Summary of Contents for Duroflame Batavia T3

  • Page 1 Technical manual 19.3...
  • Page 2 Page 2 of 43...

  • Page 3: Table Of Contents

    Introduction Terms of guarantee and recommendations Terms of guarantee Safety recommendations Recommendations for the operation Operation The fuel Operation Control panel 3.1.1 3.1.2 AUTO 3.1.3 ON/OFF 3.1.4 Temperature 3.1.5 Power Installing the stove 3.2.1 Precautions 3.2.2 Location of the stove 3.2.3 Connection Starting the pellet stove...
  • Page 4 4.2.1 Batavia T3 4.2.2 Rembrand T2 / Carré 4.2.3 Pelle / Rinus Problems and solutions No image No pellet supply No ignition The pellet stove becomes too hot It’s becoming too hot in the house Fault reports and solutions 6.1.1 ERROR 1 6.1.2...

  • Page 5: Introduction

    We recommend that you carefully read this manual before using the Duroflame stove to ensure optimum safety and enjoyment from your Duroflame.

  • Page 6: Terms Of Guarantee And Recommendations

    The previous paragraph does not apply to the consumer.  In the event of a correct claim under the guarantee, Duroflame will – at its discretion – provide free repair or replacement of the items, the correct execution of the agreed work or reimbursement of or a discount on the agreed price.

  • Page 7: Safety Recommendations

    Duroflame from any liability.  Any modification of the stove and replacements using non-original parts may compromise the user’s safety and releases Duroflame from any liability. It is forbidden to apply these modifications and replacements without written permission. ...

  • Page 8: Recommendations For The Operation

    Recommendations for the operation  Use the control panel to switch off the stove in the event of a power cut or malfunction.  Never manually throw pellets in the combustion pot.  If the stove fails to start up properly, remove unburned pellets before attempting to start it up again.

  • Page 9: Operation

    It is not permitted to use a Duroflame pellet stove for burning any raw materials other than wood pellets. This also applies to lighting the stove. The guarantee does not cover damage caused by using other materials and in addition safety is compromised.

  • Page 10: Use

    3 Use Observe this chapter when you start using your pellet stove. It provides a step-by-step description of what is happening and the malfunctions and problems that may occur. These are described in chapter 5 and 6 with the corresponding solutions. Control panel 3.1.1 SET This button is used to confirm or to enter a selected menu.

  • Page 11: Installing The Stove

    Installing the stove 3.2.1 Precautions The stove must be installed by qualified personnel. The stove must be installed in a suitable room, which must:  comply with the operation and environmental conditions (described in this manual).  be provided with electricity (230V 50 Hz (EN73-23). ...

  • Page 12: Connection

    3.2.3 Connection Electrical connection It is important for the stove to be installed by a specialist technician. The connection to the electricity grid is made by means of the power cable supplied. Make sure the plug remains accessible at all times when the appliance is installed. Also make sure you have a well-earthed socket.

  • Page 13: Starting The Pellet Stove

    (electric) exhaustion or other heating systems are present in the same room (e.g. a cooker hood or wood-burning stove). An external air inlet can be connected to all Duroflame pellet stoves. External air inlets allow the pellet stove to use outside air for combustion and the combustion of the stove will no longer be affected by the ventilation in the room.

  • Page 14: Switching On The Pellet Stove

    3.3.2 Switching on the pellet stove Switch on the stove using the feed switch. The feed switch is the switch the feeder cable is connected to. Possible defect: 5.1 No image 3.3.3 Ignition  Check that there are sufficient pellets in the tank. ...

  • Page 15: Pellet Stove In Operation

    Pellet stove in operation The pellet stove has successfully completed its start-up process and is now in operation. The following text is shown: VERW. MANUAL P... 3.4.1 Meaning of VERW. MANUAL This means..: ‘heating manually’. The stove must be switched on and off manually. The stove is not set using a timer and will not automatically turn on and off.

  • Page 16: Weekly Program

    3.6.2 Weekly program This is where you set the timer for the entire week. Below is a picture of the menu. We will provide a step-by-step explanation of what you are required to set. Refer to the above for details on how to proceed with the settings. This is the program number.

