Page 2
Safety InforMatIon Safety WarnInGS WarnInG • To reduce the risk of fire or electric shock, do TO REDUCE THE RISK OF ELECTRIC SHOCK, DO not expose this appliance to rain or moisture. NOT REMOVE THE COVER (OR BACK). CaUtIon NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE •...
Page 3
ManUaL cold temperatures. If transporting the unit You can access the Full Manual on Samsung’s during the winter, wait approximately on-line customer support centre by scanning 2 hours until the unit has reached room the QR code.
ContentS Checking the Components Inserting Batteries before using the Remote Control (AA batteries X 2) ------------------------- Product overview Front Panel / Right Side Panel of the Soundbar ------------------------- Bottom Panel of the Soundbar ------------------------- Connecting the Soundbar Connecting Electrical Power ------------------------- Connecting to your tV Method 1.
Page 5
Connecting a Mobile Device Method 1. Connecting via Bluetooth ------------------------- Method 2. Connecting via Wi-Fi (Wireless Network) ------------------------- Using the remote Control How to Use the Remote Control ------------------------- Adjusting the Soundbar volume with a TV remote control ------------------------- Software Update Installing the Wall Mount Installation Precautions -------------------------...
• For Soundbar wall mounting components, see page 20. • See page 22 for instructions on how to use the Holder-Cable. • To purchase additional components or optional cables, contact a Samsung Service Centre or Samsung Customer Care. Inserting batteries before using the remote Control (aa batteries X 2) Slide the battery cover in the direction of the arrow until it is completely removed.
(Source) button for more than 5 seconds. PoWer oUt Connect the power cord of a Samsung TV connected to the Soundbar and mounted on (for tV) the wall using a Wall Mount Kit (WMN300SB - not supplied). PoWer In Connect the Soundbar's AC power cable.
Connect to the HDMI output of an external device. HDMI oUt Connect to the HDMI (ARC) jack on a TV. Wi-fi SetUP Connect to a wireless network (Wi-Fi) via the Samsung Multiroom app. / SPK aDD 03 ConneCtInG tHe SoUnDbar Connecting electrical Power •...
04 ConneCtInG to yoUr tV Hear TV sound from your Soundbar through wired or wireless connections. • When the Soundbar is connected to a selected Samsung TVs, the Soundbar can be controlled using the TV’s remote control. – When using optical cable, this feature can be supported by 2017 Samsung Smart TVs that support Bluetooth.
• If “tV arC” does not appear in the display window of the Soundbar main unit, confirm that the cable is connected to the correct port. • Use the volume buttons on the TV’s remote control to change the volume of the Soundbar. Connecting using an optical Cable bottom of the Soundbar DIGITAL AUDIO IN...
5. You can now hear TV sound from the Soundbar. If the device fails to connect • If the previously connected Soundbar listing (e.g. “[aV] Samsung Soundbar MSxxx”) appears in the list, delete it. • In “bt” mode, press and hold the (Source) button for more than 5 seconds on the right side panel of the Soundbar or on the remote control to switch to “bt PaIrInG”...
(Play/Pause) button on the remote control for 5 seconds in “bt reaDy” status. (Toggle On → Off) Connecting via Wi-fi Pre-connection Checklist 1. Confirm that your Samsung smart tV was released after 2014. This function is compatible only with Samsung smart TVs released after 2014. 2. Make sure your Wireless router (Wi-fi) is ready and working.
Page 13
(Source) button on the right side of the Soundbar or on the remote control to select “WIfI” mode. • When using selected Samsung TV (2016 or 2017 Samsung smart TVs that support Bluetooth.) – If you select “WIfI” mode when the TV is turned on, the TV screen displays a pop-up window providing instructions on how to automatically connect the Soundbar to a wireless router (Wi-Fi).
Page 14
2015 1. Home menu Sound Speaker List Select [AV] Samsung Soundbar MSxxx (Wi-Fi) 2. The Soundbar outputs TV sound. for tVs released in 2014 1. Home menu Sound Speaker Settings Select Multiroom Link - Settings ...
05 ConneCtInG an eXternaL DeVICe Connect to an external device via a wired or wireless network to play the external device’s sound through the Soundbar. Connecting using an HDMI Cable bottom of the Soundbar HDMI IN external Device HDMI OUT HDMI Cable HDMI OUT (TV-ARC)
Connecting using an optical or analogue audio (aUX) Cable right Side of the Soundbar bD / DVD player / Set-top box / Game console DIGITAL AUDIO IN (OPTICAL) OPTICAL OUT optical Cable (not supplied) WIRELESS - AUDIO - AUX IN audio (aUX) Cable bottom of the Soundbar (not supplied)
06 ConneCtInG a USb You can play music files located on USB storage devices through the Soundbar. Display USb port USB (5V 0.5A) Wi-Fi SETUP SPK ADD POWER DIGITAL AUDIO IN (For TV) (OPTICAL) HDMI IN WIRELESS POWER AUX IN HDMI OUT (TV-ARC) USB (5V 0.5A)
Page 18
4. Play music files from the device, connected via Bluetooth, through the Soundbar. If the device fails to connect • If the previously connected Soundbar listing (e.g. “[aV] Samsung Soundbar MSxxx”) appears in the list, delete it. • In “bt” mode, press and hold the (Source) button for more than 5 seconds on the right side panel of the Soundbar or on the remote control to switch to “bt PaIrInG”...
