Operation &
Maintenance Manual
HM400-5
ARTICULATED DUMP TRUCK
SERIAL NUMBERS
HM400-5
WARNING
Unsafe use of this machine may cause serious injury or
death. Operators and maintenance personnel must read
this manual before operating or maintaining this
machine. This manual should be kept inside the cab for
reference and periodically reviewed by all personnel who
will come into contact with the machine.
- 10001
and up
ORIGINAL INSTRUCTIONS
EENAM03380