  • Page 17: Change Language

    3.6.3 Change language You can choose your preferred language using the power buttons. Confirm the desired language using SET. 3.6.4 Setting the pellet stove Use this menu for setting three different values: the pellet auger (7.1.4), the blower (7.1.9) and the convection fan (7.1.10). By default, these values are set to 0%. You can adjust these values between -50% and +50%.

  • Page 18: Eco Stop

    3.6.7 ECO stop Set the ECO stop if you wish for the stove to completely switch off as soon as the desired temperature has been reached. Be aware that this may have consequences for the life of your glow plug. In addition, and for ECO stop in particular, it is important that you regularly check the combustion pot for contamination to ensure that the stove starts up properly.

  • Page 19: Periodic Maintenance

    This causes slagging. When cleaning, make sure no ash or pellets are left under the combustion pot. Duroflame combustion pot used in the Batavia T3, Square and Rembrand T2 Page 19 of 43...

  • Page 20: Cleaning The Glass

    Duroflame combustion pot used in the Pelle and Rinus 4.1.2 Cleaning the glass The glass in the door must be cleaned to maintain a clear view of the fire. The frequency of cleaning depends on the pellets used. Clean the glass using a damp paper cloth dabbed in ash and wipe it dry.

  • Page 21: Maintenance Schedule

    This annual maintenance must be carried out by qualified personnel. Below are the various models and the parts to be disassembled for cleaning the flues and heat exchanger. 4.2.1 Batavia T3 Page 21 of 43...

  • Page 22: Rembrand T2 / Carré

    4.2.2 Rembrand T2 / Carré 4.2.3 Pelle / Rinus Page 22 of 43...

  • Page 23: Problems And Solutions

    5 Problems and solutions No image Nothing appears on the display screen. There may be various causes for this. No power supply; check whether the outlet has power. Check the fuses in your house. Check for a break in the cable. Replace the power cord if there is a break in the cable. Check the fuse in the switch.

  • Page 24: The Pellet Stove Becomes Too Hot

    The pellet stove becomes too hot If the pellet stove becomes too hot, it malfunctions and indicates ERROR 6 (refer to 6.1.3) on the display. The maximum thermostat (refer to 7.1.7) will switch on. This may be caused by one of several reasons: The combustion is too hot.

  • Page 25: Fault Reports And Solutions

    6 Fault reports and solutions Reset the fault by pressing and holding the ON/OFF button until you hear a beep. 6.1.1 ERROR 1 This report appears if there is no ignition. Refer to 5.3 No ignition. 6.1.2 ERROR 5 No pellets. The flue gas temperature is too low. Possible causes include: - The tank is empty.

  • Page 26: Components

    7 Components Explanation of the components 7.1.1 Printed circuit board The printed circuit board or motherboard controls every stove component. 7.1.2 Control panel The control panel or display is used to operate the stove. 7.1.3 Data cable The data cable or flat cable connects the printed circuit board and the control panel. 7.1.4 Screw conveyor motor The screw conveyor motor is attached to the bottom of the screw conveyor, also referred to as a worm.

  • Page 27: Encoder

    7.1.11 Encoder This is a sensor that measures the blower’s RPM. This is usually a black cap on top of the blower where a wheel rotates. Stoves with a continuously rotating screw conveyor motor have their encoder on the screw conveyor motor. 7.1.12 Flue gas temperature sensor This is a sensor that measures the temperature of the flue gases, so the stove can determine the amount of fire in the stove.

  • Page 28: Reading And Resetting Operating Hours

    8.1.6 Reading and resetting operating hours Go to the screen with ‘Ore Lav. Da Ass’ to determine the number of hours your stove has been burning. Read the total amount of operating hours under Ore Lav. These hours cannot be reset. Find the hours you can reset under Da Ass. If this amount exceeds 1200, the pellet stove displays a service message.

