OWNER'S MANUAL
VMX12T(C)
LIT-11626-18-18
5GK-28199-15

Advertisement

Table of Contents
loading

Summary of Contents for Yamaha VMX EAU10041

  • Page 1 OWNER’S MANUAL VMX12T(C) LIT-11626-18-18 5GK-28199-15...
  • Page 2 EAU10041...
  • Page 3 INTRODUCTION EAU10080 Congratulations on your purchase of the Yamaha VMX12. This model is the result of Yamaha’s vast experience in the pro- duction of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and reli- ability that have made Yamaha a leader in these fields.
  • Page 4: Important Manual Information

    This manual should be considered a permanent part of this motorcycle and should remain with it even if the motorcycle is subsequently sold. Yamaha continually seeks advancements in product design and quality. Therefore, while this manual contains the most current product information available at the time of printing, there may be minor discrepancies between your motorcycle and this manual.
  • Page 5 IMPORTANT MANUAL INFORMATION AND UNTIL YOU HAVE BEEN TRAINED IN SAFE AND PROPER RIDING TECHNIQUES. REGULAR INSPECTIONS AND CAREFUL MAINTENANCE, ALONG WITH GOOD RIDING SKILLS, WILL ENSURE THAT YOU SAFELY ENJOY THE CAPABILITIES AND THE RELIABILITY OF THIS MOTORCYCLE.
  • Page 6 IMPORTANT MANUAL INFORMATION EAU10192 AFFIX DEALER LABEL HERE VMX12T(C) OWNER’S MANUAL ©2004 by Yamaha Motor Corporation, U.S.A. 1st edition, April 2004 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited.
  • Page 7: Table Of Contents

    SAFETY INFORMATION ...1-1 Location of important labels ...1-5 DESCRIPTION ...2-1 Left view ...2-1 Right view ...2-2 Controls and instruments ...2-3 INSTRUMENT AND CONTROL FUNCTIONS ...3-1 Main switch ...3-1 Indicator and warning lights ...3-1 Speedometer unit ...3-2 Tachometer ...3-3 Coolant temperature gauge ...3-3 Handlebar switches ...3-3 Clutch lever ...3-5 Shift pedal ...3-5...
  • Page 8 STORAGE ...7-1 Care ...7-1 Storage ...7-3 SPECIFICATIONS ...8-1 CONSUMER INFORMATION...9-1 Identification numbers ...9-1 Reporting safety defects ...9-3 Motorcycle noise regulation ...9-4 Maintenance record ...9-5 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY ...9-7 YAMAHA EXTENDED SERVICE (Y.E.S.) ...9-9...
  • Page 9: Safety Information

    EAU10270 MOTORCYCLES SINGLE TRACK VEHICLES. THEIR SAFE USE AND OPERATION ARE DEPEN- DENT UPON THE USE OF PROPER RIDING TECHNIQUES AS WELL AS THE EXPERTISE OF THE OPERA- TOR. EVERY OPERATOR SHOULD KNOW THE FOLLOWING REQUIRE- MENTS BEFORE RIDING THIS MOTORCYCLE.
  • Page 10 A passenger should also observe the above precautions. Modifications Modifications made to this motorcycle not approved by Yamaha, or the re- moval of original equipment, may ren- der the motorcycle unsafe for use and may cause severe personal injury. Modifications may also make your motorcycle illegal to use.
  • Page 11 Accessories Genuine Yamaha accessories have been specifically designed for use on this motorcycle. Since Yamaha cannot test all other accessories that may be available, you must personally be re- sponsible for the proper selection, in- stallation and use of non-Yamaha accessories.
  • Page 12 SAFETY INFORMATION Gasoline and exhaust gas GASOLINE IS HIGHLY FLAMMA- BLE: • Always turn the engine off when refueling. • Take care not to spill any gaso- line on the engine or exhaust system when refueling. • Never refuel while smoking or in the vicinity of an open flame.
  • Page 13: Location Of Important Labels

