IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
• Made from particleboard,MDF with a wood effect finish.
• Made in Indonesia.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching
or damage.
• Ensure the mats and coasters used do not have an abrasive surface underneath.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly
and periodically check all fixings and tighten if necessary.
804990
ASSEMBLY INSTRUCTIONS.
1 of 12
BARLOW SIDEBOARD

Advertisement

loading
Need help?

Need help?

Do you have a question about the BARLOW SIDEBOARD 804990 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next BARLOW SIDEBOARD 804990

  • Page 1 804990 BARLOW SIDEBOARD ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 FITTINGS 15x12 mm. 7.5X32 mm. 8x32 mm. 20x9 mm. T35 Full Curve. 18x3 mm. 6x40 mm. Ax36 Bx36 Cx66 Gx20 F4x19 mm. F6x13 mm. 660 mm. F10X70 mm. 25x30 mm. P4x15 mm. 150 mm. Hx24 Ix40 F6x30 mm. 15.3x25 mm. 350 mm.
  • Page 3 STEP ONE - Attach 8x cambolts (B) into the holes of panel 1. Recommend to use cross-blade screwdriver. STEP TWO - Insert 4x camlocks (A) into the holes of panel 2 and ensure that arrow indicator is pointing towards the panel edge - Insert 4x wooden dowels (C) into the holes of panel 2.
  • Page 4 STEP FOUR - Attach 2x cambolts (B) into the holes of panel 3L. - Insert 2x camlocks (A) into the holes of panel 3L and ensure that arrow indicator is pointing towards the panel edge. - Insert 2x wooden dowels (C) into the holes of panel 3L. Recommend to use cross-blade screwdriver.
  • Page 5 STEP SEVEN - Attach 2x hinges (E) to the holes of panel 7R and secure by tightening 4x screws ( I ) clockwise with a screwdriver. - Attach 1x handle (L) to the holes of panel 7R and secure by tightening 1x screw (M) clockwise with a screwdriver. Recommend to use cross-blade screwdriver.
  • Page 6 STEP TEN - Attach 2x panel 12 to the panel 2 and secure by tightening 2x screws (O) clockwise with a screwdriver. Recommend to use cross-blade screwdriver. STEP ELEVEN - Attach panel 4L and 4R to the assembled unit by tightening 4x screws (K) clockwise with a cross-blade screwdriver.
  • Page 7 STEP THIRTEEN - Carefully lift the unit upright . (This should lifted by 2 people) - Insert panel 13 (3x) and 14 to the recessed grooves of panel 3L,3R and 2. - Repeat this step for the remaining fittings and parts. - Slide bar (J) between back panels 13 and 14.
  • Page 8 STEP SIXTEEN - Attach panel 6 to the assembled unit by tightening 4x screws (R) clockwise with a cross-blade screwdriver STEP SEVENTEEN - Attach 12x cambolts (B) into the holes of panel 8 (x6). - Attach 6x handles (L) to the holes of panel 8(x6) and tighten 6 x screws (M) clockwise with a flate-blade screwdriver.
  • Page 9 STEP NINETEEN - Insert panel 11 to the recessed grooves of panel 10L,10R and 9. - Repeat this step for the remaining parts. 6SETS STEP TWENTY - Attach panel 8 to the assembled unit by tightening 2x camlocks (A) clockwise with a flat-blade screwdriver. - Repeat this step for the remaining fittings and parts.
  • Page 10 STEP TWENTY TWO - Insert 2x door stoppers (D) into the holes of panel 6. - Insert 8x shelf supports (P) into the holes of panel 4R and 4L and insert 2x panel 5 to the assembled unit. - Insert the drawers to the assembled unit. STEP TWENTY THREE - Attach panel 7R and 7L to assembled unit and tightening 8x screws ( I ) clockwise with a cross-blade screwdriver...
  • Page 11 NB : Wall fixing are not included. Please source suitable fixing for your wall type. If in doubt please consult a qualified trades person. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 11 of 12...
  • Page 12 Note : Whilst position foil stickers to cover the holes. Ensure that you arrange them on the centre of the holes before sticking. And ensure the grain direction of foil sticker have to be in the same direction as current surface area. Next Retail Ltd, Desford Road, Leicester, LE19 4AT 12 of 12...
