LISTS OF SPARE PARTS AND CONSUMABLES

There are multiple options available for your machine. If you need to order a piece, make sure to look in
the right list. If you need assistance, see contact information right above.
Suggested spare part list per machine for KLR.950
Numbers Part numbers
1 OS-018S
2 PE-00217
3 PE-01532
4 PE-00817
5 PE-00816
6 PE-01533
7 PE-01534
8 P17-00017
9 PM-00275
10 PE-01351
11 PM-00196-1
12 PM-01520
13 PR-95092
14 P02-00095
15 PR-95091-V2
16 PR-95059
17 PR-95116
18 PR-95090
19 PE-01517
20 PR-95095-V3
21 PM-00269
22 P02-00133
23 PR-95038
24 SG-1616IKS
25 PM-01541
26 PM-00380
27 PR-95105
28 PR-95107
29 PR-95104
30 PR-95106
31 PR-95052-V1
32 PR-95120
Quantity Descriptions
2 SPRING, OD 3/8'', WIRE 0.041'', 3 3/4'' LG.
2 FUSE GLASS 5 AMP
1 SINGLE AXIS MOTOR
2 CONNECTOR SOCKET 22-28AWG CRIMP TIN
2 CONNECTOR HOUSING 6POS 2.5MM SHROUD
STEPPER MOTOR DRIVE 1.5-4A 10-40VDC NEMA
1
17/23/24
1 FLANGE NEMA 23 FOR STEPPER MOTOR
LONG NOSE SPRING PLUNGER, 5/16-18 UNC x 1''
1
LG
JEWELERS HSS SLOTING SAW, OD 2 1/2'', BORE
1
1/2'', .057'' THICKNESS
1 TRS 24VDC 1CO
1 SLIDER_1-NH15AN
4 BEARING
1 LOWER SPLINE DRIVE SHAFT
8 BEARING
2 DRIVE PULLEY
2 IDLE WHEEL
2 PULLEY NUT
1 UPPER SPLINE DRIVE SHAFT
1 SENSOR OPTICAL 5MM MOD SLOT TYPE
1 BAG FINGER
1 PLASTIC RETRACT. PIN 1/2"
1 BEARING
GEAR SPUR, DIAMETRAL PITCH 16, 68 TEETH, BORE
1
5/8''
GEAR SPUR, DIAMETRAL PITCH 16, 16 TEETH, BORE
1
1/2''
1 BEARING 1"
1 DIE SPRING
SELECT THE CORRECT OPTIONS
2 MODIFIED TIMING BELT XL, BOTH SIDE TEETH
2 MODIFIED TIMING BELT XL
2 MODIFIED TIMING BELT XL, BOTH SIDE TEETH
2 MODIFIED TIMING BELT XL
1 SHEAR MODEL CAM
1 CLIP BREAKER MODEL CAM