    SAFETY INFORMATION EAU10381 Location of important labels Please read the following important labels carefully before operating this vehicle.
  • Page 14 SAFETY INFORMATION CALIFORNIA ONLY...
  • Page 15: Description

    DESCRIPTION EAU10410 Left view 1. Clutch fluid reservoir (page 6-25) 2. Air filter element (page 6-18) 3. Fuse box (page 6-33) 4. Main fuse box (page 6-33) 5. Owner’s tool kit (page 6-1) 6. Shock absorber assembly spring preload adjusting ring (page 3-11) 7.
  • Page 16: Right View

    DESCRIPTION EAU10420 Right view 1. Fuel tank cap (page 3-6) 2. Battery (page 6-30) 3. Coolant reservoir (page 6-14) 4. Front brake fluid reservoir (page 6-25) 5. Main switch (page 3-1) 6. Radiator cap (page 6-14) 7. Radiator (page 6-14) 8.
  • Page 17: Controls And Instruments

    DESCRIPTION EAU10430 Controls and instruments 1. Clutch lever (page 3-5) 2. Left handlebar switches (page 3-3) 3. Speedometer unit (page 3-2) 4. Right handlebar switches (page 3-3) 5. Brake lever (page 3-5) 6. Throttle grip (page 6-19) 7. Tachometer (page 3-3) 8.
  • Page 18: Instrument And Control Functions

    INSTRUMENT AND CONTROL FUNCTIONS Main switch The main switch controls the ignition and lighting systems. The various main switch positions are described below. All electrical systems are supplied with power, and the headlight, meter light- ing, taillight and position lights come on, and the engine can be started.
  • Page 19: Speedometer Unit

    2. Shift the transmission into the neu- tral position or pull the clutch lever. 3. Push the start switch. If the warn- ing light does not come on, have a Yamaha dealer check the electri- cal circuit. NOTE: Even if the oil level is sufficient, the...
  • Page 20: Tachometer

    INSTRUMENT AND CONTROL FUNCTIONS Tachometer 1. Tachometer 2. Tachometer red zone The electric tachometer allows the rider to monitor the engine speed and keep it within the ideal power range. CAUTION: Do not operate the engine in the ta- chometer red zone. Red zone: 9000 r/min and above EAU11851 Coolant temperature gauge...
  • Page 21 EAU12410 Dimmer switch “LIGHTS” Set the switch to “HI” for the high beam and to “LO” for the low beam. EAU12420 Turn signal switch “TURN” To signal a right-hand turn, push this switch to the right. To signal a left-hand turn, push the switch to the left.
  • Page 22: Clutch Lever

    INSTRUMENT AND CONTROL FUNCTIONS Clutch lever 1. Clutch lever The clutch lever is located at the left handlebar grip. To disengage the clutch, pull the lever toward the handle- bar grip. To engage the clutch, release the lever. The lever should be pulled rapidly and released slowly for smooth clutch operation.
  • Page 23: Brake Pedal

    EAU12941 Brake pedal 1. Brake pedal The brake pedal is on the right side of the motorcycle. To apply the rear brake, press down on the brake pedal. INSTRUMENT AND CONTROL FUNCTIONS EAU13060 Fuel tank cap To remove the fuel tank cap 1.
  • Page 24: Fuel

    Your Yamaha engine has been de- signed to use regular unleaded gaso- line with a pump octane number [(R+M)/2] of 86 or higher, or a research octane number of 91 or higher.
  • Page 25: Starter (Choke) Lever

    EAU13630 Starter (choke) lever 1. Starter (choke) lever Starting a cold engine requires a richer air-fuel mixture, which is supplied by the starter (choke). Move the lever in direction (a) to turn on the starter (choke). Move the lever in direction (b) to turn off the starter (choke).
  • Page 26: Rider Seat

