DVD PLAYER
SD7200KU
SDK990KU
OWNER'S MANUAL
© 2009 Toshiba Corporation
DIGITAL VIDEO
The model number and serial number are on the back of
your DVD Player. Record these numbers in the spaces
below. Refer to these numbers whenever you communicate
with your Toshiba dealer about this DVD Player.
Model number:
Serial number:
Introduction
2
Connections
11
Basic playback
16
Advanced playback
19
Function setup
29
Others
35
Advertisement
Table of Contents
Related Manuals for Toshiba SD7200KU
Summary of Contents for Toshiba SD7200KU
-
Page 1: Dvd Player
The model number and serial number are on the back of your DVD Player. Record these numbers in the spaces below. Refer to these numbers whenever you communicate with your Toshiba dealer about this DVD Player. Model number: Serial number:... -
Page 2: Introduction
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. WARNING: Changes or modifications to this unit not expressly approved by Toshiba, or parties authorized by Toshiba, could void the user authority to operate the equipment. Warnings: •... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 4: Precautions
Introduction Precautions Notes on handling When shipping the DVD player, the original shipping carton and packing materials come in handy. For maximum protection, repack the unit as it was originally packed at the factory. Take care not to give it a shock or shake when carrying. -
Page 5: Notes On Discs
Notes on Discs On handling discs Do not touch the playback side of the disc. Playback side Do not attach paper or tape to discs. On cleaning discs Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the center outwards with a soft cloth. -
Page 6: Notes On Region Numbers
Because of problems and errors that can occur during the creation of DVD and CD software and/or the manufacture of DVD and CD discs, Toshiba cannot assure that this DVD player will successfully play every disc bearing the DVD and CD logos. -
Page 7: Table Of Contents
Table of Contents Introduction SAFETY PRECAUTIONS ... 2 IMPORTANT SAFETY INSTRUCTIONS ... 3 Precautions ... 4 Notes on Discs ... 5 Notes on region numbers ... 6 Table of Contents ... 7 Identification of Controls ... 8 Front panel ... 8 Rear panel ... -
Page 8: Identification Of Controls
Introduction Identification of Controls See the page in for details. Front panel Rear panel Power Cord HDMI OUT jack DVD display The indicators vary depending on the kinds of discs you play. Bad disc No disc Bad disc DVD VIDEO VIDEO CD •... -
Page 9: Remote Control
Remote control The instructions in this manual describe the functions on the remote control. See the page in * RETURN button Return to menu display for VCD (2.0) discs with menu. for details. HDMI button * MENU button Use the MENU button to display the menu included on many DVDs. -
Page 10: Loading Batteries
Introduction Identification of Controls (continued) Loading batteries Open the cover. Insert batteries (R03/AAA size). Make sure to match the + and – on the batteries to the marks inside the battery compartment. Caution Never throw batteries into a fire. Notes •... -
Page 11: Connections
Connections Connecting to a TV Connect the DVD player to your TV. Connecting to a TV Normal TV T o audio T o video input input (yellow) Audio/Video cables (supplied) Notes • Refer to the owner’s manual of the connected TV as well. •... -
Page 12: Connecting To A Display
• Analog audio out will not have sound if DTS playback is selected. • ColorStream ® and ColorStream Pro ® are registered trademarks of Toshiba America Cousumer Products L.L.C. Connecting to a display (Using a HDMI T o HDMI Output Available output signals are below: •... -
Page 13: Connecting To Optional Equipment
Connections Content of the output for each output jack is shown in the following table and differ depending on the On-Screen Display Setting: On-Screen Display Setting Content of output for each output jack "Video Out" HDMI Output HDMI Video Setting Setting * Output Output... -
Page 14: Connecting To An Amplifier Equipped With A Dolby
Connections Connecting to Optional Equipment (Continued) Connecting to an amplifier equipped with a Dolby Dolby Digital Dolby Digital is the surround sound technology used in theaters showing the latest movies, and is now available to reproduce this realistic effect in the home. You can enjoy motion picture and live concert DVDs with this dynamic realistic sound by connecting the DVD player to a 6 channel amplifier equipped with a Dolby Digital decoder or Dolby Digital processor. -
