- Page 1 NEMESIS GEFORCE2 MX200/MX400 User’s Manual Version 1.0 Notice This device has been approved by EMI for home. It can be used in all areas including residential area.
- Page 2 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC FULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction • Features of NEMESIS GEFORCE2 MX200/MX400 • System Configuration and Each Part Description Chapter 2 Installation • Installation of display drivers Windows 98 Windows ME Windows 2000 Windows NT • Installation of application programs Chapter 3 How to use programs •... -
Page 4: Chapter 1 Introduction
Chapter 1. Introduction Contents of the package Thank you for purchasing the NEMESIS GEFORCE2 MX200/MX400. Please make sure that you have a full content of the NEMESIS GEFORCE2 MX200/MX400 after removing the package. NEMESIS GEFORCE2 MX200/MX400 Board It is equipped in AGP slot of system main board. -
Page 5: Features Of Nemesis Geforce2 Mx200/Mx400
Features of NEMESIS GEFORCE2 MX200/MX400 * Powered by nVIDIA’s GeForce 2 MX 200 / MX 400 * Two new Hypertexel pipelines * Up to 20million triangles per second at peak rates * Full scene anti-aliasing and Per-Pixel Shading * Maximum resolution up to 2048x1536 at 75 Hz... -
Page 6: System Configuration And Each Part Description
System Configuration and Each Part Description System Configuration To use the NEMESIS GEFORCE2 MX200/MX400 effectively, you need the following configuration. CPU & Main board IBM-PC compatible main board in compliance with AGP 2.0 (More than Intel 440BX or VIA Apollo pro) - Page 7 It is called as Frame buffer or Video buffer. 32MB(or 64MB) high speed SDRAM or DDR SGRAM are provided as standard, which is the maximum amount of memory supported by the NEMESIS GEFORCE2 MX200/MX400.
-
Page 8: Chapter 2 Installation
Installation of display drivers Windows 98 SE In case of installing the NEMESIS GEFORCE2 MX 200/MX 400 with Windows 98 SE If you have installed Windows 98 newly, your system recognizes the video card as “Standard PCI Graphics Adapter [VGA]”. If it has not been set correctly, switch display to “Standard PCI Graphics Adapter [VGA]”... - Page 9 7. Select “Specify a location”. ( Do not select other items.) 8. Select “WIN9X” folder on “MX200-400” folder of CD-ROM drive by using “Browse…” button then click “Next”. 9. If it recognizes “NVIDIA GEFORCE2 MX / MX400”, click “ Next” again. (“NVIDIA GeForce2 MX200”...
- Page 10 In case of exchanging the VGA card to the NEMESIS GEFORCE2 MX 200/MX 400 in Windows 98 SE 1. When Windows 98 SE begins, the “Add new hardware wizard” dialog box will appear then click “Next”. 2. Select “Search for the best driver for your device. [Recommended]” and click “Next”.
- Page 11 5. The appropriate drivers will be copied and the system will be configured automatically. 6. Click “Finish”. 7. If a dialog box appears asking if you want to restart your system, select “Yes”.
-
Page 12: Windows Me
Windows ME In case of installing Windows ME in your system that has the NEMESIS GEFORCE2 MX200/MX400. When you install Windows ME in condition that the NEMESIS GEFORCE2 MX200/MX400 has been installed, Adapter type is set to “Standard PCI Graphics Adapter[VGA]”. You can find Video controller (VGA compatible) in “Other device”... - Page 13 7. Select “WINME” folder on “MX200-400” folder of CD-ROM drive by using “Browse” button then click “OK”. 8. When it turns back to the “Update Device Driver Wizard”, then click “Next”. 9. “NVIDIA GeForce2 MX / MX400 (vX.XX)” in “Update Device Driver Wizard” is displayed, then click “Next”.
- Page 14 In case of exchanging the VGA card to the NEMESIS GEFORCE2 MX200/MX400 When you remove the existing VGA card from your system and newly install the NEMESIS GEFORCE2 MX200/MX400 then “New hardware found” dialog box appears and “add new hardware wizard” is started automatically.
- Page 15 then click “Next”. 5. Select “The updated software [Recommended]”. Click “Next”. The appropriate drivers will be copied and the system will be configured automatically. A message that the driver has been installed successfully appears. Then click “Finish”. It will prompt you to restart your computer, click “Yes” to restart your computer to complete the installation.
-
Page 16: Windows 2000
Windows 2000 In case of installing Windows 2000 in your system that has the NEMESIS GEFORCE2 MX200/MX400. When you install Windows 2000 in condition that the NEMESIS GEFORCE2 MX200/MX400 has been installed, Adapter type is set to “VGA”. You can find Video controller (VGA compatible) in “Other device”... - Page 17 Select “Search for the best driver for your device (recommended)” and click “Next”. Select “Specify location”, click “Next” and “Browse”. Select “\MX200-400\WIN2000” folder on the Installation CD when the browse dialog box appears and click “Open”. When you click “O.K”, the location of the INF file appears. Click “Next”. If the driver has not been certified by WHQL, “Can not find the digital signature”...