    INSTRUMENT AND CONTROL FUNCTIONS Rider seat To remove the rider seat 1. Release the rider seat backrest by pushing the levers on the left and right side as shown, and then slide the backrest forward. 1. Opening lever 2. Remove the bolts and screws, and then pull the rider seat off.
  • Page 27: Helmet Holder

    1. Front fork air valve cap 2. Front fork air valve 3. Check the air pressure in each fork leg with an air pressure gauge. 1. Air pressure gauge NOTE: An optional air pressure gauge is avail- able at a Yamaha dealer.
  • Page 28: Adjusting The Shock Absorber Assemblies

    INSTRUMENT AND CONTROL FUNCTIONS 4. To increase the spring rate and thereby harden the suspension, in- crease the air pressure with an air pump or compressed air. To de- crease the spring rate and thereby soften the suspension, decrease the air pressure by pushing each valve stem down.
  • Page 29 Do not deform or damage the gas cylinders in any way, as this will result in poor damping per- formance. Always have a Yamaha dealer service the shock absorbers.
  • Page 30: V-Boost

    Adjustment should be left to a Yamaha dealer who has the profes- sional knowledge and experience to do CAUTION: The V-Boost was set at the Yamaha factory after many tests. If the set- tings are changed by someone with- out sufficient technical knowledge, poor engine performance and dam- age may result.
  • Page 31: Ignition Circuit Cut-Off System

    Yamaha dealer re- pair it if it does not function proper- INSTRUMENT AND CONTROL FUNCTIONS EAU15321 Ignition circuit cut-off system The ignition circuit cut-off system (com- prising the sidestand switch, clutch switch and neutral switch) has the fol- lowing functions.
  • Page 32 This check is most reliable if performed with a warmed-up engine. The neutral switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer. The sidestand switch may be defective. The motorcycle should not be ridden until checked by a Yamaha dealer.
  • Page 33: Pre-Operation Checks

    PRE-OPERATION CHECKS EAU15591 The condition of a vehicle is the owner’s responsibility. Vital components can start to deteriorate quickly and unexpectedly, even if the vehicle remains unused (for example, as a result of exposure to the elements). Any damage, fluid leakage or loss of tire air pressure could have serious consequences.
  • Page 34: Pre-Operation Check List

    • If necessary, add recommended coolant to specified level. • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check lever free play. • Adjust if necessary. Front brake •...
  • Page 35 • Check hydraulic system for leakage. • Make sure that operation is smooth. • Check cable free play. Throttle grip • If necessary, have Yamaha dealer adjust cable free play and lubricate cable and grip housing. • Make sure that operation is smooth. Control cables •...
  • Page 36: Operation And Important Riding Points

    NOTE: When the transmission is in the neutral position, the neutral indicator light should be on, otherwise have a Yamaha dealer check the electrical cir- cuit. 3. Turn the starter (choke) on and completely close the throttle. (See EWA10290 page 3-8.)
  • Page 37 OPERATION AND IMPORTANT RIDING POINTS ter starting with sufficient fuel, have a Yamaha dealer check the electrical circuit. 5. After starting the engine, move the starter (choke) back halfway.
  • Page 38: Starting A Warm Engine

    OPERATION AND IMPORTANT RIDING POINTS Starting a warm engine Follow the same procedure as for start- ing a cold engine with the exception that the starter (choke) is not required when the engine is warm. EAU16640 Shifting 1. Shift pedal Shifting gears lets you control the amount of engine power available for starting off, accelerating, climbing hills,...
  • Page 39: Engine Break-In

    4. At the recommended shift points shown in the following table, close the throttle, and at the same time, quickly pull the clutch lever in. 5. Shift the transmission into second gear. (Make sure not to shift the transmission into the neutral posi- tion.) 6.
  • Page 40: Parking

    Keep the engine speed out of the tachometer red zone. If any engine trouble should oc- cur during the engine break-in period, immediately have a Yamaha dealer check the vehi- cle. ECA10331 Parking When parking, stop the engine, and then remove the key from the main switch.
  • Page 41: Periodic Maintenance And Minor Repair

