Summary of Contents for Connex CX22A19DC
- Page 1 FHD LED TV Model：CX22A19DC Instruction Manual...
-
Page 2: Table Of Contents
Contents Important Safety Instructions ............... . About Your TV . -
Page 3: Important Safety Instructions
Important Safety Instructions... - Page 4 Important Safety Instructions gently...
-
Page 5: About Your Tv
About Your TV Specifications Includes • Model: CX22A19DC • Remote control and 2 AAA batteries • Screen Size: 22” • Base stand • Panel Resolution: 1920*1080 • I nstruction Manual • Viewing Angle: 176(H)*176(V) • 12V DC harness. • Aspect Ratio: 16:9 •... -
Page 6: Mounting The Tv On A Wall
Mounting the TV on a wall If you mount this TV on the wall, follow the instructions exactly as set out by the manufacturer. Incomplete or improper installation may cause injury to you, and/or damage to the LED TV. When you have appropriate wall mount brackets, please install them by using the VESA screws included in TV PE bag. -
Page 7: Orientation
Orientation TV Controls INPUT Press to select the input source MENU Press to enter the main menu VOL+ Press to increase the volume VOL- Press to decrease the volume Press to skip to the next channel Press to skip to the previous channel... - Page 8 Orientation Inputs DC 12V IN: Power (DC 12V or plugpack) input. USB: USB Port for media playback when Media is the TV’s selected source. HDMI Input(ARC) Jack: HDMI in. VGA Input Jack: Connects to the VGA output jack on a personal computer. PC Audio Input Jack: Connects to the Audio out jack of a computer.
-
Page 9: Remote
Orientation Remote ENTER During playback, press to select the previous track/chapter. During playback, press to select the next track/chapter. Switch to the previous display. Move to the next display. Jump to a specific time on a DVD/ VCD/MP3/WMA or CD. Press to start the A-B repeat function. -
Page 10: Main Menu Operation Setup Wizard
Main Menu Operation Setup Wizard The Setup Wizard 4. Use keys to navigate and select time you turned on the TV. It will assist you to your desired settings. IMPORTANT: Make sure the antenna or cable TV Setup Wizard system connection is made. Menu Language English 1. -
Page 11: Setup Menu
Setup Menu 1. Press MENU button, the setup window will appear on the screen. keys to highlight Setup mode. 2. Use 3. Use to highlight the item you would like to reset, then press to select the settings. 4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting. Picture Sound Lock... -
Page 12: Picture Menu
Picture Menu 1. Press MENU button, the setup window will appear on the screen. Picture Sound Time Setup Lock Channel 2. Use keys to highlight Picture mode. Picture Mode EnergySaving 3. Use to highlight the item you would Contrast like to reset, then press to select the Brightness Color... -
Page 13: Sound Menu
Sound Menu 1. Press MENU button, the setup window will appear on the screen. 2. Use keys to highlight Sound mode. 3. Use to highlight the item you would like to reset, then press to select the settings. 4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting. Picture Sound Lock... -
Page 14: Time Menu
Time Menu 1. Press MENU button, the setup window will appear on the screen. Picture Sound Time Setup Lock Channel 2. Use keys to highlight Time mode. Sleep Timer 3. Use to highlight the item you would Time Zone Daylight Saving Time like to reset, then press to select the Time Format... -
Page 15: Lock Menu
Lock Menu 1. Press MENU button, the setup window will appear on the screen. 2. Use keys to highlight Lock mode. keys to highlight “Enter Password” and input “0000” to enter the setup window. 3. Use 4. Use to highlight the item you would like to reset, then press to select the settings. -
Page 16: Channel Menu
Channel Menu 1. Press MENU button, the setup window will appear on the screen. 2. Use keys to highlight Channel mode. 3. Use to highlight the item you would like to reset, then press to select the settings. 4. Press Enter 5. -
Page 17: Media Menu
Media Menu INPUT button and select MEDIA. Press Enter to enter. keys to select to view Photo or Music. Press 2. Use Enter to enter. 3. Use 4. Press MENU to return to the previous menu or press EXIT at any time to exit the setting. -
Page 18: Trouble Shooting
Trouble Shooting Problem Solution/Issue Make sure the power cord is plugged in. TV does not Try another AC outlet. operate Unplug unit for an hour, then plug it back in. Check the volume settings. Normal picture, but Sound muted? Press MUTE button. no sound Try another channel. -
Page 19: Customer Support Warranty
Customer Support Warranty Limited 1 Year Warranty The Manufacturer warrants this product to be free from defects in workmanship and materials, under normal use and conditions, for a period of 1 year for parts and 90 days for labor from the original date of purchase. - Page 20 River Park Inc. 21953 Protecta Drive | Elkhart, IN 46516 http://www.riverparkinc.com U.S.(800) 442-7717 International(574) 522-7781...
