: For easy configuration, choose SAMSUNG (codeset 753) as trigger and operate the remote. Point the remote at the front of the TT455-RT-238 and operate the keys to set Mode and Trigger. https//lintronic.
  • Page 22 ACTION ( Outgoing signals ) An Action is for example: - one or more InfraRed (IR) signals for your products (audio/video, light, curtains, aircon etc.) - an RS232/RS485 command for your computer, projector, lcd/plasma screen,light, etc. Select remote Select project Configuration https//lintronic.
  • Page 23 In this example we assume you use a Beo4 NAVI (recommended) to set the Mode/Trigger. 1. Point the BEO4 at the TT455-RT-238's external receiver or use the mouse to select: Mode TV - Trigger 0 2. Add Sony TV KV-F29FX20E to the project.
  • Page 24 The high-power wide-angle dual-band front IR booster, will reach most if not all products in the same room. If you place the TT455-RT-238 on top of a cabinet, then the low-power outputs can reach products inside the cabinet, by means of the low-power emitters TT-IT-ET02.
  • Page 25 - or any combination of the three. 1. Click here to enter NUMBERS mode 2. Click here to adjust ports Options are: 1 = low-power port 1 2 = low-power port 2 3 = high-power front IR H = front use 100% power https//lintronic.
  • Page 26 On comport 1 (pin 7-8) or on comport 2 (pin 2-3). You can use both RS232 ports to control your products. The TT455-RT-238 can be placed on top of a cabinet and you can connect RS232 kables to for example a TV, a projector, an amplifier, etc.
  • Page 27 You can instruct the signal to be transmitted on any of the two RS232 comports, but only on one of them. 1. Click here to enter NUMBERS mode 2. Click here to adjust ports Options are: 1 = comport 1 (pin 7-8) 2 = comport 2 (pin 2-3) https//lintronic.
  • Page 28 TT455-RT-238 on the TT455-RT-238’s comport2. When you ask the TT455-RT-238 to send out RS232 commands on comport 2, then the RS232 command is therefore send back to the computer). The configurator will show you what was received, allowing you to see the commands that will be send to the device connected on comport2, when the TT455-RT-238 is disconnected from the computer.
  • Page 29 The TT455-RT-238 holds 2 comports. You can for example trigger the TT455-RT-238 by bluetooth signals from our BTRS232 on comport1 (pin 7 and 8) and let the TT455-RT-238 communicate with or control another product on comport 2 (pin 2 and 3).
  • Page 30 Enter your comments and suggestions. Save your score. You will be asked whether you want to send your feedback to LinTronic. You can at any time read your score, change it and save again. Set 10% for worst score and 100% for best score - for each area.
  • Page 31 MyScore Get started Click the S for each area, to see how other LinTronic users scored the particular area. For example, click the S left for the Documentation label, which will show you how other users likes the documentation. We evaluate the scorings to determine how we can improve in all areas.
  • Page 32 MyScore Get started Click to see the average score, for all users for all areas: See more at: http://lintronic.dk/rating.aspx https//lintronic.
  • Page 33 MyFeedback Get started Step 5 - MyFeedback If you have contributed to our online fedback page, then you get a simplified copy in this folder. In order to help us with your feedback goto: http://lintronic.dk/feedback.aspx https//lintronic.
  • Page 34 In order to download a project as a dealer, you need to know the Project ID and the Download key. To ensure everything works as expected at customer/dealer site, downloaded projects cannot be edited. If this could be intersting for your organisation, please contact LinTronic. https//lintronic.

  • Page 35: Step 7 - Radiofrequency

    MyFeedback Get started Step 7 - RadioFrequency See special Application Note: http://lintronic.dk/appnote_RF.pdf InfraRed Booster InfraRed InfraRed LowPower RS232 InfraRed Booster Transmitter RS232 Receiver: RF InfraRed Booster RS232 Receiver: RF https//lintronic.
  • Page 36 Get started Do not forget to study the technical manual in order to get the most out of your TT455-RT-238: http://lintronic.dk/hw6.pdf It can do so much more. [end of document] https//lintronic.