Page 19
• Connect a single Soundbar to Wi-Fi to access a variety of music streaming services and Internet radio. Connect multiple Soundbars to Wi-Fi to use grouped playback or stereo sound mode. • To connect a Soundbar to a mobile device via a wireless network (Wi-Fi), the Samsung Multiroom app is required.
Page 20
) at the top, and then select “add Speaker”. 2. To connect the Soundbar to 2 Samsung wireless speakers and configure a surround sound system, follow the steps shown below. (You cannot set up a surround sound system using one audio device and one Soundbar.)
Page 21
08 USInG tHe reMote ControL How to Use the remote Control Turns the Soundbar on and off. Power You can select from trebLe, SynC, rear LeVeL, or rear SPeaKer on/off. • To adjust the trebLe volume, select Sound Sound Control Control trebLe, and then use the Up/Down buttons to adjust the volume within the -6 to +6 range.
Page 22
Anynet+ and Auto Power Link are controlled by the right and Left buttons respectively. – Anynet+ : If the Soundbar is connected to a Samsung TV through an HDMI cable, you can control your Soundbar with the Samsung TV’s remote control.
Page 23
• After installing the Soundbar, you can adjust the Soundbar’s volume using the IR remote control that came with a Samsung TV. (If you do not want to use this function, when the Soundbar is on, press and hold the Surround button for 5 seconds. “off-tV reMote” appears in the Soundbar’s display and the function turns off.) To adjust the volume using only the Samsung TV remote control,...
Page 24
09 SoftWare • Connect cables from the unit to external devices before you install the Soundbar on UPDate the wall. • Make sure the unit is turned off and unplugged before you install it. Otherwise, it When the Soundbar is connected to the Internet, may cause an electric shock.
Page 25
2. Align the Paper Template’s Centre Line with 5. Push a screw (not supplied) through each Holder-Screw, and then screw each screw the centre of your TV (if you are mounting the Soundbar below your TV), and then fix firmly into a support screw hole. the Wall Mount Guide to the wall using tape.
Page 26
assembling the Holder-Cable 7. Install the Soundbar with the attached bracket-Wall Mounts by hanging the As shown in the image, use the supplied Screw to bracket-Wall Mounts on the Holder-Screws fix the Holder-Cable to the Soundbar, and then on the wall. use the Holder-Cable to organise any cables.
Page 27
; Connected via Wi-fi Is the Mute function on? 1. Check if the TV is a compatible model. ; Press the VoL button to cancel the • Only Samsung smart tVs released function. after 2014 are supported. Is the volume set to minimum? 2.
Page 28
Multimedia Interface, and the HDMI Logo are found in the list of speakers when trademarks or registered trademarks of HDMI Samsung Multiroom app is run on the Licensing LLC in the United States and other mobile device (e.g. smartphone or countries.
Page 29
Dolby® Digital), DTS noteS • Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. • Weight and dimensions are approximate. • For more information about the power supply and power consumption, refer to the label attached to the product.
POWER IN 會損壞 Soundbar 或引致故障。) 如需兼容 WMN300SB 掛牆套件和 POWER USB (5V 0.5A) POWER DIGITAL AUDIO IN (OPTICAL) (For TV) HDMI IN OUT 插孔的 Samsung TV 清單 , 請參閱 WIRELESS POWER AUX IN HDMI OUT (TV-ARC) WMN300SB 掛牆套件使用者手冊。您可以在 Soundbar 主設備的底部 網上查看手冊 :...
06 連接 USB 您可以透過 Soundbar 播放位於 USB 儲存裝置上的音樂檔案。 USB 埠 顯示螢幕 USB (5V 0.5A) Wi-Fi SETUP SPK ADD POWER DIGITAL AUDIO IN (For TV) (OPTICAL) HDMI IN WIRELESS AUX IN POWER HDMI OUT (TV-ARC) USB (5V 0.5A) 1. 將 USB 裝置連接至產品背部的 USB 連接埠。 2.
Page 50
• Anynet+ / Auto Power Link WOOFER 您可以開啟或關閉 Anynet+ 和 Auto Power Link。 Anynet+ 和 Auto Power Link 分別由右和左按鈕控制。 – Anynet+:如果使用 HDMI 線將 Soundbar 連接至 Samsung TV,您 可以使用 Samsung TV 遙控器控制 Soundbar。按住右按鈕 5 秒以將 Anynet+ 切換至 ON 或 OFF。 – Auto Power Link:如果透過數位光纖纜線連接 Soundbar 和電...
Page 56
3. 檢查 Soundbar 是否已連接至 Wi-Fi 。 The terms HDMI and HDMI High- • 連接後 , 當 Samsung Multiroom Definition Multimedia Interface, and the 應用程式在流動裝置 (例如 ,智能 HDMI Logo are trademarks or 手機或平板電腦) 上執行時,您會 registered trademarks of HDMI 在揚聲器清單上看到 Soundbar。 Licensing LLC in the United States and (請參閱第...