    (if applicable). EWA10320 WARNING If you are not familiar with mainte- nance work, have a Yamaha dealer do it for you. PERIODIC MAINTENANCE AND MINOR REPAIR EAU17301 PERIODIC MAINTENANCE PROPER PERIODIC MAINTENANCE...
  • Page 42 NOTE: If you do not have the tools or experi- ence required for a particular job, have a Yamaha dealer perform it for you. EWA10340 WARNING Modifications approved Yamaha may cause loss of perfor- mance, excessive emissions, and render the vehicle unsafe for use.
  • Page 43: Periodic Maintenance Chart For The Emission Control System

    • Check control system for dam- sion control system age. (For California only) • Replace if necessary. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. PERIODIC MAINTENANCE AND MINOR REPAIR INITIAL 600 mi 4000 mi...
  • Page 44: General Maintenance And Lubrication Chart

    PERIODIC MAINTENANCE AND MINOR REPAIR General maintenance and lubrication chart ITEM • Clean with compressed air. 1 * Air filter element • Replace if necessary. • Check specific gravity and breath- 2 * Battery er hose for proper operation. • Check operation and fluid leak- 3 * Clutch age.
  • Page 45 ITEM ROUTINE • Check bearings for smooth oper- 9 * Wheel bearings ation. • Replace if necessary. • Check bearing assemblies for Swingarm pivot looseness. 10 * bearings • Moderately repack with lithium- soap-based grease. • Check bearing assemblies for looseness.
  • Page 46 24 * if necessary. ing and cable • Lubricate the throttle grip housing and cable. * Since these items require special tools, data and technical skills, have a Yamaha dealer perform the service. INITIAL 600 mi 4000 mi ROUTINE (1000 km)
  • Page 47 NOTE: From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months. NOTE: The air filter needs more frequent service if you are riding in unusually wet or dusty areas. Hydraulic brake and clutch systems •...
  • Page 48: Removing And Installing The Cowling And Panels

    PERIODIC MAINTENANCE AND MINOR REPAIR Removing and installing the cowling and panels The cowling and panels shown need to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the cowling or a panel needs to be re- moved and installed.
  • Page 49: Checking The Spark Plugs

    NOTE: If any spark plug shows a distinctly dif- ferent color, the engine could be defec- tive. Do not attempt to diagnose such problems yourself. Instead, have a Yamaha dealer check the vehicle.
  • Page 50: Canister (For California Only)

    PERIODIC MAINTENANCE AND MINOR REPAIR 3. Check each spark plug for elec- trode erosion and excessive car- bon or other deposits, and replace it if necessary. Specified spark plug: NGK/DPR8EA-9 DENSO/X24EPR-U9 To install a spark plug 1. Measure the spark plug gap with a wire thickness gauge and, if nec- essary, adjust the gap to specifica- tion.
  • Page 51: Engine Oil And Oil Filter Cartridge

    EAU19871 Engine oil and oil filter cartridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 52 1. Oil filter cartridge 2. Oil filter wrench NOTE: An oil filter wrench is available at a Yamaha dealer. 5. Apply a thin coat of engine oil to the O-ring of the new oil filter car- tridge. 1. O-ring...
  • Page 53: Final Gear Oil

    ECA10400 CAUTION: If the oil level warning light flickers or remains on, immediately turn the engine off and have a Yamaha dealer check the vehicle. 10. Turn the engine off, and then check the oil level and correct it if necessary.
  • Page 54: Coolant

