SAVANNAH STOKER v4 INSTRUCTION MANUAL
SAVANNAH STOKER v4 TEMPERATURE CONTROLLER
Thank-you for purchasing the Savannah Stoker Pellet Grill Control
System. The Savannah Stoker is a PID based artificial intelligent
temperature controller that allows you to control your wood pellet grill or
smoker with "simplicity but infinite control".
FEATURES
• Set the desired cooking/smoking temperature from 150°- 550°F
or the max temperature your grill can reach in 1° increments.
• Typical temperature swings are 5-10°F when cooking above
250°F and 10-15°F when smoking below 225°F.
• Hardwired permanent installed temperature sensor, compatible
with the OEM temperature sensor.
• Cool-down cycle. The fan runs until the grill temperature drops
below 120°F.
• Auto-relight. The controller will attempt to relight the fire if the
grill temperature drops too low below the set temperature. If the
fire does not relight; the cool down cycle automatically starts.
• 3 Phase Cooking Program: Smoke, Cook, Hold. Set the time
and temperature for each phase in the cooking process.
• Food Probe: For use with the cooking program or standalone to
monitor the food temperature.
• Auger Bypass. Press a button and the auger runs 100% to get
to grilling temperatures faster.
• Optional interface with the STOKER® Power Draft System from
Rocks Bar-B-Que. Add the features of the STOKER like remote
temperature control and monitoring from a computer or
Smartphone or graph the cook with StokerLog running on a PC.
Requires an optional cable. The STOKER is available from
http://www.rocksbarbque.com.
Compatibility
The Savannah Stoker is a direct replacement temperature controller for
most Traeger Wood Pellet Grills but it will not fit in the Traeger Junior or the
PTG. It will also control most smokers made by Smokin Brothers, Blaz'n
Grills Works, Royall Wood Pellet Grills (except the tailgater), Camp Chef
Pellet Grill & Smoker, and Smoke Daddy Pellet Pro. The Savannah Stoker
maybe compatible with other wood pellet grills but may requiring
modifications to the grill or wiring connectors.
WARNING Electrical Shock Risk!
Electrical power is present to the controller
anytime the grill is connected to an AC Power
Source. Before attempting to remove or install
the controller the grill must be disconnected
from the AC Power Source. Failure to do so
could result in personal injury from electrical
shock and/or damage to the controller. When
not in use the grill should be disconnected from
the AC Power Source. The controller should be
protected from moisture at all times. It is highly
recommended the grill be connected to a GFCI
outlet or other protected circuit when in use.
1
Ver.SSV4.1 Copyright © Sound Solutions, LLC. All Rights Reserved. Find us: SavannahStoker.com Facebook.com/SavannahStoker Pelletheads.com and LetsTalkBBQ.com
FOR THE WOOD PELLET GRILL
SPECIFICATIONS
Grill Temp Sensor RTD Compatable with the OEM RTD 1000 ohm
Accuracy 0.75%Full scale
Display Resolution 1°F or 1°C
Automatic Control using PID based algorithims
Manual Control
Control Modes
3 Step Cooking Program
STOKER® Control (optional interconnect cable required)
Fan Output Zero crossing SSR, 85-240VAC/3A
Auger Output Zero crossing SSR, 100-240VAC/3A
Igniter Output Zero crossing SSR, 100-240VAC/10A
Power supply 100-240VAC 50-60Hz
Power consumption > 300 Watts at startup, 50 Watts normal operation
Ambient temperature 0~50ºC, 32~122ºF
Fuse 5A ATO-ATC blade fuse.
Food Sensor Stainless steel probe, 750° wires
LIMITED WARRANTY
Sound Solutions, LLC, warrants to the original purchaser, the controller
to be free from defects in material and workmanship under normal use
for a period of one (1) year from the date of original purchase. The
temperature sensors and the STOKER® interface cable are warranted
for a period of ninety (90) days.
The warranty shall not apply: (i) to any controller subjected to accident,
misuse, neglect, water damage, alteration, acts of God, improper
handling, improper transport, improper storage, improper use or
application, improper installation, improper testing or unauthorized
repair; or (ii) to cosmetic problems or defects that result from normal
wear and tear under ordinary use and do not affect the performance or
use of the product. If the controller develops a covered defect during
the warranty period, Sound Solutions, LLC, will, at its option, either
repair or replace the controller, the temperature sensor or the STOKER
interface cable at no charge, provided that the controller and/or
temperature sensor are returned to Sound Solutions, LLC, during the
warranty period
To obtain warranty service contact Sound Solutions for an RMA # by
phone: 1-252-746-3367 or email:
Return the component(s) along with a copy of the sales receipt to:
Sound Solutions, LLC
4205 Holly Street
Ayden, NC 28513
THE ABOVE STATED WARRANTY IS EXCLUSIVE AND REPLACES
ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING
THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. SOUND SOLUTIONS, LLC WILL NOT BE HELD LIABLE
FOR ANY OTHER DAMAGES OR LOSS INCLUDING INCIDENTAL
OR CONSEQUENTIAL DAMAGES AND LOSS OF PROFITS OR
REVENUES FROM WHATEVER CAUSE, INCLUDING BREACH OF
WARRANTY OR NEGLIGENCE.
