CONTENTS
DESIGN VIEW BATH SCREEN
A
Wall Profile Cover x 1
B
Top Pivot Cover x 1
C
M3.5 *25mm Screw x 4
D
E
Top Pivot Cover x 1
F
Top Pivot Kit (LH) x 1
G
H
Waterproof Strip x 1
Tools and equipment needed
Drill, 6mm Masonry drill bit, 3.2mm General drill bit, Philips screwdriver, Spirit level, Pencil, Scissors, Silicone sealant.
D
I
J
K
L
Top Pivot x 1
M
N
O
Hinge x 2
P
Waterproof Strip x 1
Waterproof Strip(LH) x 1
Bottom Pivot Cover (LH) x 1
Bottom Pivot Kit (LH) x 1
M4 *50mm Screw x 4
Wall Plug x 4
Washer x 4
Q
M4 *12mm Screw x 4
R
S
Top Pivot Kit (RH) x 1
T
Bottom Pivot Kit (RH) x 1
U
Bottom Pivot Cover (RH) x 1
V
Waterproof Strip(RH) x 1
W
Allen Key 4mm x 1
Cover x 4
