Grab the fuse with the fuse extractor
and withdraw the fuse.
Engine compartment fuse
box
The fuse box is in the front left of the
engine compartment.
Disengage the cover and remove it.
No. Circuit
12 Heated washer jets
14 Front and rear screenwash
pump
15 Front radar system, electric
power steering
17 Built-in systems interface
Vehicle care
No. Circuit
19 Front wiper motor
20 Front and rear screenwash
pump
21 Headlight wash pump
22 Horn
23 Right high beam
24 Left high beam
After having changed defective fuses,
close the fuse box cover and lock it.
If the fuse box cover is not closed
correctly, malfunction may occur.

Instrument panel fuse box

The fuse box is located behind a
cover in the instrument panel at the
left side.
