LG -D802 Service Manual page 343

Level LocationNo.
Capacitor
6 C6019
Ceramic,Chip
Capacitor
6 C122
Ceramic,Chip
R180
6 R182 Resistor,Chip
R186
R11002
6 R13014 Resistor,Chip
R6076
R1040
6 Resistor,Chip
R1041
R162
6 Resistor,Chip
R163
6 R13005 Resistor,Chip
R1034
6 Resistor,Chip
R1039
6 R3008 Resistor,Chip
6 R8045 Resistor,Chip
6 R8043 Resistor,Chip
Inductor
6 L6003
Wire Wound,Chip
Capacitor
6 C10013
Ceramic,Chip
6 D13000 Diode,TVS
IC,LDO Voltage
6 U12002
Regulator
LGE Internal Use Only
12. EXPLODED VIEW & REPLACEMENT PART LIST
Description PartNumber
ECZH0001215
ECZH0025920
ERHY0009505
ERHY0009506
ERHY0009521
ERHY0009526
ERHY0009527
ERHY0042409
ERHZ0000250
ERHZ0000286
ERHZ0000411
EAP62366101
EAE62685201
EAH61794301
EAN62735301
Spec
C1005X5R1A105KT000F 1uF 10% 10V X5R -
55TO+85C 1005 R/TP - TDK KOREA
COOPERATION
GRM033R71C102K 1nF 10% 16V X7R -
55TO+125C 0603 R/TP - - MURATA
MANUFACTURING CO.,LTD.
MCR006YZPJ103 10KOHM 5% 1/20W 0603 R/TP -
ROHM.
MCR006YZPJ104 100KOHM 5% 1/20W 0603 R/TP
- ROHM.
MCR006YZPJ331 330OHM 5% 1/20W 0603 R/TP -
ROHM.
MCR006YZPJ472 4.7KOHM 5% 1/20W 0603 R/TP
- ROHM.
MCR006YZPJ473 47KOHM 5% 1/20W 0603 R/TP -
ROHM.
RC0201FR-0749R9L 49.9OHM 1% 1/20W 0603
R/TP - YAGEO CORPORATION
MCR01MZP5F2400 240OHM 1% 1/16W 1005 R/TP
- ROHM.
MCR01MZP5F4701 4.7KOHM 1% 1/16W 1005
R/TP - ROHM.
MCR01MZP5J121 120OHM 5% 1/16W 1005 R/TP -
ROHM.
TFM252010GHM-2R2M 2.2UH 20% - 2.5A 3.1 2.5
0.097OHM - - SHIELD 2.5X2.0X1.0 MM - R/TP
TDK KOREA COOPERATION
C1005X5R1E104K 0.1uF 10% 25V X5R -
55TO+85C 1005 R/TP 0.55T max. TDK KOREA
COOPERATION
ESD5205P6T6G 5V 5.5V min. 10V 2UA 0W SOT-
963 R/TP 6P 5 ON SEMICONDUCTOR
RP114K101D-TRB 1.4v to 5.25v 1.0 0W DFN R/TP
4P - RICOH COMPANY, LTD.
- 343 - Copyright © 2013 LG Electronics. Inc. All right reserved.
Remark
Only for training and service purposes
