- Page 1 A22-77620-000 instructions for use A22-77620-000_(DC)_IM_20200902...
-
Page 3: Table Of Contents
INDEX CHAPTER 1: INSTRUCTIONS FOR USE ..................4 USER MANUAL ............................5 GENERAL INFORMATION ......................5 WIRING SYSTEM ..........................8 SETTING THE INSIDE TEMPERATURE ..................9 FILLING ..............................10 DEFROSTING ............................10 CLEANING ............................10 MAINTENANCE ..........................11 USEFUL ADVICES ..........................11 CHAPTER 2: INSTALLATION MANUAL ..................12 INSTALLATION MANUAL ......................... -
Page 4: Chapter 1: Instructions For Use
A 22-7 7620 - 0 0 0 CHAPTER 1 INSTRUCTIONS FOR USE A22-77620-000_(DC)_IM_20200902... -
Page 5: User Manual
They can work even if they are assembled at a slant of up to 30°. In order to make sure that your Indel B refrigerator works as efficiently as possible, please pay attention to the following general instructions: •... - Page 6 A 22-7 7620 - 0 0 0 A 22-7 7620 - 0 0 0 NOTICE Do not install the refrigerator near heat sources (ex. portable heater). FREEZER BASKET A22-77620-000_(DC)_IM_20200902...
- Page 7 N OTICE WARNING! Do not install the refrigerator near heat sources. WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of any obstruction. WARNING! Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
-
Page 8: Wiring System
A 22-7 7620 - 0 0 0 1 . 2 WIRING SYS TE M To operate the refrigerator on the vehicle battery, please refer to the instruction manual of the vehicle's manufacturer. WIRING SYSTEM: FUNCTIONS AND FEATURES (WITH AUXILIARY BATTERY) The electronic control unit of the compressor is an electronic equipment which controls the motor of the compressor, takes care of the system and protects the electrical components. -
Page 9: Setting The Inside Temperature
WARNING Never connect non insulated cables, and use only connectors of a size suitable to the cross section of the cable being used. 1 . 3 S E T TIN G THE IN S ID E TE M PE R ATURE The refrigerators are provided with a manual thermostat. -
Page 10: Filling
A 22-7 7620 - 0 0 0 1 . 4 FILLIN G Do not put hot food into the refrigerator. Make sure the door is always well closed, and keep the door open to a minimum. 1 . 5 D E FROS TIN G Since the evaporator operates at temperatures well below freezing, ice and frost will inevitably form upon The humidity in the air, the temperature and the number of times the door is opened will have a significant impact on frost formation. -
Page 11: Maintenance
This type of damage is considered to be non-warrantable. • DTNA Service Bulletins, pertaining to Indel B refrigerators, should be reviewed prior to replacing any components. • If nothing is running or only fan is running, using a volt meter on 20v DC setting, check voltage at fridge with truck off and fridge off . -
Page 12: Chapter 2: Installation Manual
A 22-7 7620 - 0 0 0 CHAPTER 2 INSTALLATION MANUAL A22-77620-000_(DC)_IM_20200902... -
Page 13: Installation Manual
INS TALL ATION MANUAL 2 . 1 HAND LIN G The refrigerator is equipped with a strap for easier handling. FIG. 7 WARNING Do not remove or cut these straps. WARNING Handle the refrigerator using the provided straps. -
Page 14: Assembly
A 22-7 7620 - 0 0 0 2 . 2 A SS E M B LY The refrigerator is suitable to be mounted into the specific furniture. It can be fixed through the upper flange and the lower flange: - Insert the two hooks into the lower flange (Fig.1); - Use three screws to fasten the upper flange to the matching furniture flange (Fig.2). -
Page 15: Wiring Connections
2 . 3 WIRIN G CO NNEC TIO N S When you connect the refrigerator, you must follow the instruction below: 1) Connect the refrigerator power cable directly to the connector in the vehicle (Fig.5). 2) Any switches must have a breaking load not less than 20 A. 3) Make sure the polarity is right: connect the red cable to the positive terminal (+) and the black cable to the negative terminal (-). -
Page 16: Chapter 3: How To Detect Functional Problems And Fix Them
A 22-7 7620 - 0 0 0 CHAPTER 3 HOW TO DETECT FUNCTIONAL PROBLEMS AND FIX THEM A22-77620-000_(DC)_IM_20200902... -
Page 17: Cooling / No Operations From Compressor And Fan
NO COOLING / NO OPERATIONS FROM COMPRESSOR AND FAN WARNING Before replacing the refrigerator, prior be sure that voltage is ok and trouble shooting steps described in these forms have been followed! Turn Cab Load Disconnect Switch to ON Replace fuse. If fuse continues to Not ok and check refrigerator fuse. -
Page 18: Cooling / Compressor And Fan Is Operating
A 22-7 7620 - 0 0 0 3 . 2 N O COOLIN G / COM PRE SSO R AND FAN IS O PE R ATIN G WARNING Before replacing the refrigerator, prior be sure that voltage is ok and trouble shooting steps described in these forms have been followed! Check that thermostat is switched ON. -
Page 19: Form A: How To Fix Lamp
3 . 3 FO RM A: HOW TO FIX L A M P 1) Pull out the drawer until 1 inch from stop of rails and lift it up to remove it. 2) Remove display cover removing the 3 rivets fixing it 3) Pull out the display and disconnect it. - Page 20 A 22-7 7620 - 0 0 0 5) Unscrew the switch (2 rivets) 6) Remove the switch and replace it with a new one. Reverse the procedure to install the new switch Attention! Before installing again the drawer check if the switch stopper is rightly assembled on the back of the drawer.
