Section 3 • Systems & Components Overview & Operation
• if necessary, fi ll useing
SAE 0W-30 Full SyntheticPower
Steering Fluid ONLY.
• Replace cap and cover
Make it a habit of checking the fl uid level before
each trip.
REFER TO THE ENGINE MANUFACTURER'S
MANUAL IN YOUR OWNER'S MANUAL PACKET
FORCOMPLETE INSTRUCTIONS AND WARRANTY.

Fuel System

NOTICE
Fuel tanks should never be fi lled to capacity.
Allow 2% for expansion.
Fuel Tank
Fig. 3.3.1
1 GAS FILL KEY
2 INTEGRATED FUEL TANK VENT
FUEL FILL (AUXILIARY TANK)
3
4 FUEL FILL (STARBOARD TANK)
5
FUEL FILL HOSE (AUXILIARY TANK)
6
FUEL FILL HOSE (STARBOARD TANK)
7
FUEL TANK SENDER (STARBOARD TANK)
8
110 GAL. (416.3 L) ALUMINUM FUEL TANK
9
TANK STRAP
10
75 GAL. (284 L) ALUMINUM FUEL TANK
11
FUEL TANK SENDER (AUXILIARY TANK)
NOTICE
Fuel gauge only reads accurately when boat is
level (not underway).
305 Conquest
The 305 Conquest is equipped with a gasoline fuel
system. Please take time to read and understand
all the fuel related information and warnings in
the engine owner's packet.

Fuel tanks

Your boat is equipped with three (3) aluminum fuel
tanks. The port and starboard tanks have a volume
of 110 gal (416.3L) each. The auxiliary tank , located
under the mid cabin fl oor, has a volume of 75 gal
(284L).
Fuel fills are located amidship on the port and
starboard gunwale. The fuel fi ll deck plates can be
opened by use of a special key that is included in
your owner's manual packet. Refer to the engine
manufacturer's manual for recommended types
of fuel to use.
1
FWD
Starboard fuel tank shown, port tank is typical
3
2
4
5
6
7
9
8
10
11
3-3
