Brinkmann Immersions pumps of the series SGL801 ... 1103
Contents
1 Indication to the manual .................................... 2
2 Description of product .................................... 2-3
3 Safety instructions ............................................. 4
4 Transport and storage ....................................... 4
5 Installation and connection ................................ 5
6 Start up / Shut down .......................................... 6
7 Operation ........................................................... 6
8 Servicing and Maintenance ............................... 6

1 Indication to the manual

This operating manual gives basic instructions which
are to be observed during installation, operation and
maintenance of the pump. It is therefore imperative
that this manual be read by the responsible person-
nel and operator prior to assembly and commission-
ing. It is always to be kept available at the installation
site.
1.1 Identification of safety instructions in the
operating manual
Safety instructions given in this manual non-compli-
ance with which would affect safety are identified by
the following symbol
Safety sign according with
ISO 3864 - B.3.1
or where electrical safety is involved, with:
Safety sign according with
ISO 3864 - B.3.6
Where non-compliance with the safety instructions
may cause a risk to the machine and it's function the
word
ATTENTION
is inserted.

2 Description of product

2.1 General description of the pump
Pumps of this type are one or multi-stage rotary
pumps where the impellers are fixed on the driving
shaft extension. The pump shaft and motor shaft are
interconnected by means of a shaft clamp. Pump
and motor form a compact and space-saving unit.
These pumps are fitted out with semi-open impellers
and a suction screw.
Vertically mounted pumps are equipped with a
mounting flange. The pump end immerses into the
tank and the motor extends vertically above the tank.
BE2810
9 Trouble shooter's guide ..................................... 7
10 Spare part ...................................................... 8-9
11 Repair ............................................................... 9
12 Disposal ............................................................ 9
13 EC declaration of conformity ........................... 10
2.2 Intended use
The immersion pumps of the series SGL are suitable
for handling extremely inflated fluids (grinding oils)
within the limiting application in accordance with ta-
ble 1.
Limit of Application (Table 1)
Type
Mediums
Kinetic viscosity
of the medium
Temperature of
medium
Particle-size in
the medium
min. delivery
volume
Dry running
Switching-on
frequency per
hour
Ambient tempe-
rature
Set-up altitude
The pumps are to be operated within their design
limits. Applications outside of these limits are not ap-
proved. The manufacturer is not responsible for any
damages resulting from use of the pumps in such
applications.
11/2019
Edition
SGL801...804 SGL1101...1103
Coolants, cooling- and cutting-oils,
grinding oils
2
...45 mm /s ...45 mm
0 ... 80 °C 0 ... 80 °C
6 mm SGL 801... 804
8 mm SGL1101...1103
1% of Q max.
Dry running causes increased
wear and should be avoided.
During the test of the direction of
rotation (< 30 s) permissible.
Motors less 3 kW max. 200
from 3 kW to 4.0 kW max. 40
from 5.0 kW to 10.3 kW max. 20
Motors 11 kW and higher max. 15
40 °C
1000 m
ATTENTION
Page 2 of 10
