- Page 1 Industrial Bluetooth Communication System ® User’s Guide www.sena.com...
- Page 2 ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under license. iPhone, iPod touch are registered trademarks of Apple Inc. Zumo™ is a trademark of Garmin Ltd. or its subsidiaries. TomTom™ is the trademark or registered...
-
Page 3: Table Of Contents
GETTING STARTED ....................8 INTERCOM ......................21 3.1 Button Operation ........................8 8.1 Two-Way Intercom .........................21 3.2 Sena Softwares ........................9 8.2 Multi-Way Intercom........................21 3.3 Noise Reduction Rating ......................9 8.3 Three-Way Conference Phone Call with Intercom Participant ..........23 3.4 Powering On and Off.......................9 8.4 Group Intercom ........................23... -
Page 4: Package Contents
Tufftalk M 1.2 Hard Hat Mount Earmuff Type 1 PACKAGE CONTENTS • Headset Main Units (including the Type A Hard Hat Adapter for Tufftalk M) 1.1 Over-the-Head Earmuff Type • Headset • USB Power & Data Cable • Microphone • USB Power & Data Cable • Microphone Sponge (2) • Microphone • Rubber Pad (2) • Microphone Sponge (2) • Type B Hard Hat Adapter for Tufftalk M (2) -
Page 5: Installing The Headset
Tufftalk M Note: 2 INSTALLING THE HEADSET Removing the Microphone 1. Unfasten the microphone by rotating it clockwise. 2.1 Installing the Microphone (Over-the-Head Earmuff Type/Hard Hard Hat Mount Earmuff Type) 1. Align the arrows on the main unit and microphone and insert the microphone. -
Page 6: Installing The Headset (Hard Hat Mount Earmuff Type)
The headset with the microphone should be mounted on the right side of the hard hat. 2. Organize the cables under the hard hat suspensions. Right Speaker Cover Type A Hard Hat Adapter for Tufftalk M Tufftalk M Headset... -
Page 7: Replacing The Ear Pads
Tufftalk M 2.3 Replacing the Ear Pads Note: 1. Use your fingers to remove the ear pads. • If the rubber pad on the inner surface of the bracket-top begins to fray, 2. Insert the included ear pads. replace it with the included pad. -
Page 8: Getting Started
Tufftalk M 3 GETTING STARTED 3.1 Button Operation Status LED Center Button (-) Button (+) Button Mesh Intercom Button Left Ear Cup Left Ear Cup Right Ear Cup Right Ear Cup DC Power Charging & DC Power Charging & Microphone... -
Page 9: Sena Softwares
3.2.1 Sena Utility App (+) Button for 1 second. To power off the headset, tap the Center By simply pairing your phone with your headset, you can use the Sena Button and the (+) Button. Utility App for quicker and easier set up and management. -
Page 10: Checking The Battery Level
Note: • Any 3rd party USB charger can be used with Sena products if the charger is approved by either the FCC, CE or IC. • The headset is compatible with 5 V/1 A input USB-charged devices only. -
Page 11: Muting The Microphone (Default: Unmute)
2. You will hear a voice prompt, “Phone pairing”. 3. Search for Bluetooth devices on your mobile phone. Select the Sena Tufftalk M in the list of the devices detected on the mobile phone. 4. If your mobile phone asks for a PIN, enter 0000. -
Page 12: Intercom Pairing
Tufftalk M 4.2 Intercom Pairing 4. The intercom pairing queue is ‘Last-Come, First-Served’. If a headset has multiple paired headsets for intercom conversations, 4.2.1 Pairing with Other Headsets for Intercom Conversation the last paired headset is set as first intercom friend. The... -
Page 13: Mobile Phone
Tufftalk M 5.2 Speed Dialing 5 MOBILE PHONE You can quickly make a phone call by using the voice speed dial menu. 1. To enter into the voice speed dial menu, press and hold the (+) Button for 3 seconds and you will hear a mid-toned single beep 5.1 Mobile Phone Call Making and Answering... -
Page 14: Stereo Music
Tufftalk M 6. If you want to exit the speed dial immediately, tap the (+) Button 6 STEREO MUSIC or the (-) Button until you hear a voice prompt, “Cancel”, and tap the Center Button. Note: 6.1 Bluetooth Stereo Music •... -
Page 15: Mesh Intercom
Channel 1 users without the need to pair each headset together. The working distance between each Tufftalk M in Mesh Intercom can be up to 1.1 km (0.7 miles) in open terrain. In open terrain, the Mesh can be extended up to 4.4 km (2.8 miles) between a minimum of 6 users. -
Page 16: Starting Mesh Intercom
When Mesh Intercom is enabled, the Tufftalk M will automatically users to leave, join, or rejoin a group intercom conversation without connect to nearby Tufftalk M users and allow them to talk to each other by pressing the Mesh Intercom Button. -
Page 17: Using The Mesh In Open Mesh
Tufftalk M 7.3 Using the Mesh in Open Mesh 7.4 Using the Mesh in Group Mesh When Mesh Intercom is enabled, the headset will be in Open Mesh 7.4.1 Mesh Grouping (default: channel 1) initially. Creating a Group Mesh 7.3.1 Channel Setting (Default: channel 1) 1. - Page 18 Tufftalk M 2. When the headsets complete Mesh Grouping, users will hear a voice prompt, “Group Mesh”. Headsets automatically switch from Open Mesh to Group Mesh. Note: If the Mesh Grouping is not completed within 30 seconds, users will hear In Open Mesh a voice prompt, “Grouping failed”.
