- Page 1 SC-2004-OC SC-2004FC-OC SC-2008-OC Quality Medical Products Since 1983 Instructions For Use SC-2004-OC, SC-2004FC-OC and SC-2008-OC Sequential Circulators SC-2004-OC & SC-2004FC-OC SC-2008-OC...
-
Page 2: Intended Use
INTENDED USE: The Sequential Circulators SC-2004-OC, SC-2004FC-OC /SC-2008-OC are pneumatic compres- sion devices intended for either primary or adjunctive treatment of primary or secondary lymphedema. The devices are also intended for additional or alternate treatment of venous insufficiency and chronic venous stasis ulcers associated with venous insufficiency as well as general treatment for swelling of the extremities. -
Page 3: Warnings And Precautions
To prevent the potential for reverse pressure and retrograde flow, do not adjust the gradient pressures without a physician’s supervision. INTRODUCTION Congratulations on the purchase of your Bio Compression Systems SC-2004-OC, SC-2004FC-OC or SC-2008-OC Sequential Circulator and accompanying garment(s). DEVICE DESCRIPTION AND OPERATING PRINCIPLE The SC-2004-OC, SC-2004FC-OC and SC-2008-OC Sequential Circulators provide gradient pneu- matic compression for the treatment of lymphedema and associated venous disorders. -
Page 4: Package Contents
PACKAGE CONTENTS 1 - SC-2004-OC, SC-2004FC-OC or SC-2008-OC Sequential Circulator (“pump”) 1 - Instructions for Use (IFU) 2 - Blocker Bars for use during single garment therapy 1 - Power Cord 0 - Garments (Garments provided separately) GARMENTS Caution: Do not share garments with other users. -
Page 5: Key Functions
Photo of Blocker Bars (uninstalled) Tubing Latch Connector Bars (shown on the end of Tubing) (Note: SC-2008-OC and SC-2004-OC, SC-2004FC-OC same key functions. No Auxiliary Air Supply Ports on the SC-2004-OC/SC-2004FC-PC) LATCH CONNECTORS Attach and detach the garment to the pump via the Receptor Ports (for Tubing Latch Connector Bars), depicted by #4 in the illustration above. - Page 6 OPERATING INSTRUCTIONS Unpacking Equipment 1. Open the shipping box and lift the device up and out of the box. (Maintain shipping box for future use. Equipped with a special fold-up handle for ease of use). 2. Remove the protective end caps from the sides of the device. 3.
- Page 7 Powering On the Sequential Circulator 11. Patient shall be seated in a reclined position, legs elevated within easy reach of the Sequential Circulator. 12. Press the “Power On/Off” button to turn the pump on. 13. Within several seconds, the pump shall begin producing air pressure. The air pressure may be set in the same position as the previous treatment.
-
Page 8: Maintenance And Storage
CAUTION: In case of power failure, the Sequential Circulator shall automatically power off. The pump does not have a battery backup nor timer memory. Once power is re- stored, the Sequential Circulator will need to be powered on in order to resume treat- ment. -
Page 9: Troubleshooting
An internal problem Contact Bio Compression Systems, Inc., for repair. If the corrective action does not resolve the problem, please call Bio Compression Systems, Inc., at 1-800-888-0908. Serial number is required when calling for service. -
Page 10: Warranty Information
REPAIR SERVICE INFORMATION Technical Support—please call for all service repairs. Model and Serial numbers shall be required for all service inquiries. CAUTION: Tampering with or dismantling the Sequential Circulator in any way shall void the warranty on the device. Warranty repairs or adjustments shall be performed in a timely manner with minimal inconvenience. - Page 11 4 CHAMBER GARMENT SPECIFICATIONS (for use with SC-2004-OC & SC-2004FC-OC) PRODUCT APPLICATION SIZE SIDE GS-3035-S Small GS-3035-M Medium GS-3035-L Large GS-3035-SH/S Arm & Shoulder Small GS-3035-SH/M Arm & Shoulder Medium GS-3035-SH/L Arm & Shoulder Large GA-3035-S Small Adjustable GA-3035-M Medium Adjustable...
- Page 12 8 CHAMBER GARMENT SPECIFICATIONS - (for use with SC-2008-OC) PRODUCT APPLICATION SIZE SIDE G8-3035-S Small G8-3035-M Medium G8-3035-L Large G8-3035-SH/S Arm & Shoulder Small G8-3035-SH/M Arm & Shoulder Medium G8-3035-SH/L Arm & Shoulder Large GV-3010-S-R Arm Elite Bio Vest Small Right GV-3010-S-L Arm Elite Bio Vest...
- Page 13 700hPa - 1060hPa ELECTRICAL SPECIFICATIONS/EQUIPMENT CLASSIFICATION The Sequential Circulators, SC-2004-OC, SC-2004FC-OC and SC-2008-OC, interior components are “double insulated” and do not require a “protective ground.” The devices are equipped with 18 gauge, 2-wire, 10’ Power Cords, secured through the pump casings with a Heyco strain relief brushing, as well as, an additional “hold-down”...
-
Page 14: Guidance And Manufacturer's Declaration - Electromagnetic Immunity
Guidance and Manufacturer’s Declaration — Electromagnetic Immunity The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in the electromagnetic environment specified below. The customer or the user of the SC-2004-OC/SC-2004FC-OC/ C-2008-OC should assure that it is used in such an environment. Immunity IEC 60601 test Compliance level Electromagnetic environment—guidance... -
Page 15: Recommended Separation Distances Between Portable And Mobile Rf Communications Equipment
Recommended separation distances between portable and mobile RF communications equipment and the SC-2004-OC/SC-2004FC-OC/SC-2008-OC The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer of user of the SC-2004-OC/SC-2004FC-OC/SC-2008-OC can help prevent electromagnetic interference by maintain- ing a minimum distance between portable and mobile RF communications equipment (transmitters) and the SC-2004-OC/SC-2004FC-OC/SC- 2008-OC as recommended below, according to the maximum output power of the communications equipment.
