Summary of Contents for Equipter RB 4000

  • Page 1 R B 4 0 0 0 S E R V I C E M A N U A L...
  • Page 3 The information in this manual is provided to promote the safe use of, and assist the operator in achieving the best performance from Equipter products described herein, for their intended applications. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of New Heights, LLC.

  • Page 4: Table Of Contents

    Index B: Service Checklist..............................8 Index C: Service Schedule............................9-10 For more than 15 years, our team has manufactured Equipter products using top-quality processes and components. To protect your investment and ensure a long service life, it’s essential to perform regular maintenance.

  • Page 5: Recommended Service Schedule

    Recommended Service Schedule We recommend doing the first preventative maintenance at about 30 service hours. Following this service, select maintenance tasks should be performed monthly, every six months, and so forth. Please refer to Index B: Service Checklist for a comprehensive list of preventative maintenance tasks and when to complete them.

  • Page 6: Replace Air Filter

    R E P L A C E A I R F I L T E R 1. Unscrew the wing knob. 2. Remove the air filter cover. 3. Remove the wing nut. 4. Lift the old air filter away and replace with the new filter.

  • Page 7: Replace Engine Oil

    R E P L A C E E N G I N E O I L NOTE: Drain oil while the engine is still warm to ensure rapid, complete draining. 1. Undo the drain bolt using the 12mm wrench provided in this service kit. 2.

  • Page 8: Inspect Parking Brake

    I N S P E C T P A R K I N G B R A K E • Visually inspect the parking brake handle for wear. • If it’s loose, turn the handle clockwise until it’s tight. Brake Handle I N S P E C T B R E A K A W A Y S Y S T E M •...

  • Page 9: Lubricate Fittings

    L U B R I C A T E F I T T I N G S NOTE: Never work under the raised dump box without using the safety arm to prevent the box from falling down. All four stabilizers and rollback must be fully extended when greasing fittings on the RB4000.

  • Page 10: Wheel Lock Handle

    Wheel Lock Handle 1. Disengage the wheel lock pin. 2. Grease the wheel lock pin. 3. Replace the wheel lock pin. Wheel Lock Pin Front Axle Hub 1. Use a flat screwdriver to remove the rubber grease cap. 2. Insert grease into the zerk until the zerk is full.

  • Page 11: Index A: Service Providers

    I N D E X A : S E R V I C E P R O V I D E R S Manufacturer’s Recommended Service Provider Equipter, LLC 49 Eagle Drive Suite 102 Leola, PA 17540 (717) 661-3591 support@equipter.com...

  • Page 13: Index C: Service Schedule

    I N D E X C : R B 4 0 0 0 S E R V I C E S C H E D U L E Date: Service Type: Engine Hours: Notes: Date: Service Type: Engine Hours: Notes: Date: Service Type: Engine Hours:...
  • Page 14 I N D E X C : R B 4 0 0 0 S E R V I C E S C H E D U L E Date: Service Type: Engine Hours: Notes: Date: Service Type: Engine Hours: Notes: Date: Service Type: Engine Hours:...
  • Page 16 ©️2019 New Heights, LLC. All rights reserved. No part of this manual may be reproduced, in any form, without prior, express, written authorization of New Heights, LLC.
