Bradley Navigator S59-4000 Installation

S59-4000
S59-4000A
(Shown with Optional
Mounting Bracket)
Read this entire installation manual to ensure proper installation. When
finished with the installation, file this manual with the owner or maintenance
Installation
department. Compliance and conformity to local codes and ordinances is
the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for
Packing List
•
before discarding packaging material. If any parts are missing, do not begin
•
•
IS
T H installation until you obtain the missing parts.
E •
S ID
U P
Make sure that all water supply lines have been flushed and then completely
turned off before beginning installation. Debris in supply lines can cause
valves to malfunction.
Product warranties may be found under "Products" on our web site at
bradleycorp.com.
215-1638 Rev. E ECN 14-09-013B
© 2014 Bradley
Page 1 of 3 4/16/2014
Installation
S59-4000
S59-4000A
S59-4000BY
Navigator
Valve for Sinks/Faucets
Supplies and Tools Required ................................. 2
Installation ............................................................. 2
Maintenance and Troubleshooting ......................... 3
S59-4000BY
(Shown with Optional
Mounting Bracket)
Inlet Connections: 1/2" NPT or 3/8" Compression
Outlet Connection: 1/2" NPT or 3/8" Compression
Temperature Range: 95 – 125°F
Maximum Pressure: 125 PSIG
Inlet Temperature, Hot: 120 – 180°F
Inlet Temperature, Cold: 33 – 80°F
Minimum Temperature Differential (from valve set point): 10°F
IMPORTANT!
Thermostatic Mixing
®
ASSE 1070 & cUPC certified
