Table of Contents
Related Manuals for GN Jabra Elite 85t
Summary of Contents for GN Jabra Elite 85t
- Page 1 Jabra Elite 85t User manual...
- Page 2 GN Audio A/S. The Bluetooth word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by GN Audio A/S is under license. Made in China MODEL: OTE130R / OTE130L /...
- Page 3 1. Welcome .........5 2. Jabra Elite 85t overview .....6 2.1 Included accessories 3. How to wear ........8 3.1 Changing EarGels 4. How to charge ......10 4.1 Charging the earbuds 4.2 Fast charge the earbuds 4.3 Charging the charging case using USB 4.4 Charging the charging case using the Jabra...
- Page 4 7.9 Auto-pause music and calls 7.10 Sleep mode 7.11 MyControls 7.12 Multiple call handling 7.13 Multi-connect 7.14 Voice assistant 7.15 Voice guidance and languages 7.16 Update firmware 7.17 Reset the earbuds 8. Jabra Sound+ app ...... 32 9. Support ........33 9.1 FAQ 9.2 How to care for your earbuds 9.3 Replacement accessories...
- Page 5 1. Welcome Thank you for using the Jabra Elite 85t. We hope you will enjoy it! Jabra Elite 85t features • Accept No Compromise. Jabra Advanced ANC™ gives you fully adjustable noise cancellation in a compact design. • Big sound. Small body. 12mm speakers for massive sound and powerful bass.
- Page 6 2. Jabra Elite 85t overview Jabra Elite 85t earbuds LEFT EARBUD RIGHT EARBUD Vent holes Vent holes Right Left button button Microphones Microphones Wireless charging case Charging port Qi-certified wireless charging...
-
Page 7: Included Accessories
2.1 Included accessories EarGels pre-mounted on the earbuds USB-A to USB-C charging cable... -
Page 8: How To Wear
3. How to wear Microphone Insert each earbud into your ear and ensure the microphones are pointed towards your mouth. The EarGels have an oval shape to provide you a better fit in the ear. This means that the body of the earbud does not sit as deeply within the ear. -
Page 9: Changing Eargels
3.1 Changing EarGels For the optimal audio and ANC experience, it is recommended to try each of the different EarGel sizes. The fit should feel light and comfortable in your ear. The medium EarGels are pre-mounted on the earbuds. When attaching a new EarGel, ensure the oval mounting tip on the earbud is aligned with the oval attachment on the EarGel. -
Page 10: How To Charge
4. How to charge Get up to 5.5 hours on a single charge with ANC on, with a total charge of up to 25 hours with the charging case. If you use the earbuds without ANC and HearThrough, you’ll get even more battery, with up to 7 hours in the earbuds and a total of 31 hours with the charging case. - Page 11 4.2 Fast charge the earbuds When the earbuds are at low battery, placing them in the charging case for 15 minutes will fast charge the earbuds and give up to 60 minutes of battery. Fast charging the earbuds requires that the charging case has a minimum of 30% battery.
- Page 12 4.3 Charging the charging case using USB Plug the supplied USB-A to USB-C charging cable into the charging case and a USB-A power supply or certified wall charger. It takes up to 3 hours to fully charge the earbuds and the charging case.
- Page 13 4.4 Charging the charging case using the Jabra wireless charging pad The charging case is Qi-certified. Place the charging case on the Jabra wireless charging pad. The LED on the charging case will flash to indicate the charging case is placed correctly. It takes up to 3.5 hours to fully charge the earbuds and the charging case.
-
Page 14: What The Leds Mean
5. What the LEDs mean EARBUD STATUS High battery/Power on Power off Pairing Medium battery Resetting Low battery BATTERY STATUS WHEN OPENING CHARGING CASE High battery Low battery Medium battery... - Page 15 CHARGING STATUS WITH USB CABLE Firmware updating High battery Medium battery Firmware update error (see Section 7.16) Low battery Fully charged CHARGING STATUS WITH WIRELESS CHARGING PAD Firmware updating High battery Medium battery Firmware update error (see Section 7.16) Low battery...
-
Page 16: How To Pair
6. How to pair 6.1 Pairing with a mobile device 3 Sec 1. Power on the earbuds by removing them from the charging case. Alternatively, press and hold the Left and Right buttons (1 sec) simultaneously to power the earbuds on. 2. -
Page 17: How To Use
7. How to use Left button Right button 7.1 Power the earbuds off/on Place the earbuds in the charging case to power them off, or remove them from the charging case to power them on. Alternatively, the earbuds can be manually powered off by pressing the Left and Right buttons on the earbuds simultaneously. -
Page 18: Music Controls
7.2 Music controls Left earbud Function Right earbud Press the Right Play/pause button when not music on a call Press and hold Volume up the Right button Press and hold the Volume down Left button Double-press the Left button when Next track listening to music Triple-press the... -
Page 19: Call Controls
7.3 Call controls Left earbud Function Right earbud Press the Left or Press the Left or Answer call Right button Right button Double-press Double-press the Left or Right End/Reject call the Left or Right button button Press the Left or Mute/unmute Press the Left or Right button... - Page 20 7.4 ANC, HearThrough and Voice assistant controls Left earbud Function Right earbud Press the Left Cycle between button when not ANC and on a call HearThrough Activate Voice Double-press assistant the Right button (Siri, Google when not on Assistant) a call All button functions can be reassigned using MyControls in the Jabra Sound+ app.
