PICKERING SMOKE CONTROL ISSUE No.1 23/03/2018

UNPACK THE STOVE

Carefully cut the straps and lift the box up over the top of the stove. Remove the packing
from round the outside of the stove, it is important to protect the paint finish from any
damage, water, dust or fire cement. Using a 17mm spanner, remove the two bolts
attaching the stove to the pallet, and then replace the bolts into the stove legs, these are
used as levelling bolts if required. Open the stove door and remove the packaging from
inside the stove, there is some behind the baffle. Remove the bag inside the stove, this
contains the operating tool, instructions, stove handle cover and a pair of stove gloves.
When installing the Pickering stove please ensure that both the lower and upper
baffles are pushed to the back of the stove. There should be no gap at the back when the
baffles are in their correct position.
CLEARANCES
The Pickering Smoke Control needs to be sited next to and on a non-combustible surface.
A minimum clearance of 150mm at the sides and at least 300mm above and 50mm from
the back of the stove body will allow air circulation and not impede the performance of
the stove. If it is necessary to site the stove near a combustible surface a minimum of
250mm at the back and 450 mm at the sides must be maintained. It is a requirement that
this appliance is installed on a solid, level, non-combustible hearth conforming to current
Building Regulations.
This appliance has been tested for hearth temperatures and the maximum temperature
was 51 degrees C so is also suitable for a 12mm hearth.

INSTALLATION

A minimum flue draught of 24 Pa is required for nominal heat output. As referred to in
document J of the Building Regulations, no purpose provided ventilation is normally
required for the Pickering stove. It is important that any inlet grilles are so positioned that
they are not liable to blockage. The Appliance must be installed on a floor with an
adequate load-bearing capacity. If an existing construction doesn't meet the prerequisite,
suitable measures (e.g. load distributing plate) shall be taken to achieve it. It is important
that any inlet grilles are so positioned that they are not liable to blockage.
It is essential that the stove has adequate air supply for combustion and ventilation.
Apertures provided for this purpose shall not be restricted.
Please note where the external air kit is fitted an air vent is still required in the same
room as the stove depending on air tightness of the room, please refer to Building
Regulations Part J
The flue collar is already fixed to the top of the stove.
The Pickering smoke control stove requires a Class 1 chimney of it's own, a shared