    PERIODIC MAINTENANCE AND MINOR REPAIR 2. Remove the oil filler bolt, and then check the oil level in the final gear case. NOTE: The oil level should be at the brim of the filler hole. 1. Final gear oil filler bolt 2.
  • Page 55 If water has been added to the coolant, have a Yamaha dealer check the antifreeze content of the coolant as soon as possible, otherwise the effectiveness of the coolant will be reduced.
  • Page 56 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Radiator cap 5. Turn the coolant drain cock, mak- ing sure to align the “ON” with the position indicator. 1. Coolant drain cock 2. Position indicator 6. Remove the water pump drain bolt to drain the water pump housing. 1.
  • Page 57 18. Start the engine, and then check the vehicle for coolant leakage. If coolant is leaking, have a Yamaha dealer check the cooling system. 19. Install the cowling and the panel.
  • Page 58: Cleaning The Air Filter Element

    PERIODIC MAINTENANCE AND MINOR REPAIR Cleaning the air filter element The air filter element should be cleaned at the intervals specified in the periodic maintenance and lubrication chart. Clean the air filter element more fre- quently if you are riding in unusually wet or dusty areas.
  • Page 59: Adjusting The Carburetors

    The carburetors are important parts of the engine and emission control sys- tem, which require very sophisticated adjustment. Therefore, all carburetor adjustments should be left to a Yamaha dealer, who has the necessary profes- sional knowledge and experience. PERIODIC MAINTENANCE AND MINOR REPAIR...
  • Page 60: Tires

    PERIODIC MAINTENANCE AND MINOR REPAIR Tires To maximize the performance, durabil- ity, and safe operation of your motor- cycle, note following regarding the specified tires. Tire air pressure The tire air pressure should be checked and, if necessary, adjusted before each ride.
  • Page 61 Yamaha dealer immediately and have the tire replaced. Minimum tire tread depth (front and rear): 1.0 mm (0.04 in) EWA10580...
  • Page 62: Cast Wheels

    The wheel rims should be checked for cracks, bends, warpage or damage before each ride. If any damage is found, have a Yamaha dealer replace the wheel. Do not attempt even the smallest repair to the wheel. A deformed or cracked wheel must be replaced.
  • Page 63: Clutch Lever Free Play

    If there is air in the hydraulic system, have a Yamaha dealer bleed the system before operating the motor- cycle. 6-23...
  • Page 64: Adjusting The Rear Brake Light Switch

    If a brake pad has worn to the point that the wear indi- cator almost touches the brake disc, have a Yamaha dealer replace the brake pads as a set. EAU22311...
  • Page 65: Checking The Brake And Clutch Fluid Levels

    EAU22680 Checking the brake and clutch fluid levels Front brake 1. Minimum level mark Rear brake 1. Panel B 2. Minimum level mark PERIODIC MAINTENANCE AND MINOR REPAIR Clutch 1. Minimum level mark Insufficient brake fluid may allow air to enter the brake or clutch systems, pos- sibly causing them to become ineffec- tive.
  • Page 66: Changing The Brake And Clutch Fluids

    Yamaha dealer check the cause. Changing the brake and clutch fluids Have a Yamaha dealer change the brake and clutch fluids at the intervals specified in the NOTE after the periodic fluid maintenance and lubrication chart. In...
  • Page 67: Checking And Lubricating The Throttle Grip And Cable

    EAU23110 Checking and lubricating the throttle grip and cable The operation of the throttle grip should be checked before each ride. In addi- tion, the cable should be lubricated or replaced at the intervals specified in the periodic maintenance chart. PERIODIC MAINTENANCE AND MINOR REPAIR EAU23131 Checking and lubricating the...
  • Page 68: Checking And Lubricating The Brake And Clutch Levers

    WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Recommended lubricant: Lithium-soap-based grease (all-pur- pose grease) 6-28...
  • Page 69: Checking The Front Fork

    PERIODIC MAINTENANCE AND MINOR REPAIR ECA10590 CAUTION: If any damage is found or the front fork does not operate smoothly, have a Yamaha dealer check or re- pair it. 6-29 EAU23280 Checking the steering Worn or loose steering bearings may cause danger.
  • Page 70: Checking The Wheel Bearings

