50Hz-140Hz
This setting gives satellite and small bookshelf speakers the impact
required to fill a room with deep bass. If the loudspeakers in the
system are equipped with woofers that are 4" or smaller, this is the
recommended setting. This setting will reinforce the bass response in
the 50Hz to 140Hz range.
40Hz-100Hz
This setting gives bookshelf and medium sized speakers a deep, rich
bass effect. If the loudspeakers in the system are equipped with
woofers that are 5-6", this is the recommended setting. This setting
will reinforce the bass response in the 40Hz to 100Hz range.
30Hz-80Hz
This setting is best suited for systems equipped with large, tower
speakers. If the loudspeakers in the system are equipped with woofers
that are 8" or larger, or are equipped with multiple medium sized
drivers (5-6"), than this is the recommended setting. This setting will
reinforce the bass response in the 30Hz to 80Hz range.
LFE
Many digital surround receivers are equipped with their own low
frequency crossover control to adjust the bass sent to a subwoofer. If
you choose to use the bass management integrated into your receiver
then use the LFE setting. The LFE setting, when used with the bass
control of your receiver, will provide the thunderous bass associated
with digital effects.
Phase:
The phase control will fine tune the bass performance. Have one person sit in the listening
position and a second person toggle the switch between Normal and Reverse to achieve
the desired bass output.
SW 8.3
Description:
Triple 8"Powered Subwoofer
Woofer:
8" PolyCel Driver
Dual 8"Passive Depth Drivers
Amplifier Power (Internal):
125 Watts
Frequency Response:
35Hz - 150Hz
Dimensions (HWD):
13" x 13" x 14
21000 TransCanada • Baie D'Urfé, QC, Canada, H9X 4B7
Tel.: (514) 457-2555 • Fax: (514)457-5507
WWW.SINCLAIRAUDIO.COM
© 2007 Jam Industries Ltd.
SPECIFICATIONS
SW 10.3
Triple 10"Powered Subwoofer
10" PolyCel Driver
Dual 10" Passive Depth Drivers
250 Watts
30Hz - 150Hz
1
⁄
"
15" x 15" x 16
1
⁄
"
8
8
