NOTE For the Pulse Oximetry related alarms see page 122
The following alarm values are configurable:

This alarm can be adjusted from the Tidal Volume pop-up window in the Main
screen, whereas the other alarms are set from the Alarm Settings screen.




The following alarms are always operational:
A/C Power disconnect
Low Battery
Battery Empty
Over Temperature
Patient Circuit Failed
Service Notice

CHANGING INDIVIDUAL ALARM SETTINGS

Select and press Alarm Settings in the Main Menu to view the Alarm Settings
screen (Figure 133):
High and Low O2
This alarm is updated automatically when setting the FiO2 parameter and
can also be adjusted from the Alarm Settings screen
Leak %
Volume Limit Reached (for pressure controlled modes only).
Audio Alarm Volume
Inverse I:E Ratio Alarm
Tidal Volume not delivered
Patient Circuit Disconnect (Enable/ Disable – On/Off)
145
High PEEP
Low O pressure
2
Check Sensor
Sensor Disconnect
Auto Start
Need calibration
6 Alarms