    If there is play in the wheel hub or if the wheel does not turn smoothly, have a Yamaha dealer check the wheel bearings. 6-30 EAU23351 Battery 1.
  • Page 71 NOTE: Make sure that the vehicle is positioned straight up when checking the electro- lyte level. 2. Check the electrolyte level in the battery. NOTE: The electrolyte should be between the minimum and maximum level marks. 1. Maximum level mark 2.
  • Page 72 PERIODIC MAINTENANCE AND MINOR REPAIR • INTERNAL: Drink large quan- tities of water or milk and im- mediately call a physician. • EYES: Flush with water for 15 minutes and seek prompt medical attention. Batteries produce explosive hy- drogen gas. Therefore, keep sparks, flames, cigarettes, etc., away from the battery and pro- vide sufficient ventilation when...
  • Page 73: Replacing The Fuses

    4. After installation, make sure that the battery leads are properly con- nected to the battery terminals and that the breather hose is properly routed, in good condition, and not obstructed. ECA10600 CAUTION: If the breather hose is positioned in such a way that the frame is ex- posed to electrolyte or gas expelled from the battery, the frame could...
  • Page 74: Replacing The Headlight Bulb

    3. Turn the key to “ON” and turn on the electrical circuit in question to check if the device operates. 4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system. Replacing the headlight bulb This model is equipped with a quartz bulb headlight.
  • Page 75: Replacing A Turn Signal Light Bulb Or The Tail/Brake Light Bulb

    5. Install the headlight bulb cover, and then connect the coupler. 6. Install the headlight unit by install- ing the screws. 7. Have a Yamaha dealer adjust the headlight beam if necessary. PERIODIC MAINTENANCE AND MINOR REPAIR EAU24281 Replacing a turn signal light bulb or the tail/brake light bulb 1.
  • Page 76: Front Wheel

    PERIODIC MAINTENANCE AND MINOR REPAIR Front wheel To remove the front wheel WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger of it falling over. 1. Place the motorcycle on the cen- terstand.
  • Page 77: Rear Wheel

    Rear wheel EAU25100 To remove the rear wheel EWA10820 WARNING It is advisable to have a Yamaha dealer service the wheel. Securely support the motor- cycle so that there is no danger of it falling over. 1. Remove the axle nut, and then loosen the rear wheel axle pinch bolt.
  • Page 78 PERIODIC MAINTENANCE AND MINOR REPAIR 1. Nut 2. Cotter pin 3. Brake torque rod 4. Bolt 5. Spacer 6. Brake caliper bracket 5. While supporting the rear wheel, pull the wheel axle out. 6. Remove the brake caliper bracket and spacer. 7.
  • Page 79: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.
  • Page 80: Troubleshooting Charts

    There is no compression. check the vehicle. Wipe off with a dry cloth and correct the spark plug gaps, or replace the spark plugs. Have a Yamaha dealer check the vehicle. The engine turns over The battery is good. quickly.
  • Page 81 The coolant level is low. Check the cooling system for leakage. Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. 6-41 EWA10400 There is Have a Yamaha dealer check leakage.
  • Page 82: Motorcycle Care And Storage

    MOTORCYCLE CARE AND STORAGE Care While the open design of a motorcycle reveals the attractiveness of the tech- nology, it also makes it more vulnera- ble. Rust and corrosion can develop even if high-quality components are used. A rusty exhaust pipe may go un- noticed on a car, however, it detracts from the overall appearance of a motor- cycle.
  • Page 83 After normal use Remove dirt with warm water, a mild detergent, and a soft, clean sponge, and then rinse thoroughly with clean water. Use a toothbrush or bottlebrush for hard-to-reach areas. Stubborn dirt and insects will come off more easily if the area is covered with a wet cloth for a few minutes before cleaning.
  • Page 84: Storage