-
Page 19: Installing The Microphone 7.5 Toggling Open Mesh/Group Mesh
Tufftalk M 7.5 Toggling Open Mesh/Group Mesh 7.6 Reset Mesh A user is able to toggle between Open Mesh and Group Mesh without If a headset in an Open Mesh or Group Mesh resets the Mesh, it will resetting the Mesh. This allows the user to keep the Mesh Network automatically return to Open Mesh (default: channel 1). -
Page 20: Mesh Intercom Music Sharing
Tufftalk M 7.7 Mesh Intercom Music Sharing 7.8 Mesh Audio Multitasking (Always On) If you start sharing music while Mesh Intercom are running at the Mesh Audio Multitasking allows you to have a Mesh Intercom same time, then music shared during Bluetooth intercom will take conversation while simultaneously listening to music, FM radio, or GPS priority over music shared during Mesh Intercom. -
Page 21: Intercom
Tufftalk M 8.2 Multi-Way Intercom 8 INTERCOM Multi-Way Intercom enables conference-call-style conversations with up to three intercom friends at the same time. While multi-way intercom is in progress, mobile phone connection is temporarily disconnected. However, as soon as multi-way intercom terminates, the mobile phone 8.1 Two-Way Intercom... - Page 22 Tufftalk M 8.2.2 Starting Four-way Intercom 8.2.3 Ending Multi-Way Intercom With three intercom friends connected, a new participant (D) can You can completely terminate the conference intercom or just make it a four-way intercom conference by making an intercom call to disconnect an intercom connection with one of your active intercom either (B) or (C).
-
Page 23: Three-Way Conference Phone Call With Intercom Participant
Group Intercom with. the station dial. 2. Tap the (+) Button and (-) Button to begin Group Intercom. The 2. You can save current station from the Sena Device Manager or LED will flash green. the Sena Utility App. -
Page 24: Scan And Save
1. Press and hold the (+) Button for 1 second. Manager. With the region setting, you may optimize the seek function 2. The Sena tuner pauses at each station it finds for 8 seconds to avoid unnecessary frequency ranges. before moving to the next. -
Page 25: Function Priority
Tufftalk M 10 FUNCTION PRIORITY 11 CONFIGURATION SETTING The headset operates in the following order of priority: 11.1 Headset Configuration Setting (highest) Mobile phone 1. To enter configuration menu, press and hold the Center Mesh Intercom / Bluetooth Intercom Button for 10 seconds until you will also hear a voice prompt, Music sharing via Bluetooth stereo “Configuration menu”. -
Page 26: Software Configuration Setting
1. Execute Phone Pairing in the Configuration Menu. Manager or the Sena Utility App. 2. Search for Bluetooth devices on your mobile phone. Select the Sena Tufftalk M in the list of the devices detected on the mobile 11.2.1 Speed Dial phone. - Page 27 Tufftalk M 11.2.5 VOX Sensitivity (Default: 3) 11.2.8 HD Intercom (Default: Enable) VOX sensitivity can be adjusted depending on your riding environment. HD Intercom enhances the two-way intercom audio from normal quality to HD quality. HD Intercom will become temporarily disabled Level 5 is the highest sensitivity setting and 1 is the lowest.
-
Page 28: Firmware Upgrade
The headset supports firmware upgrades. You can update the firmware not be given as you select preset stations. using the Sena Device Manager. Please visit Sena website at 11.2.12 Advanced Noise Control™ (Default: Enable) www.sena.com to check the latest software downloads. -
Page 29: Troubleshooting
Tufftalk M 13 TROUBLESHOOTING 13.1 Fault Reset When the headset is not working properly or is in faulty status for any reason, you may reset by pushing the pin-hole reset button located below the Center Button. 13.2 Factory Reset If you want to restore the headset to factory default settings, use the Factory Reset in the configuration menu. - Page 30 1.0.0 www.sena.com...