Page 15: Dts Decoder
Connections Connecting to an amplifier equipped with a DTS Digital Theater Systems (DTS) DTS is a high quality surround technology used in theaters and now available for home use, on DVDs or audio CDs. If you have a DTS decoder or processor, you can obtain the full benefit of 5.1 channel DTS encoded sound tracks on DVDs or audio CDs. -
Page 16: Basic Playback
Basic playback Playing a Disc This section shows you the basics on how to play a disc. Basic playback Preparations • When you want to view a disc, turn on the TV and select the video input connected to the DVD player. •... -
Page 17: Variable Speed Playback
Variable Speed Playback You can play discs at various speeds, and resume playback from the location where you stopped playback. Playing in fast reverse or fast forward directions Press REV or FWD during playback. REV: Fast reverse playback FWD: Fast forward playback Each time you press the REV or FWD button, the playback speed changes. -
Page 18: Locating A Desired Section
Basic playback To start playback from the beginning regardless of the location where you stopped playback. 1 Press STOP twice. The DVD player deletes the memory of the location. 2 Press PLAY. Playback starts from the beginning of the current title. Playback starts from the beginning of the disc. -
Page 19: Advanced Playback
Advanced playback Accessing a Specific Location Directly Locating a specific title/chapter/time Press T. Press to select the Title/Chapter/ Track/Time. e.g. SEARCH 00 : 00 : 00 Track Time 00 : 00 : 00 Disc Time Press to select a section you want to locate. -
Page 20: Repeating A Specific Segment
Advanced playback Repeating a Specific Segment You can specify a desired segment and repeat it. Repeating a specific segment Press A-B RPT at the beginning of the segment (point A) you want to play repeatedly. A-B RPT Rep A- Press A-B RPT again at the end of the segment (point B). -
Page 21: Playing In A Favorite Order
Playing in a Favorite Order You can combine your favorite titles, chapters or tracks and play them in the order you determine. You can program up to 12 selections into the memory (Memory playback). Setting titles, chapters or tracks in a favorite order Insert a disc and press MEMORY during stop. -
Page 22: Zooming A Picture
Advanced playback Zooming a Picture You can magnify areas within a picture. Zooming a picture Press ZOOM during normal, slow or still playback. The centre part of the image will be ZOOM zoomed in. e.g. Each time you press the ZOOM button, the magnification level changes as follows: Press the ZOOM button to select the magnification level. -
Page 23: Selecting The Picture Enhancement (E
Selecting the Picture Enhancement (E.P.M.*) You can easily select a preferred picture enhancement. *E.P.M.: Enhanced Picture Mode Selecting the picture enhancement Press E.P.M. E.P.M The picture enhancement menu appears. Contrast Select the picture enhancement by pressing / , then press your selections. -
Page 24: Selecting The Camera Angle
Advanced playback Selecting the Camera Angle If the scene was recorded from multiple angles, you can easily change the camera angle of the scene you are watching. Changing the camera angle Press ANGLE while playing a scene recorded with multiple angles. ANGLE While playing a scene recorded with multiple angles, press the ANGLE... -
Page 25: On-Screen Display Operation
On-screen Display Operation When you turn on the on-screen display, you can view information on operational status and access features and settings. On-screen display operation Press NAVI. NAVI The following display appears. e.g. When playing a DVD. Chapter number 00:30:34/01:00:52 1/1 5/12 Elapsed time Remaining time Title number... -
Page 26: Playing Mp3/Wma Files
Please be advised that you must obtain permission from the applicable copyright owners to download copyrighted content, including music files, in any format, including the MP3 formats, prior to the downloading thereof. Toshiba has no right to grant and does not grant permission to download any copyrighted content. “... -
Page 27: Viewing Jpeg Files