    MOTORCYCLE CARE AND STORAGE Avoid using abrasive polishing compounds as they will wear away the paint. NOTE: Consult a Yamaha dealer for advice on what products to use. EAU26230 Storage Short-term Always store your motorcycle in a cool, dry place and, if necessary, protect it against dust with a porous cover.
  • Page 85 EWA10950 WARNING To prevent damage or injury from sparking, make sure to ground the spark plug electrodes while turning the engine over. 6. Lubricate all control cables and the pivoting points of all levers and pedals as well as of the side- stand/centerstand.
  • Page 86: Specifications

    SPECIFICATIONS Dimensions: Overall length: 2300 mm (90.6 in) Overall width: 795 mm (31.3 in) Overall height: 1160 mm (45.7 in) Seat height: 765 mm (30.1 in) Wheelbase: 1590 mm (62.6 in) Ground clearance: 145 mm (5.71 in) Minimum turning radius: 2900 mm (114.2 in) Weight: With oil and fuel:...
  • Page 87 Manufacturer/model: DENSO/X24EPR-U9 Spark plug gap: 0.8–0.9 mm (0.031–0.035 in) Clutch: Clutch type: Wet, multiple-disc Transmission: Primary reduction system: Spur gear Primary reduction ratio: 87/49 (1.776) Secondary reduction system: Shaft drive Secondary reduction ratio: 21/27 × 33/09 (2.852) Transmission type: Constant mesh 5-speed Operation: Left foot operation Gear ratio:...
  • Page 88 SPECIFICATIONS Front suspension: Type: Telescopic fork Spring/shock absorber type: Coil-air spring/oil damper Wheel travel: 140.0 mm (5.51 in) Rear suspension: Type: Swingarm Spring/shock absorber type: Coil spring/oil damper Wheel travel: 100.0 mm (3.94 in) Electrical system: Ignition system: Transistorized coil ignition (digital) Charging system: A.C.
  • Page 89: Consumer Information

    Record the key identification number, vehicle identification number and mod- el label information in the spaces pro- vided below for assistance when ordering spare parts from a Yamaha dealer or for reference in case the vehi- cle is stolen. KEY IDENTIFICATION NUMBER:...
  • Page 90 1. Model label The model label is affixed under cowl- ing A. (See page 6-8.) Record the infor- mation on this label in the space provided. This information will be need- ed when ordering spare parts from a Yamaha dealer.
  • Page 91: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 92: Motorcycle Noise Regulation

    CONSUMER INFORMATION Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new ve- hicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.
  • Page 93: Maintenance Record

    Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your motorcycle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 94 CONSUMER INFORMATION Maintenance interval 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months Date of Mileage service Servicing dealer Remarks name and address...
  • Page 95: Yamaha Motor Corporation, U.s.a. Street And Enduro Motorcycle Limited Warranty

    CONSUMER INFORMATION EAU26661 YAMAHA MOTOR CORPORATION, U.S.A. STREET AND ENDURO MOTORCYCLE LIMITED WARRANTY...
  • Page 96 CONSUMER INFORMATION...
  • Page 97: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha Extended Service.
  • Page 98 Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your Primary ID number (your frame number). We’ll be happy to help you get the Y.E.S. coverage you need.
  • Page 99 Accessories and replacement parts ... 6-22 Air filter element, cleaning ... 6-18 Battery ... 6-30 Brake and clutch fluid levels, checking ... 6-25 Brake and clutch fluids, changing... 6-26 Brake and clutch levers, checking and lubricating... 6-28 Brake and shift pedals, checking and lubricating...
  • Page 100 INDEX Tires ... 6-20 Tool kit ... 6-1 Troubleshooting ... 6-39 Troubleshooting charts ... 6-40 Turn signal indicator light ... 3-1 Turn signal light bulb or tail/brake light bulb, replacing ... 6-35 Turn signal switch ... 3-4 Valve clearance, adjusting ... 6-19 V-Boost ...
  • Page 101 YAMAHA MOTOR CO., LTD. PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2004.04-0.3×1 CR...
