Installing The Projector In A Mount Or Tripod - Epson EF12 User Manual

4:3 Aspect Ratio Image or Screen
Screen or image size
50 inches
60 inches
70 inches
80 inches
90 inches
100 inches
120 inches
Parent topic:

Installing the Projector in a Mount or Tripod

When installing the projector in an optional mount, follow these guidelines:
Note: You will require the optional mounting plate (ELPMB65) to install the projector in a mount.
• You can install the projector on VESA-compliant (75 × 75 mm) mounting hardware.
• You can install the projector on a tripod that uses 1/4-20UNC size fixed screws
• When installing the projector in a high place, be sure to install the optional security wire set
(ELPWR01) for safety purposes
1. Turn the projector upside down.
Projection distance (1)
Wide to Tele
54 inches
(136 cm)
64 inches
(164 cm)
75 inches
(192 cm)
86 inches
(220 cm)
97 inches
(247 cm)
108 inches
(2275 cm)
130 inches
(331 cm)
Projector Placement
Distance from center of lens to
base of screen (2)
0 inches (0 cm)
0 inches (0 cm)
0 inches (0 cm)
0 inches (0 cm)
0 inches (0 cm)
0 inches (0 cm)
0 inches (0 cm)
25
