Drolo Stretch Weaver Manual

Left channel Right channel
Out In Out
L
wet dry dry
left ctrl right
tape
STRETCH
repeat pitch
weave glide
WEAVER
stretch gate
ringmod
In
R
wet
mix L+R
sep L/R
DC Power
Supply
TRS
Expression
Input
bypass switch
The Stretch Weaver has 2 separate channels that can interact with each
other in various ways, mostly through sidechaining where a channel can
trigger an action that will be applied to the other channel.
When you plug in only one source on the right channel, it will internally
be routed to the left channel, so that you can use most of the modes in
interesting ways even if only one input is being used.
wet/dry:
Controls the level of the wet and dry signals for each channel indivi-
dually. Unity gain is around noon position.
left/right:
Adjusts the threshold at which the respective channel will trigger the
effect applied to the other channel. (except in weave mode, where right
adjusts grain length).
control knob
Its function will depend on the selected mode.
mix L+R ; sep L/R:
in the sep position, each channel is separate.
in mix mode, both of the wet signals are mixed together and routed
equally to both L and R outputs.
bypass switch:
If you give it a short tap (<0.3sec) it acts in latching mode.
If you press it for more than 0.3sec you are in momentary mode.
It's a buffered bypass.