  • Page 29: Technical Specifications

    9 Technical specifications DUROFLAME DUROFLAME Batavia T3 Rembrand T2 P elletkachel bestemd vo o r gebruik in huiselijke ruimtes. P elletkachel bestemd vo o r gebruik in huiselijke ruimtes. A fstand to t aangrenzende brandbare materialen: A fstand to t aangrenzende brandbare materialen:...
  • Page 30 DUROFLAME DUROFLAME Pelle Rinus P elletkachel bestemd vo o r gebruik in huiselijke ruimtes. P elletkachel bestemd vo o r gebruik in huiselijke ruimtes. A fstand to t aangrenzende brandbare materialen: A fstand to t aangrenzende brandbare materialen: Vo o rzijde: 80 cm...
  • Page 31 DUROFLAME Carré P elletkachel bestemd vo o r gebruik in huiselijke ruimtes. A fstand to t aangrenzende brandbare materialen: Vo o rzijde: 80 cm Zijkanten: 1 5cm A chterzijde:20cm P restaties No minaal M inimaal Vermo gen 5,8kW 2,5kW Rendement...

  • Page 32: Electrical Diagram

    10 Electrical diagram Page 32 of 43...

  • Page 33: Combustion Cycles

    11 Combustion cycles This section describes the cycles the pellet stove goes through during the various combustion phases and which parameters are addressed. During this phase, the glow plug starts to glow Preheating/cleaning and the combustion pot is cleaned Time par. 29/30 During this phase, pellets are added until fire is Supplying pellets/oxygen measured in the combustion pot.
  • Page 34 This declaration of conformity shall be issued under the full responsibility of the manufacturer. Product description: Batavia T3 pellet stove for domestic use. The object described above is in accordance with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.
  • Page 35 EU declaration of conformity Product: Carré Manufacturer: Duroflame BV Verbindingsweg 17 9781 DA Bedum The Netherlands This declaration of conformity shall be issued under the full responsibility of the manufacturer. Product description: Carré pellet stove for domestic use The object described above is in accordance with Directive...
  • Page 36 Commission regulation (EU) 2015/1185 Approved laboratory which carried out the initial type of tests: SGS Nederland B.V. Leemansweg 51 6827BX Arnhem The Netherlands Notified Body 0608 Rapport EZKA/2017-02/00031-1 Bedum, 13-05-2019, Aldrik Sebens Director Duroflame BV Page 36 of 43...
  • Page 37 Commission regulation (EU) 2015/1185 Approved laboratory which carried out the initial type of tests: SGS Nederland B.V. Leemansweg 51 6827BX Arnhem The Netherlands Notified Body 0608 Rapport EZKA/2018-01/00003-2 Bedum, 13-05-2019, Aldrik Sebens Director Duroflame BV Page 37 of 43...
  • Page 38 Commission regulation (EU) 2015/1185 Approved laboratory which carried out the initial type of tests: SGS Nederland B.V. Leemansweg 51 6827BX Arnhem The Netherlands Notified Body 0608 Rapport EZKA/2017-02/00031-1 Bedum, 13-05-2019, Aldrik Sebens Director Duroflame BV Page 38 of 43...
  • Page 39 DECLARATION OF PERFORMANCE According to regulation (EU) 305/2011 n° 1810 1. Unique identifier code for product-type Batavia T3 2. Model Batavia T3 3. Intended use of the product in accordance with the Residential spaceheating appliance fired by woodpellets applicable harmonised technical specification without hot water supply 4.
  • Page 40 3. Intended use of the product in accordance with the Residential spaceheating appliance fired by woodpellets applicable harmonised technical specification without hot water supply 4. Name or trademark of the manufacturer Duroflame BV Verbindingsweg 17 9785DA Bedum The Netherlands 5. Name and address of the agent N.A.
  • Page 41 3. Intended use of the product in accordance with the Residential spaceheating appliance fired by woodpellets applicable harmonised technical specification without hot water supply 4. Name or trademark of the manufacturer Duroflame BV Verbindingsweg 17 9785DA Bedum The Netherlands 5. Name and address of the agent N.A.
  • Page 42 3. Intended use of the product in accordance with the Residential spaceheating appliance fired by woodpellets applicable harmonised technical specification without hot water supply 4. Name or trademark of the manufacturer Duroflame BV Verbindingsweg 17 9785 DA Bedum The Netherlands 5. Name and address of the agent N.A.
  • Page 43 Page 43 of 43...
