Table 1-1 Denominations

ITU
[ITU-T G.991.2]
SHDSL:
Single-Pair High-Speed DSL
STU:
SHDSL Transceiver Unit
STU-C:
SHDSL Transceiver Unit -
Central Office
STU-R:
SHDSL Transceiver Unit -
Remote End
SRU:
SHDSL Regenerator Unit
SRU-C:
SHDSL Regenerator Unit -
Central Office
SRU-R:
SHDSL Regenerator Unit -
Remote End

Application Areas for the CSX

The CSX offers transport and conversion of several service interface onto a copper
network. All this gives a wide bouquet of combinations, which will not all available or
mentioned in the order matrix. Please check with your local arcutronix partner for
your needs and possible options.
The user-side is variable and can support different types of applications, which will be
depicted in more detail below.

Ethernet First Mile

For bridging Ethernet packets directly from the central office side (CO) to the end user
(CPE) over voice-grade copper pairs, the Ethernet community standardized in [IEEE
802.3ah] the EFM PHY 2BASE-TL referring to [ITU-T G.991.2] (192kbps to 5.7Mbps).
2016-01-05
ETSI
[ETSI TS 101 524]
SDSL:
Symmetric single pair high
bit rate Digital Subscriber
Line
TU:
SDSL Termination Unit
LTU:
Line Termination Unit
NTU:
Network Termination Unit
REG:
Signal Regenerator
REG-C:
NTU side of the signal
regenerator
REG-R:
LTU side of the signal
regenerator
Abstract
CSX - Family Description
Manual
SHDSL
STU
STU-C
STU-R
SRU
SRU-C, downstream
SRU-R, upstream
