Door Panels

Furrion offers high gloss black, matte black, stainless steel
and black stainless steel colors of refrigerator door panel.
Contact Furrion or Furrion authorized dealer to purchase the
replacement door panel.
Replacement Door Panel
Color
8 cu. ft. 12V Built-in
Stainless Steel C-FCR08DCGTA-A01
Matte Black C-FCR08DCGTA-A02
High Gloss Black C-FCR08DCGTA-A03
Black Stainless Steel C-FCR08DCGTA-A04
Black Midnight Glass C-FCR08DCGTA-A05
Refrigerator Door Panel
When replacing the refrigerator door panel, the following
dimensions should be met:
Model
8 cu. ft. 12V Built-in
273/4"±1/16"
Refrigerator
10 cu. ft. 12V Built-
343/4"±1/16"
in Refrigerator
NOTE: "T" indicating the thickness of the replacement door panel.
14
Model
10 cu. ft. 12V Built-in
Refrigerator Refrigerator
C-FCR10DCGTA-A01
C-FCR10DCGTA-A02
C-FCR10DCGTA-A03
C-FCR10DCGTA-A04
C-FCR10DCGTA-A05
H V
233/4"±1/16"
233/4"±1/16"
1. Pull out the Side Cover. (Fig. 27)
Fig. 27
2. Slide out the Refrigerator Door Panel and replace with a
new one. (Fig. 28)
Fig. 28
Replacing Freezer Door Panel
T
When replacing the freezer door panel, the following
3/16" dimensions should be met:
3/16"