Viewing JPEG Files You can play JPEG files that have been recorded on a CD-R or CD-RW on the DVD player. You can select a preferred view: a page of 9 thumbnail images or a single image view. Also, rotating, enlarging and shifting of each image can be possible. To playback in HD JPEG resolution, see Viewing JPEG files Preparations... -
Page 28: Playing Divx /Mpeg-4 Files
Advanced playback JPEG files compatibility Discs whose compatibility with this DVD player has been confirmed by TOSHIBA are as follows. CANON QuickCD FUJICOLOR CD Kodak Picture CD NORITSU QSS CD JPEG disc compatibility with this DVD player is limited as follows: •... -
Page 29: Customizing The Function Settings
Customizing the Function Settings You can change the default settings to customize performance to your preference. Setting procedure Press SETUP during stop. The following on-screen display appears. Language : English : Off DivX subtitle : ASCII : English : English DVD Menu Press to select an option for the... -
Page 30: Divx Subtitle
Function setup Customizing the Function Settings (continued) Setting details ® DivX Subtitle If your DivX ® files include a subtitle file, then you may ® select a supported DivX subtitle language by region: ASCII Unicode Turkish Central European Cyrillic 1) Press SETUP button. 2) Press button, then use the button to select... -
Page 31: Video Out
Notes • The displayable picture size is preset on the DVD. Therefore, the playback picture of some DVDs may not conform to the picture size you select. • When you play DVDs recorded in the 4:3 picture size only, the playback picture always appears in the 4:3 picture size regardless of the TV shape setting. -
Page 32: Digital Output
Function setup Customizing the Function Settings (continued) Setting details HD JPEG Mode 1) Press SETUP button. 2) Press button to select Video. 3) Press button, then use the button to select HD JPEG Mode. 4) Press ENTER button, then use the On or Off mode. -
Page 33: Parental Control Dvd
Rating Parental Control : 8. Adult Set Password Parental Control DVDs equipped with the password function are rated according to their content. The contents allowed by a parental lock level and the way a DVD can be controlled may vary from disc to disc. - Page 34 Function setup Customizing the Function Settings (continued) Setting details DivX ® Registration Some DivX ® Video-On-Demand files required registration code, please get the code of your DVD player as follow: 1) Press SETUP button. 2) Press button to select Misc. 3) Press button, then use the button to select...
-
Page 35: Others
Others Table of Languages Table of languages and their abbreviations Abbreviation Language Abbreviation – – – No alternate language CHI (ZH) Chinese DUT (NL) Dutch ENG (EN) English FRE (FR) French GER (DE) German ITA (IT) Italian JPN (JA) Japanese KOR (KO) Korean MAY (MS) -
Page 36: Before Calling Service Personnel
Others Before Calling Service Personnel Check the following guide for the possible cause of a problem before contacting service. Symptoms and correction Symptom Cause No power. • The power plug is disconnected. The DVD player turned off by • The automatic power off function turned the itself. -
Page 37: Specifications
Others Specifications DVD player / outputs / supplied accessories DVD Player Power supply 120 V AC, 60 Hz Power consumption 8 W (standby: less than 1.0W) Mass 1.26 kg External dimensions 430 x 41 x 197 mm (W/H/D) Signal system NTSC Laser Semiconductor laser, wavelength 650/780 nm... -
Page 38: Limited Warranty
Limited United States Warranty Digital Audio Video (“DAV”) Product - Exchange Warranty Toshiba America Consumer Products, L.L.C. (“TACP”) makes the following limited warranties to original consumers in the United States. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS DAV PRODUCT AS A GIFT FROM THE ORIGINAL CONSUMER PURCHASER AND TO NO OTHER PURCHASER OR TRANSFEREE. - Page 39 Limited Canadian Warranty For Toshiba Brand Digital Audio/Video Products Toshiba of Canada Limited (“TCL”) makes the following limited warranties to original consumers in Canada. THESE LIMITED WARRANTIES EXTEND TO THE ORIGINAL CONSUMER PURCHASER OR ANY PERSON RECEIVING THIS TOSHIBA BRAND DIGITAL AUDIO/VIDEO PRODUCT (the “DAV PRODUCT(S)”...
- Page 40 ABOVE, YOUR SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT OF THE DEFECTIVE PART. IN NO EVENT WILL TCL, TOSHIBA CORPORATION, THEIR AFFILIATES, ADRs OR ASPs (THE “RELATED PARTIES”) BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DAMAGES.
