FHD Wireless Indoor Camera
Quick Installation Guide
ADT Interactive Solutions: Control & Pulse
RC845 FHD Wireless Indoor Camera
Property of ADT, LLC. Information accurate as of published date and is provided
"as is" without warranty of any kind.
©2019 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT
logo, 800 ADT.ASAP and the product/service names listed in this document are
marks and/or registered marks. Unauthorized use is strictly prohibited.
RC845-QIG (05/19)
FCC ID: P27RC845
Advertisement
Table of Contents
Related Manuals for ADT RC845
Summary of Contents for ADT RC845
- Page 1 ADT Interactive Solutions: Control & Pulse RC845 FHD Wireless Indoor Camera Property of ADT, LLC. Information accurate as of published date and is provided “as is” without warranty of any kind. ©2019 ADT LLC dba ADT Security Services. All rights reserved. ADT, the ADT logo, 800 ADT.ASAP and the product/service names listed in this document are...
-
Page 3: Table Of Contents
Mounting Suggestion .................... 20 Smart IR Function .................... 20 6 Troubleshooting .................... 21 If the Camera Continually Goes Offline ............. 21 Appendix A ........................ 22 Technical Specifications .................. 22 Regulatory Approvals ................... 22 FCC Statement (US) .................. 22 IC Statement (Canada) .................. 23 RC845 Indoor Full HD Camera Installation Guide ... -
Page 4: Introduction
This section provides information about the RC845 Indoor Day/Night HD Camera's features, components and capabilities. Overview The RC845 is an indoor day/night wireless camera with HD resolution and 802.11n Wi-Fi connectivity intended for use with both ADT Control ® and Pulse ®... -
Page 5: Physical Details
Light Sensor—This is a hardware sensor to detect daylight level or lux. Lens—The lens is fixed and cannot be adjusted. Please ensure that the lens cover remains clean of dust and debris. Rear Figure 1-2 Rear Panel RC845 Indoor Full HD Camera Installation Guide ... -
Page 6: Sd Card Slot (Future Enhancement)
Beneath this cover is a microSD card slot that will be used in a future software release. Note: As the microSD card slot is not functional at this time, please do not remove this protective cover. Figure 1-3 microSD Card Slot Location RC845 Indoor Full HD Camera Installation Guide... -
Page 7: Packaging Contents
INTRODUCTION ADT HD Indoor Camera FCC ID: P27RC845 Quick Installation Guide Packaging Contents The following items are included in the package. Figure 1-4 What's in the Box RC845 Indoor Full HD Camera Installation Guide ... -
Page 8: Basic Setup
2 Basic Setup This section provides information on how to assemble and configure the RC845 Indoor HD Camera for enrollment. Installation Assembling the Camera 1. Temporarily locate the camera close to the computer for enrollment. 2. Attach the camera stand to the camera and connect the power cable. -
Page 9: Check The Led Status
4. Mounting the Camera Mount the camera in its final permanent location. For mounting on a wall using the mounting bracket, see Section 5: Wall Mounting. Figure 2-3 Location of Status LEDs RC845 Indoor Full HD Camera Installation Guide ... - Page 10 3 ADT Control Enrollment This section provides instructions for wirelessly enrolling the RC845 Indoor HD Camera onto the ADT Control platform. This process uses the Soft AP method to wirelessly connect the HD Camera to the Customer’s network. Using Soft AP to Enroll Camera ...
-
Page 11: Adt Control Enrollment
12. Select install from the video device list to begin adding camera. If a laptop or mobile device are not on the Customer’s network, then enter the MAC address of the camera. RC845 Indoor Full HD Camera Installation Guide ... - Page 12 ADT Control ADT HD Indoor Camera Enrollment Quick Installation Guide FCC ID: P27RC845 13. Follow the on-screen instructions to finish adding the camera. RC845 Indoor Full HD Camera Installation Guide...
-
Page 13: Adt Pulse Enrollment
4 ADT Pulse Enrollment This section provides instructions for wirelessly enrolling the RC845 Indoor HD Camera into the ADT Pulse network. This process uses the Wi-Fi Protected Setup (WPS) with PIN method to wirelessly enroll the HD Camera to the gateway via the ADT Pulse Portal or TS Installer App. - Page 14 7. Enter the camera’s PIN into the WPS PIN field. Figure 4-2 Entering the PIN 8. Ensure that the camera is powered on and that the Power LED is flashing green/amber. RC845 Indoor Full HD Camera Installation Guide...
- Page 15 Note: You must complete the WPS connection within 2 minutes or else the process will timeout. The time remaining is displayed in the upper-left portion of the screen. Figure 4-4 Pressing WPS Button RC845 Indoor Full HD Camera Installation Guide ...
- Page 16 The following screen is shown while the camera is configured. 11. When the Camera Details screen appears, showing that the camera has been enrolled, assign the RC845 a unique name (usually based on the location of the camera) in the Name field, and then click Save. Figure 4-5 Saving Camera Details The Pulse enrollment is complete.
- Page 17 15. Wait until the Power LED and Network LED are both lit solid green, and then disconnect the camera from power. 16. Install the camera in its final location. Please refer to Section 5: Wall Mounting. RC845 Indoor Full HD Camera Installation Guide ...
-
Page 18: Wall Mounting
5 Wall Mounting This section provides details for final mounting of the RC845 HD Camera. You should ensure that the camera is configured and enrolled in the platform before permanently mounting it. Note: Ensure that the camera is configured and enrolled in ADT Control or Pulse before permanently mounting it. ... - Page 19 Caution: Use only the power adapter provided. Using a different power adapter can result in hardware damage. Figure 5-3 Connecting the Power Cable RC845 Indoor Full HD Camera Installation Guide ...
- Page 20 Figure 5-4 Inserting Grommet 12. Adjust the camera to the desired position and secure it firmly. 13. Verify that the camera is active on the wireless network and is recognized by the platform. RC845 Indoor Full HD Camera Installation Guide...
-
Page 21: Mounting Suggestion
2 below. Smart IR Function The RC845 uses a smart IR function for night viewing. This means that the camera automatically adjusts the IR light output and gain. As a result, if any objects are in the close foreground of the image, the camera lowers the IR light output to prevent overexposing those objects. -
Page 22: Troubleshooting
6 Troubleshooting This section provides details for troubleshooting wireless connection issues of the RC845 Indoor Day/Night HD Camera. If the Camera Continually Goes Offline If after it is enrolled the camera continually goes offline (Power LED blinks continually), the camera will automatically attempt to recover the wireless connection. -
Page 23: Technical Specifications
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. RC845 Indoor Full HD Camera Installation Guide... -
Page 24: Ic Statement (Canada)
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : l’appareil ne doit pas produire de brouillage ; l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. Cet émetteur ne doit pas être Co‐placé ou ne fonctionnant en même temps qu'aucune autre antenne ou émetteur. Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres entre le radiateur et votre corps. Exposure This device meets the exemption from the routine evaluation limits in section 2.5 of RSS102 and users can obtain Canadian information on RF exposure and compliance. Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 et la conformité à l'exposition de RSS‐102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la conformité de rf. RC845 Indoor Full HD Camera Installation Guide...
