Kenmore C47012 Operating Instructions page 2

Cycle Selection
For best results, follow the fabric care label directions
on items to be washed.
Regular Cycle
Up to 18 minutes of reversing tumble action for most
fabrics. Three rinses, two spins, a pause and a brief
tumble complete the cycle.
• Heavy Wash provides up to 18 minutes of
reversing tumble action for heavily soiled fabrics.
• Normal provides up to 13 minutes of reversing
tumble action for normally soiled fabrics.
• Light Wash provides up to 6 minutes of reversing
tumble action for lightly soiled fabrics.
Knits/Delicates Cycle
Up to 11 minutes of gentle tumble action for the gentle
care of knit, delicate and hand washable items. Two
rinses and two spins complete the cycle.
Controls
Always follow instructions on fabric care labels.
Note: There is no need to select a water level
because the washer automatically adjusts the
water level to the type and size of wash load.
TEMPERATURES - This determines water temperatures
for washing and rinsing. For example, the Warm/Cold
setting provides a warm water wash and a cold water
final rinse.
Note: Detergents are not as effective at wash water
temperatures below 65°F (18.3°C).
CYCLE SIGNAL - A signal will sound at the end of the
cycle when the Cycle Signal is set to YES. This can be
turned off by selecting NO on the Cycle Signal switch.
The following chart suggests wash/rinse temperatures
for basic fabric types.
Fabric Type
Heavily soiled white/colorfast
cotton, perm press
Normally soiled white/colorfast Warm/Cold
cotton, perm press
Lightly soiled/noncolorfast
fabrics, knits, delicates,
hand washables
Washable woolens
EXTRA RINSE - Use Extra Rinse when additional
rinsing is desired to remove excess dirt and detergent
from heavily soiled loads.
• Select Extra Rinse ON to automatically
include an extra rinse in Regular or Perm Press
cycle.
• Select Extra Rinse OFF to conserve water
when an extra rinse is not desired.
P/N 134854900A (0801)
Wash/Rinse
Temperature
Hot/Cold
Cold/Cold
Warm/Warm