-
Page 21: Form B: How To Short Circuit Thermostat On Ecu
3 . 4 FO RM B: HOW TO S H ORT CIRCU IT THE RMOS TAT O N ECU Jumper wire example... -
Page 22: Form C: How To Replace Thermostat
A 22-7 7620 - 0 0 0 3 . 5 FO RM C: HOW TO RE PL ACE THE RMOS TAT 1) Pull out the drawer until 1 inch from stop of rails and lift it up to remove it. 2) Pull out the drawer. - Page 23 6) Remove the adhesive paste 5) Remove the thermostat bulb 5) Remove the thermostat bulb 6) Remove the adhesive paste around the pipe of evaporator around the pipe of evaporator 7) Unscrew the plastic ring fixing the thermostat sensor 7) Unscrew the plastic ring fixing the thermostat sensor 8) Pull out the thermostat sensor...
- Page 24 A 22-7 7620 - 0 0 0 9) Unscrew the thermostat box (2 screws) 10) Disconnect the 2 wires from the thermostat 11) Unscrew the thermostat (2 screws) and pull it out. Reverse the procedure to install the new thermostat A22-77620-000_(DC)_IM_20200902...
-
Page 25: Form D: How To Replace Ecu (Electronic Control Unit)
FORM D: HOW TO REPLACE ECU (ELECTRONIC CONTROL UNIT) Disconnect all wires from ECU, unscrew it (one screw) and with the help of a screwdriver push the connector towards left side. Reverse the procedure to install the new ECU. -
Page 26: Form E: How To Test And Replace Fan
A 22-7 7620 - 0 0 0 3 .7 FO RM E: HOW TO TE S T AND RE PL ACE FAN Disconnect wires of fan from + and F of the ECU and check if there is continuity. If not replace fan. Cut the four black plastic strips holding the fan to the condenser Remove the fan from condenser and reverse the procedure to install the new one A22-77620-000_(DC)_IM_20200902... -
Page 27: Chapter 4: How To Detect Functional Problems And Fix Them
CHAPTER 4 HOW TO REPLACE AESTETHICAL PARTS... -
Page 28: Part 1: Complete Drawer
A 22-7 7620 - 0 0 0 4 . 1 PART 1: COM PLE TE D R AWE R 1) Pull out the drawer until 1 inch from stop of rails and lift it up to remove it. A22-77620-000_(DC)_IM_20200902... -
Page 29: Part 2: Handle
4 . 2 PART 2 : HAND LE 1) Raise up the handle and push the spring towards the middle. The handle and the pivot will be unfixed 2) Insert the pivot of the handle from the top of the door and push it inside. Place the new handle making enter the pivots of the spring in the two holes... -
Page 30: Part 3: Drawer Sideboard
A 22-7 7620 - 0 0 0 4 . 3 PART 3: D R AWE R S ID E BOARD Description of operations: On the backside of the drawer, turn the screw toward the outside of the sideboard with the help of a screwdriver (picture A and B). To uninistall it from the inner front side turn the sideboard in counter clockwise (picture C and D). -
Page 32: Part 4: Slide
A 22-7 7620 - 0 0 0 4 . 4 PART 4: S LID E Description of operations: remove the drawer and pull out the slide system. Unscrew the fixed part of the sliding system (3 screws – picture G). To install the new slide, placing it on the plastic inner body of the cabinet ( picture H). -
Page 34: Part 5: Top Drawer
A 22-7 7620 - 0 0 0 4 . 5 PART 5: TO P D R AWE R Pull out the drawer. Lift up the lever on the right slide and lift down the lever on the left slide 4 .6 PART 6: BOT TLE RE TAINE R OF TO P D R AWE R Pull up the bottle retainer to remove it from the top drawer A22-77620-000_(DC)_IM_20200902... -
Page 35: Part 7: Front Of Top Drawer
4 .7 PART 7: FRO NT OF TOP D R AWE R Pull out the bottle retainer Remove the 4 rivets fixing the front of the top drawer Pull out the front... -
Page 36: Part 8: Upper Slide
A 22-7 7620 - 0 0 0 4 . 8 PART 8: U PPE R S LID E Description of operations: remove the drawer and pull out the slide system. Unscrew the fixed part of the sliding system (3 screws). To install the new slide, placing it touching its housing on the plastic inner body of the cabinet Start to attach it from the last screw towards the back wall of the cabinet (picture I), working forward. -
Page 37: Part 9: Upper Flange
4 .9 PART 9: U PPE R FL ANG E Unscrew the upper flange (3 screws) and remove it... -
Page 38: Chapter 5: Spare Parts
A 22-7 7620 - 0 0 0 CHAPTER 5 SPARE PARTS A22-77620-000_(DC)_IM_20200902... - Page 40 A 22-7 7620 - 0 0 0 A22-77620-000_(DC)_IM_20200902...
- Page 41 INDEL B P/N DESCRIPTION E188 Thermostat Box G007 G112 Thermostat G131 Compressor G538 Light G540 Light Protection G543 Rails (Rh+Lh) G588 Back Tray G598 Thermostat Knob G600 Light Switch G604 Fridge Basket G608 Freezer Basket G609 Drip Tray G665 Rh Mobile Rail...
- Page 42 A 22-7 7620 - 0 0 0 A22-77620-000_(DC)_IM_20200902...