- Page 21 7.5 Advanced ANC Advanced Active Noise Cancellation (ANC) counters noise by detecting and analyzing the pattern of incoming sound, and then generating an anti-noise signal to cancel noise out. As a result, you experience a reduced level of surrounding noise during music and calls. Left button Cycle between...
- Page 22 7.6 HearThrough HearThrough lets you pay attention to your surroundings and engage in conversation, when not on a call, without needing to remove the earbuds. The microphones pick up surrounding sounds and transmit them to the speakers. Left button HearThrough Cycle between Press the Left button...
- Page 23 7.7 Sidetone Sidetone enables you to hear your own voice when you are on a call. The benefit of Sidetone is that it enables you to determine how loud you are speaking. Sidetone is on by default during calls and can be turned on/off using the Jabra Sound+ app.
- Page 24 7.8 Mono earbud use The right earbud can be used individually for mono music playback or for calls. When used as a mono earbud, the right earbud retains its current button functionality. To use the right earbud as a mono earbud, place it in your ear and place the left earbud in the charging case.
- Page 25 The earbuds will automatically relink when you place both of them in your ears. 7.9 Auto-pause music and calls When one of the earbuds is removed from your ear, music will automatically pause. To unpause the music, return the earbud to your ear within 60 seconds.
- Page 26 7.10 Sleep mode conserve battery, earbuds will automatically power off when they are out of range of your mobile device for 15 minutes and are not in the charging case, or when they have been inactive for 30 minutes. To power the earbuds on, press and hold (1 sec) the Left and Right buttons simultaneously.
- Page 27 7.11 MyControls MyControls is a feature in the Jabra Sound+ app that enables you to reassign any function to each of the earbud buttons, offering you the flexibility to configure the earbuds precisely to your personal preference. By default, the functions listed below cannot be controlled using the earbuds, however these functions can be added to the earbuds using MyControls in the Jabra Sound+ app.
-
Page 28: Multiple Call Handling
(refer to section 6). After pairing to both mobile devices, you will need to select the Jabra Elite 85t again on the first mobile device in the Bluetooth settings to complete the pairing to both mobile devices. - Page 29 7.14 Voice assistant Right button Voice assistant Activate Double-press the Right Siri, Google button when not on Assistant a call Voice assistant settings can be configured using the Jabra Sound+ app. 7.15 Voice guidance and languages Voice guidance can be turned on/off and the language can be changed using the Jabra Sound+ app.
-
Page 30: Update Firmware
7.16 Update firmware The Jabra Elite 85t can be updated to the latest firmware version using the Jabra Sound+ app. If notifications are enabled in the Jabra Sound+ app, you will receive an automatic notification when a firmware update is available. - Page 31 7.17 Reset the earbuds Resetting the earbuds clears the list of paired devices and resets all settings. 1. Place both earbuds in the charging case. 2. Press and hold (10 sec) the Left and Right buttons on the earbuds simultaneously until the LEDs on the earbuds flash purple.
-
Page 32: Jabra Sound+ App
8. Jabra Sound+ app Jabra Sound+ app Personalize your music with MySound Customize ANC, HearThrough and MyControls Register your 2-year warranty... - Page 33 9. Support 9.1 FAQ View the FAQs on Jabra.com/help/elite85t 9.2 How to care for your earbuds • Always store the earbuds in the charging case and safely protected. • To prevent the depletion of the battery lifetime or capacity, avoid storing the earbuds in hot or cold environments, such as a closed car in summer, or in winter conditions.
-
Page 34: Replacement Accessories
9.3 Replacement accessories Replacement or additional accessories can be purchased online at jabra.com/accessories. Left and right earbud set Charging case EarGels... - Page 35 Jabra wireless charging pad USB charging cables 9.4 Using replacement earbuds 1. Place the replacement earbuds into the charging case and close the lid. 2. Open the charging case lid and remove the earbuds. 3. Wear the earbuds and follow the voice instructions to pair to your mobile device.
- Page 36 9.5 Using a replacement charging case Before using a replacement charging case for the first time, it will need to be synced with your current earbuds and charged for 1 hour. To begin syncing, place your current earbuds inside the replacement charging case and close the lid for 10 seconds.