- Page 18 In case of exchanging the VGA card to the NEMESIS GEFORCE2 MX200/MX400 in Windows 2000. When you remove the existing VGA card from your system and newly install the NEMESIS GEFORCE2 MX200/MX400 “New hardware found” dialog box appears and “add new hardware wizard”...
- Page 19 Select “WIN2000” folder on “\MX200-400” folder of CD-ROM drive by using “Browse” button. Click “Next”. 6. If the driver has not been certified by WHQL, “Can not find the digital signature” dialog box appears. Click “Yes” to proceed. 7. A message that the driver has been installed successfully appears. Then click “Finish”. It will prompt you to restart your computer, click “Yes”...
-
Page 20: Windows Nt
Windows NT4.0 Note To install the NEMESIS GEFORCE2 MX200/MX400 in Windows NT 4.0, you should have Service pack 3 or higher. Start Windows NT4.0. Insert the installation CD into your CD-ROM Drive. Click the right mouse button on the Windows screen and select “properties” on the dialog box. -
Page 21: Installation Of Application Programs
Installation of application programs Installation of application programs for NEMESIS GEFORCE2 MX200/MX400 Insert the installation CD into your CD-ROM Drive. Open “My Computer” in Windows 98 and select your CD-ROM Drive. Run “SETUP.EXE” in the “UTILITY” folder. The instruction screen appears. Then click “Next” to proceed. -
Page 22: Chapter 3 How To Use Programs
Chapter 3 How to use Utility programs Using the NEMESIS GEFORCE2 MX200/MX400’s utilities This is a utility program that sets display properties and 3D functions provided by the NEMESIS GeForce2 MX 200/MX 400. When selecting “GeForce 2 MX” tab right after clicking “Advanced” in “Settings” of the “Display properties”, the following dialog box that shows hardware information, driver version and... - Page 23 Color management This is a utility to adjust a color (Gamma value) and contrast value. Shows the screen condition that is controlled by the below bars. Sets a color to control among Red, Blue, Green and all three colors. Controls the brightness. Controls the contrast.
- Page 24 DirectX 3D settings This is to specify each detailed item for 3D acceleration. MIPMAP detail level (best quality best speed) adjusts 5 levels of MIPMAP. Saves the configuration. Restores to the default value. Sets Texel arrangement and PCI texture memory size.
- Page 25 Open GL settings This is to set the buffer and video memory for OpenGL.
- Page 26 Overlay color control This is to control the overlay color when watching TV or VCD.
- Page 27 Other options This sets the display drivers and icon images for display tabs.
-
Page 28: Watching Video Cd
Watching Video CD Note Make sure that you have installed a sound card in your system before you run SIGMA utilities such as SIGMA VCD player and SIGMA MP3 player. When running a utility program, it automatically searches the sound card in your system. If your sound card driver has not been installed correctly, the utility will deny to work. - Page 29 Menu screen Click “Menu”[ ], the following pop-up menu appears. MPEG config Sets MPEG configuration for audio channel, volume control, screen size and DirectDraw. Subtitle change Changes the subtitle to another language. This is supported with Video CD 2.0. Screen size control Changes the screen size to the full or its original.
- Page 30 Button Functions Button Description Function Capture Captures motion prictures. Video CD Play Plays video CD or audio CD. CD-ROM Eject Ejects CD-ROM drive tray. Online Help Displays help for Sigma VCD Player. Menu Displays configuration menu to play Sigma VCD Player. File Open Opens images in file.
-
Page 31: Listening To Mp3 Audio
Listening to MP3 audio (Sigma MP3) SIGMA MP3 player is a high quality MP3 player that runs in Windows environment. You can play all kinds of MP3 files at your convenience. Repeat Repeats a MP3 file when clicking the icon. Open Opens a MP3 file or list to be played. -
Page 32: Addendum
Addendum Q & A Q1: There is an irregular beep sound when booting up the system after installation and nothing on the monitor screen. A1: Make sure that your system has been connected to the monitor with cable correctly. Also check the power cable is well connected to the monitor. - Page 33 SIGMACOM CO., LTD. SIGMACOM CO., LTD. SIGMACOM CO., LTD. SIGMACOM CO., LTD. 1588-9 Anyang Nonghyup B/D 4F Kwanyang-dong Dongan-gu Anyang city Kyunggi-do 431-060 Republic of Korea Phone +82-31-384-1010 +82-31-382-8506 http://www.sigmaM.com...
