Requirements For The Floor; Floor Covering; Floor Loading; Front Access - NCR SelfServ 22e Site Preparation

REQUIREMENTS FOR THE FLOOR

The ATM is suitable for mounting on a concrete or other non-combustible surface only.

Floor Covering

An antistatic floor covering should be used and must be of a type that will not generate
dust or fluff. The surface on which the ATM is to be sited should be level and even. In
locations where the floor may be uneven, it is recommended that a steel plate is used under
the ATM.

Floor Loading

The ATM must be installed on a floor capable of supporting the maximum weight. Only
the maximum weight should be considered as additional options may be added after
installation.

Front Access

Maximum weight
Floor loading

Rear Access

Maximum weight
Floor loading
NCR SelfServ 22e ATM Site Preparation
CEN Grade L or CEN
UL 291 24 Hours Level 1
Grade 1
520 kg
(1146.6 lb.)
2
1714 kg/m
2
(351.1 lb./ft )
CEN Grade L UL 291 24 Hours Level 1
560 kg
(1234.8 lb.)
2
1557 kg/m
2
(318.6 lb./ft )
B006-6902-D000
UL 291 Business Hours
440 kg
(970.2 lb.) (595.4 lb.)
2
1438 kg/m 896 kg/m
2
(294.5 lb./ft ) (183.4 lb./ft
475 kg
(1047.4 lb.)
2
1319 kg/m
2
(270.2 lb./ft )
270 kg
2
2
)
39
