BluStream C88 Quick Reference Manual

Introduction

FEATURES:

• Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
• Features 8 x HDMI inputs which can be independantly routed to 8 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Extends HDMI up to a distance of 70m over single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Web interface module for control and configuration of the Matrix
• Supports bi-directional IR on all HDBaseT™ outputs
• Supplied with Blustream IR Receivers and Emitters
• Control via front panel, IR, RS-232 and TCP/IP
• Supports PoC (Power over Cable) to power compatible HDBaseT™ Receivers
• 3rd party drivers available for all major home control brands
• Advanced EDID management
• HDCP 2.2 compliant
contact:
support@blustream.com.au
C88
Quick Reference Guide
4
Our Contractor 8x8 HDBaseT™ Matrix offers unprecedented performance
and value for the custom installation market. The C88 is a 4K HDCP 2.2 Matrix
delivering HDMI, bi-directional IR and PoC up to lengths of 70m over a single
CAT cable. The Matrix also provides advanced features including simultaneous
HDBaseT™ / HDMI on output 1 and a web browser interface module for control
and configuration of the Matrix.
|
