- Page 1 REGISTER NOW TO Wheel Lock ACTIVATE YOUR PRODUCT CODE: FNP300 YEAR WARRANTY* www.purpleline.co.uk 01473 601200 design...innovate...improve MOTORHOME WHEEL LOCK Installation guide and user manual *WARRANTY REGISTRATION MUST BE COMPLETED WITHIN 14 DAYS OF PURCHASE FNP300-UM-03/2020...
- Page 2 PARTS IDENTIFICATION & FITTING DIAGRAM Fig. A Fig. B Shield Plate Wheel Bar Locking Portion Pin Grip Adjustable Pin 1mm Spacer Ring (x20) Locking Portion Hex Screw 3mm Hex Key Key (x3) Lock Cap 19mm Wheel Wrench Adapter M14 Receiver Wheel Bolt (x2) Fig.
-
Page 3: Installation
INSTALLATION The FullStop Nemesis Plus Wheel Lock is designed to secure a wheel by locking onto a replacement Wheel ® bolt, which works alongside an Adjusting Pin and Wheel Bar to then prevent wheel rotation. Before the product can be used, two of your existing wheel bolts must be removed and replaced with Receiver Wheel Bolts (12). -
Page 4: Maintenance
INSTALLATION (CONT.) Before using the device it may be necessary to add Spacer Rings (6) to ensure that, when fitted, the back face of the Shield Plate (1) is as tight as possible to the face of the wheel when the Locking Portion (3) is locked into a Receiver Bolt (12). - Page 5 ALTERNATIVE RECEIVER WHEEL BOLTS Various receiver bolt sizes are available for purchase to work in conjunction with the Nemesis Plus Wheel Lock. Please check your motorhome wheel specification or contact your motorhome manufacturer prior to purchasing or attempting to fit any Receiver Bolt. Attempting to fit the incorrect size wheel bolt can cause damage to the wheel hub of the motorhome.
-
Page 6: Product Specification
No form of consequential loss what so ever will be accepted. © Copyright 2020. Purple Line Limited, Peninsula Business Centre, Wherstead, Suffolk, IP9 2BB, UK www.purpleline.co.uk +44 1473 601200 Photographs for illustration purposes only.
