Gree FLEXX Series Service Manual

Dc inverter heat pump condensing unit
Hide thumbs Also See for FLEXX Series:
Table of Contents

Advertisement

Quick Links

FLEXX
DC INVERTER HEAT PUMP
CONDENSING UNIT SERVICE MANUAL
(GC202006-I)
Capacity: 24kBtu/h~60kBtu/h
Rate Frequency: 60Hz
Operation Range:
Cooling: 5°F(-15°C)~129.2° F(54° C )
Heating: -22°F (-30°C)~75.2°F (24°C)
1
